User Manual (Hardware)
T(P)GS-H7624XT
24 1G Copper + 6 10G Copper (w/ PoE at/af) EN50155 OS5 Managed Ethernet Switch
T(P)GS-H7624XFT
24 1G Copper + 4 10G Copper + 2 10Q Q-ODC Fiber (w/ PoE at/af)
EN50155 OS5 Managed Ethernet Switch
T(P)GS-H7616XT
16 1G Copper + 6 10G Copper (w/ PoE at/af) EN50155 OS5 Managed Ethernet
Switch
T(P)GS-H7608XT
8 1G Copper + 6 10G Copper (w/ PoE at/af) EN50155 OS5 Managed Ethernet Switch
V1.01
MAR. 2025
RP-001-31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lantech TGS-H7624XT
Summary of Contents for Lantech TGS-H7624XT
- Page 1 User Manual (Hardware) T(P)GS-H7624XT 24 1G Copper + 6 10G Copper (w/ PoE at/af) EN50155 OS5 Managed Ethernet Switch T(P)GS-H7624XFT 24 1G Copper + 4 10G Copper + 2 10Q Q-ODC Fiber (w/ PoE at/af) EN50155 OS5 Managed Ethernet Switch T(P)GS-H7616XT 16 1G Copper + 6 10G Copper (w/ PoE at/af) EN50155 OS5 Managed Ethernet Switch...
-
Page 2: Approval Information
Approval Information Version 1.00 Name Title Date Author Greg Tsai Marketing 2025.03.17 Verifier Jacky Chou HW QA 2025.03.17 Approver Thomas Lee RD head 2025.03.17 Version Date Content of Modification Author(s) V1.00 2025.03.13 Greg Tsai V1.01 2025.03.17 Update the 110V attention Greg Tsai scenarios... - Page 3 Recommendation for Shielded network cables STP cables have additional shielding material that is used to reduce external interference. The shield also reduces emissions at any point in the path of the cable. Our recommendation is to deploy an STP network cable in demanding electrical environments. Examples of demanding indoor environments are where the network cable is located in parallel with electrical mains supply cables or where large inductive loads such as motors or contactors are in close vicinity to the camera or its cable.
-
Page 4: Important Notice
Lantech Communications Global Inc. Products offered may contain software which is proprietary to Lantech Communications Global Inc. The offer or supply of these products and services does not include or infer any transfer of ownership. -
Page 5: Fcc Warning
FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. -
Page 6: Table Of Contents
Content Chapter 1 Hardware Description ....... 6 Physical Dimension ........6 Package Content:......... 11 IP Protection ..........12 Front Panel ........... 15 LED Indicators..........19 Bypass design ..........20 Chapter 2 Hardware Installation ........ 22 Wall mount installation ......... 22 Chapter 3 Connect Cable ........ -
Page 7: Chapter 1 Hardware Description
Chapter 1 Hardware Description Lantech T(P)GS-H7XXX series are high performance OS5 EN50155 10G uplink Ethernet switches with up to 24 10/100/1000T (incl. up to 24 PoE at/af injectors) by M12 connectors which provides L2 wire speed and advanced security function for connecting PD network. - Page 8 w/o -OOB-PEXT model...
- Page 9 T(P)GS-H7624XFT Aluminum case. IP-54, 390mm(W)x108.2mm(H)x225mm(D) -OOB-PEXT model w/o -OOB-PEXT model...
- Page 10 T(P)GS-H7616XT Aluminum case. IP-54, 390mm(W)x103mm(H)x225mm(D) -OOB-PEXT model w/o -OOB-PEXT model...
- Page 11 T(P)GS-H7608XT Aluminum case. IP-54, 390mm(W)x103mm(H)x225mm(D) -OOB-PEXT model w/o -OOB-PEXT model...
-
Page 12: Package Content
1.2 Package Content: ◼ Product ◼ Console cable... -
Page 13: Ip Protection
1.3 IP Protection The IP Code, Ingress Protection Rating, sometimes also interpreted as International Protection Rating, classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water in mechanical casings and with electrical enclosures. It is published by the International Electrotechnical Commission (IEC) Solid particle protection The first digit indicates the level of protection that the enclosure provides against access... - Page 14 Liquid ingress protection The second digit indicates the level of protection that the enclosure provides against harmful ingress of water. Protected Level Testing for Details against — — protected Dripping Dripping water (vertically Test duration: 10 minutes water falling drops) shall have no Water equivalent to 1 mm harmful effect.
- Page 15 Powerful Water projected in powerful Test duration: at least water jets jets (12.5 mm nozzle) 3 minutes against the enclosure from Water volume: 100 litres per any direction shall have no minute harmful effects. Pressure: 100 kPa at distance of 3 m Immersion Ingress of water in harmful Test duration: 30 minutes...
