  • Page 1 Instruction Manual Thermo Scientific Savant ® DNA120, ® DNA120 OP SpeedVac Concentrators...
  • Page 2 © 2008 Thermo Fisher Scientific. All rights reserved. ® “Suva ” is a registered trademark of DuPont. All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
  • Page 3: Table Of Contents

    Table of Contents Section Section Title — Introduction Page Introduction Section Section Title — Installation Page Installation Receiving Unpacking Inspection Set-up Section Section Title — Operation Page Operation Mode Selection Setting Target Time Example of Manual Run Example of Auto Run Drying Rate Other Topics Section...
  • Page 4: Introduction

    Vacuum is supplied by an integral, oil-free vacuum pump with an automatic bleeder valve. The Thermo Scientific Savant DNA120 SpeedVac has a chamber heater that counteracts evaporative sample cooling and accelerates solvent evaporation rates to shorten drying times.
  • Page 5: Set-Up

    Do not attempt to open the lid unless the unit is plugged in. OPERATION The switches on the front panel control operation of the Thermo Scientific Savant DNA SpeedVac. The LED readout displays “run” parameters in minutes. You may choose between three drying rates (LOW/MEDIUM/HIGH).
  • Page 6: Operation

    OPERATION (cont’d) ROTOR INSTALLATION. Open the lid of the rotor chamber. Carefully lower the rotor onto the drive shaft. Secure the assembly by screwing the retaining knob into the drive shaft above the rotor. Tighten it firmly but not excessively. Load the rotor and close the lid. Always balance rotor loads. There need not be a tube in each hole, but the load must be evenly distributed.
  • Page 7: Mode Selection

    MODE SELECTION The dual timer front panel permits operation of the Savant DNA120 in one of the two modes. Select switch A to either: • MANUAL-to initiate a concentrator run that you can start and stop manually. The run starts when switch A is set to “MANUAL” when switch A is set to “OFF”...
  • Page 8: Example Of Manual Run

    EXAMPLE OF A MANUAL RUN Switch A should be “OFF” . Set switch B “HEATER” to bring the HEATER time to the display. Adjust switch C until the display shows the desired setting for HEATER. You can select: • “OFF”-to disable the HEATER. •...
  • Page 9: Example Of Auto Run

    EXAMPLE OF AN AUTO RUN Switch A should be “OFF” . Before starting the Auto Run, specify, a run time as follows: Set switch B to “RUN” . Adjust switch C until the display shows the desired duration of the run in hours and minutes. Start the run by setting switch A to “AUTO”...
  • Page 10: Specifications

    SPECIFICATIONS (Subject to change without notice) Input power: 120 VAC / 60 Hz, 10A or 230 VAC / 50 Hz, 5A Vacuum Chamber: TEFLON coated aluminum casting ® Cover: • Transparent acrylic (DNA120) 230 VAC / 50 Hz unit include a safety interlock •...
  • Page 11: Accessories

    ACCESSORIES RD24 24 x 1.5 ml tubes RD36 36 x 1.5 ml tubes RD48 48 x 0.5 ml tubes RD72 72 x 0.5 ml tubes RD2MP 2 microtiter plates ANT100 Post-trap assembly (standard ONLY on DNA120 OP model) ANS121/4 Ammonia neutralizing solution 4 bottles (for/DNA120 OP) GSC100 Glass safety cover (standard on DNA120 OP) DTK120R...
  • Page 12: Appendix 1

    Add a post-trap or a chemical trap. For samples labeled with radioactivity, Thermo Scientific strongly recommends an adsorbent filter be attached to the DNA SpeedVac exhaust port. This prevents release into the laboratory environment. The DTK120R Chemical Trap Kit traps volatile radioactivity and organic solvent vapors.
  • Page 13 Ulteriori informazioni sulla conformità di Thermo Fisher Scientific con queste Direttive, l’elenco delle ditte di riciclaggio nel Vostro paese e informazioni sui prodotti Thermo Scientific che possono essere utili alla rilevazione di sostanze soggette alla Direttiva RoHS sono disponibili sul sito www.thermo.com/ Conformité...
  • Page 14 Important For your future reference and when contacting the factory, please have the following information readily available: Model Number: Serial Number: Date Purchased: The above information can be found on the dataplate attached to the equipment. If available, please provide the date purchased, the source of purchase (manufacturer or specific agent/rep organization), and purchase order number.
  • Page 16 Thermo Fisher Scientific Inc. 275 Aiken Road Asheville, NC 28804 United States www.thermofisher.com 104-3003-00 Rev D...
