Harvey
®
DI+ Pressure Cartridge System
Model D12731, Series 1273
Operation Manual and Parts List LT1273X13 (296204)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harvey DI+ 1273 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermo Scientific Harvey DI+ 1273 Series

  • Page 1 Harvey ® DI+ Pressure Cartridge System Model D12731, Series 1273 Operation Manual and Parts List LT1273X13 (296204) Visit us online to register your warranty www.thermoscientific.com/warranty...
  • Page 2 Preface MANUAL NUMBER LT1273X13 (296204) 12/8/10 Transfer to Marietta (was LT1273X13 2/12/07) ECR/ECN DATE DESCRIPTION Thermo Scientific Harvey DI+...
  • Page 3 Thermo Fisher Scientific makes no representations or warranties with respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual. ©2010 Thermo Fisher Scientific. All rights reserved. Harvey DI+ Thermo Scientific...
  • Page 4 Always use the proper protective equipment (clothing, gloves, goggles, etc.) 4 Always dissipate extreme cold or heat and wear protective clothing. 4 Always follow good hygiene practices. 4 Each individual is responsible for his or her own safety. Thermo Scientific Harvey DI+...
  • Page 5 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
  • Page 6: Table Of Contents

    Ordering Procedures ........8-2 Thermo Scientific...
  • Page 8: Safety Information

    Safety Information Section 1 Your Thermo Scientific Harvey DI+ Pressure Cartridge System has been designed with function, reliability and safety in mind. It is your responsibility to install it in conformance with local building codes. For safe operation, pay attention to the Notes, Cautions, and Warnings throughout the manual.
  • Page 10: Technical Specifications

    Operating: 4°C - 49°C; 20% - 80% relative humidity, non-condensing. Installation Category II (over-voltage) in accordance with IEC 664. Pollution Degree 2 in accordance with IEC 664. Altitude limit: 2,000 meters. Storage: -25°C - 65°C; 10%-85% relative humidity. Thermo Scientific Harvey DI+...
  • Page 12: Unpacking And Installation

    • 4” minimum Free space above center of wall bracket: • 4” minimum The recommended dimensions for mounting hardware to support your equipment are: • Body Diameter, 1/4” maximum • Head Diameter, 3/8” maximum • Length, 1” typical Thermo Scientific Harvey DI+...
  • Page 13: Mounting And Utility Connections

    1/4” NPT male adapter for the inlet connection to the Harvey DI+. A fitting and tubing to connect the sterilizer to an atmospheric drain are supplied with the sterilizer. A pre-installation inspection should be performed being sure to carefully confirm that these connections are water tight. Harvey DI+ Thermo Scientific...
  • Page 14: Plumbing Connections

    The opposite end of this tube has a quick disconnect fitting (CUX15) which plugs into the inlet fitting on the backside of the sterilizer. Connect the sterilizer waste tubing as described in Option 1. Thermo Scientific Harvey DI+...
  • Page 15 Figure 3-1. Installation Diagram...
  • Page 16: Initial Operation

    Figure 4-2. Locking Pin Caution Secure the locking pin before turning the water supply on and operating. Locking pin on the canister must be fully released into the hole in the head before system is operated. Thermo Scientific Harvey DI+...
  • Page 17: Filling Procedure

    FITTING Caution Always use the shutoff valve to stop the flow of water into the Harvey DI+ system whenever it is unattended or not in use. INLET TUBE Figure 4-3. Cleaning the Screen Harvey DI+ Thermo Scientific...
  • Page 18: Maintenance And Servicing

    4. Remove the canister from the head and drain into the container. 5. Remove and discard the old cartridge. 6. Inspect the o-rings in the canister and replace if worn. 7. Install a new cartridge (D502118) as described under ‘Installing Water Treatment Cartridge’. Thermo Scientific Harvey DI+...
  • Page 19: General Cleaning Instructions

    If the system has remained inactive and full of water, then the system should be drained and cleaned before a new cartridge is installed. Harvey DI+ Thermo Scientific...
  • Page 20: Troubleshooting

    (city water to well water and vice versa) will result in a water quality change. If feedwater is from a central purification source, verify water quality and proper functioning of the system. Thermo Scientific Harvey DI+...
  • Page 22: Exploded View

    02273 FP550X1 (Pin) (Shutoff Valve) BR550X2 with (2) 06440 (Adapter w/o-ring) Outlet to Sterilizer and/or to Harvey DI+ Dispenser PMX209 (Adapter) Feedwater Inlet GSX28 (Large o-ring) CS550X1 (Canister) HN550X1A (Handle Ring) Figure 7-1. Harvey DI+ (D12731) Thermo Scientific Harvey DI+...
  • Page 24: Replacement Parts

    Recommended Quantity Single Part # Description Harvey DI+ BK583X4 Cartridge canister head CS550X1 Full-size cartridge canister HN550X1A Cartridge canister handle Thermo Scientific Harvey DI+...
  • Page 25: Ordering Procedures

    All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory.
  • Page 26 Thermo Fisher Scientific 401 Millcreek Road Marietta, Ohio 45750 United States www.thermofisher.com...