-
Page 16: Front Panel
1.4 Front Panel ※ The PoE and bypass icon may vary depending on different models. TPGS-H7624XT (-OOB-PEXT model) TPGS-H7624XT (w/o -OOB-PEXT model) - Page 17 TPGS-H7624XFT (-OOB-PEXT model) TPGS-H7624XFT (w/o -OOB-PEXT model)
- Page 18 TPGS-H7616XT (-OOB-PEXT model) TPGS-H7616XT (w/o -OOB-PEXT model)
- Page 19 TPGS-H7608XT (-OOB-PEXT model) TPGS-H7608XT (w/o -OOB-PEXT model)
-
Page 20: Led Indicators
1.5 LED Indicators The diagnostic LEDs that provide real-time information of system and optional status are located on the front panel of the industrial switch. The following table provides the description of the LED status and their meanings for the switch. Color Status Meaning... -
Page 21: Bypass Design
ODC Fiber No device attached Notification: Q-ODC fiber ports are designed with 10G fiber interface and extend from CPU, not PHY chipset. So both these ports don’t support blinking status when data is forwarding via a fiber port or both. The port is operating in PoE mode. -
Page 23: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation There are no mechanically active moving parts in the switch, to fix the switch into an installation position, please use M4 size screw and corresponding nut and standard M4 screwdriver to install switch in the field. 2.1 Wall mount installation Please make sure the screw diameter is M4. - Page 24 Mount switch in wall with 4 fixed screws. Attach switch in wall with 4 screws Move down Tighten 4 screws...
-
Page 26: Chapter 3 Connect Cable
Chapter 3 Connect Cable Alert! PoE Budget for Managed POE Switch Model For managed PoE models, the factory-default PoE budget is 12W per port; however, users can customize the PoE budget for each port based on their requirements. Managed switches have a safety feature where, if the total PoE budget is exceeded, the last connected port will automatically be disabled to prevent overloading. - Page 27 ⚫ Pin assignment of optional power cable ECABM12-05K(F)-90-1.5M PWR1 V+ PWR1 V- BLACK PWR2 V- WHITE PWR2 V+ GREEN CON1 OPEN *The color is based on the optional power cable of Lantech. ⚫ Make sure the direction of connector is correct before you connect it.
- Page 28 ⚫ Plug power connector and screw in clockwise direction to fix it. Attention: When connecting to 110V DC power sources, the following scenarios can damage to the switch. Please avoid these scenarios.
-
Page 29: Console & Usb Dongle M12 Connector
3.2 Console & USB dongle M12 connector ⚫ Pin assignment of console & USB dongle ⚫ Make sure the connector is the right direction before you connect it. ⚫ Plug console connector and screw in clockwise direction to fix it. For push-pull cable, just... -
Page 30: Di/Do M12 Connector
plug the cable to the connector. 3.3 DI/DO M12 connector In case of event, the switch being able to send an email to pre-defined addresses as well as SNMP Traps out immediately. It provides 2DI and 2DO (DI=Digital input / DO=Digital output). - Page 31 ⚫ Make sure the direction of connector is correct before you connect it. ⚫ Plug DI/DO connector and screw in clockwise direction to fix it. For push-pull cable, just plug the cable to the connector.
-
Page 32: 10G Interface M12 Connector
3.4 1G/10G interface M12 connector ⚫ Pin assignment of the 1G/10G copper port ⚫ Make sure the direction of connector is correct before you connect it. ⚫ Plug connector and screw in clockwise direction to fix it. For push-pull cable, just plug the cable to the connector. -
Page 33: Q-Odc Fiber Interface
3.5 Q-ODC fiber interface ⚫ Make sure the direction of connector is correct before you connect it. ⚫ Plug connector. 3.6 Ground interface M6 connector Ground The chassis is grounded via a separate grounding nut (M6). Use toothed locking washers for a good electrical connection. *Note: The torque should not be over 14 kilogram-force centimeter (kgf·cm). - Page 34 Ground screw of the switch...
-
Page 35: Chapter 4 Maintenance
Chapter 4 Maintenance Check each switch connection and make sure they are all screwed correctly. Keep the anti-dust cap on all un-used switch interface Access switch via web browser and check the below points: Compare the physical connection of the switch port with the switch icon on the web user interface to make sure the connecting status match each other. -
Page 36: Chapter 5 Console Management
Chapter 5 Console Management 5.1 Connecting to the Console Port The supplied cable has one M12 4-pole connector end and another RS-232 connector end. Attach the RS-232 connector end to a PC or terminal and the other M12 connector end to the console port of the switch. The connected terminal or PC must support the terminal emulation program. -
Page 37: Chapter 6 Reset The Switch
The settings of communication parameters Having finished setting up the parameters, click ‘OK’. When the blank screen shows up, press the Enter key to have the login prompt appear. Key in ‘admin’ (default value) for both User name and Password (use Enter key to switch), then press Enter and the Main Menu of console management should appear. - Page 38 ===============Notice=============== For web-based management, please refer to our “Software Management Manual”. Please contact us for more information.
