Part of Thermo Fisher Scientific
Thermo Scientific Bantam Deionizer
Type D0800, Series 494
Operating Manual and Parts List 60119 Rev. 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thermo Scientific 494 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermo Scientific Thermo Scientific 494 Series

  • Page 1 Thermo Scientific Bantam Deionizer Type D0800, Series 494 Operating Manual and Parts List 60119 Rev. 0 _________________________________________________________________________________ Part of Thermo Fisher Scientific...
  • Page 2 Preface Models covered in this manual Model number Voltage D0800 (7107) 120V D0805 (7108) 240V MANUAL NUMBER 60119 (7007107) 6/4/10 Transfer to Marietta (was 60119 3/12/08) ECR/ECN DATE DESCRIPTION Thermo Scientific Deionizer...
  • Page 3 Thermo Fisher Scientific makes no representations or warranties with respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual. ©2010 Thermo Fisher Scientific. All rights reserved. Deionizer Thermo Scientific...
  • Page 4 Always use the proper protective equipment (clothing, gloves, goggles, etc.) 4 Always dissipate extreme cold or heat and wear protective clothing. 4 Always follow good hygiene practices. 4 Each individual is responsible for his or her own safety. Thermo Scientific Deionizer...
  • Page 5 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
  • Page 6: Table Of Contents

    Ordering Procedures ........7-2 Thermo Scientific...
  • Page 8: Safety Information

    Your Thermo Scientific Bantam Deionizer has been designed with function, reliability, and safety in mind. It is the user’s responsibility to install it in conformance with local electrical codes. For safe operation, pay attention to Notes, Cautions, and Warnings throughout the manual.
  • Page 10: General Specifications

    (100 psig), the cartridge holder cannot without any back pressure. Ensure that maximum flow rate is not exceeded, the outlet is open to atmosphere, and there are no tubing restrictions. Provided with 1.7 m (5-1/2”) electrical cord and plug. Thermo Scientific Deionizer...
  • Page 12: Cartridge Specifications

    Electrical W x H x D in. (cm) Pressure (psi) Number 6 x 28.5 x 8.75 120 VAC D0800 Thermo Scientific Deionizer 5-70 (15.2 x 72.4 x 22.2) 240 VAC D0805 Required Accessories Model Choose the cartridge based on your application needs.
  • Page 14: Installation

    “drain” on the Deionizer to the sink and to make the plumbing service connection between the holder effluent connection at the top of the unit and the point of distribution. Thermo Scientific Deionizer...
  • Page 15: Elbow-Tubing Assembly

    2. Remove the o-ring from the elbow. 3. Install the metal grab ring and backup ring in the adapter nut, and install the nut on the elbow. Do not install the o-ring at this time. Figure 4-1. Elbow Tubing Installation Deionizer Thermo Scientific...
  • Page 16: Cartridge Installation

    In some instances, color or odor could be introduced by trace quantities of free amines or low molecular weight polymers which are present in fresh untreated resin. Generally, the amine odor lessens or disappears after passing a few gallons of water through the holder. Thermo Scientific Deionizer...
  • Page 18: Operation

    19 PPM (ionizable impurities) with equivalent indications in megohms resistance from 0.025 to 18, making possible constant monitoring of the water purity. To stop the meter from operating, set the on/off switch to the “off ” position. Thermo Scientific Deionizer...
  • Page 20: Maintenance And Servicing

    A 50,000 ohm resistance should correspond to “0.05” on the meter scale. 4. With the on/off switch set to “on,” adjust the potentiometer (screwdriver adjustment) at the bottom of the meter case to make the scale reading correspond to the simulated resistance. Thermo Scientific Deionizer...
  • Page 21 Section 6 Maintenance and Servicing Figure 6-1. Exploded View Deionizer Thermo Scientific...
  • Page 22: Replacement Parts

    21538 (115V) Meter 15597 Cartridge holder 15896 Nipple 15502 Lower Tightening Wheel 05302 D0803 Cartridge, high capacity D0760 Cartridge, anion removal D0815 Cartridge, cation removal D0809 Cartridge, Ultrapure D0813 Cartridge, organic removal D0832 Cartridge, Ultrapure & organic removal Thermo Scientific Deionizer...
  • Page 23: Ordering Procedures

    All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit, or can be obtained promptly from the factory.
  • Page 24 Thermo Scientific 401 Millcreek Road Marietta, Ohio 45750 United States www.thermofisher.com...

This manual is also suitable for:

Thermo scientific d0800Thermo scientific d0805
