- Page 1 Quick Start Guide ---Apply to WL-ODU350 5G Outdoor Router V1.1 http://www.wlink-tech.com Feb, 2025...
-
Page 2: Table Of Contents
WL-ODU350 QuickStart Hardware Installation ...............................3 Packing Contents .............................3 Antenna Installation ............................3 SIM Installation ..............................3 Power on Router .............................. 4 Mount Kits Installation ............................. 5 LED Status Indication ............................6 Configuration ................................7 Login ...................................7 Overview ................................8 Traffic Stats............................... 8 Device List .................................9 Tool Column .............................. -
Page 3: Hardware Installation
WL-ODU350 QuickStart Mount Kits WL-ODU350 5G/Wi-Fi Antennas PoE Power Adapter SIM1 slot is at bottom which is close to PCB board. SIM2 is at the upper slot. -
Page 4: Power On Router
WL-ODU350 QuickStart Connect PoE(passive) port via RJ45 Cable between WL-ODU350 and Wlink power adapter. Connect LAN port of Power adapter to PC to configure the router. -
Page 5: Mount Kits Installation
WL-ODU350 QuickStart... -
Page 6: Led Status Indication
WL-ODU350 QuickStart silk-screen status Indication Signal Constant light LED1: weak (CSQ0~10). LED2: good (CSQ11~19) LED3: strong (CSQ20~31) Signal Blink dialing Signal 1 Constant light online Constant Light System power operation. Constant light WLAN enable, but no data communication. WLAN Blinking quickly... -
Page 7: Configuration
Configuration Login To access and configure certain features of the WL-ODU350, one needs to log in to the WL-ODU350. Connect one Ethernet cable to PoE interface of device and PoE adapter, and connect other Ethernet cable between LAN of PoE adapter and PC. -
Page 8: Overview
WL-ODU350 QuickStart User name: admin Password: admin Overview The overview GUI will be display router system information, Ethernet ports status, VPN connection status, LAN information, 4G connection information and WLAN information. Figure 2-2 Router Status GUI Traffic Stats. Click Status->Traffic Stats. to enter the traffic stats.GUI.to check Cellular/WAN traffic in real-time. -
Page 9: Device List
WL-ODU350 QuickStart Figure 2-3 Traffic Stats. GUI Device List Click Status->Device List to enter the device list GUI.to check the connected devices information in the list. Figure 2-4 Device List GUI Tool Column Figure 2-5 Tool Column GUI Ping Click Tools->Ping to enter ping test GUI. Used to test the reachability of a host on an Internet IP network and to measure the round-trip time for messages sent from the originating host to a destination server. - Page 10 WL-ODU350 QuickStart Trace Click Tools->Trace to enter trace test GUI. diagnostic tool for displaying the routeand measuring transit delays of packets across an Internet IP network. Click Tools-> Log to enter Log GUI. Use to check logs in GUI, download GUI and send logs to server.
-
Page 11: Basic Network
WL-ODU350 QuickStart Bandwidth Click Bandwidth to enter bandwidth graphic GUI. Used to check cellular/LAN/Wi-Fi real-time bandwidth. System Click system to choose software reboot, hardware reboot and logout GUI. Basic Network Cellular Setting Step 1 Basic Network-> Cellular, you can modify relevant parameter according to the application. - Page 12 WL-ODU350 QuickStart Table 2-1 WAN Setting Instruction Parameter Instruction Enable Modem Enable/Disable 5G mode. Use PPP ECM dialup as default. PPP is suitable for 4G connection only. ICMP check If enable ICMP check and setup a reachable IP address as destination IP, the router will reconnect/reboot once ICMP check failed.
- Page 13 WL-ODU350 QuickStart Parameter Instruction Cellular Traffic Check The router will reconnect/reboot once there’s no Rx/Tx data. MTU configurable. 0 as default for MTU 1500 CIMI Send to Send CIMI to a defined IP and port by TCP protocol. SMS Code Remote control the router by SMS.
-
Page 14: Lan Setting
WL-ODU350 QuickStart The ICMP Check IP is a public IP or company server IP address. 【Cellular Traffic Check】 【Check Mode】there are Rx(Receive), Tx(Transmission) and Rx/Tx check modes. 【Rx】Router will check the 3G/LTE cellular receiver traffic. If no receiver traffic within the defined check interval, the router will implement the specified action reconnect or reboot. -
Page 15: Dynamic Dns Setting
WL-ODU350 QuickStart Table 2-2 LAN Setting Instruction Parameter Instruction Bridge Supports 4 LAN IP address for br0 to br3 interface. If need to support VLAN, please go to VLAN GUI. Router IP Address Router IP address, default IP is 192.168.1.1 Subnet Mask Router subnet mask, default mask is 255.255.255.0... -
Page 16: Wlan Setting
Table 2-3 DDNS Setting Instruction parameter Instruction Default is standard DDNS protocol, for customized protocol, please IP address contact Wlink engineer. Usually, use default IP 0.0.0.0 Auto refresh Set the interval of the DDNS client obtains new IP, suggest 240s or time above Service Select the DDNS service provider that listed. -
Page 17: Basic Setting
WL-ODU350 QuickStart Basic Setting Step 1 WLAN->Basic Setting to configure relative parameter Table 2-4 Basic of WLAN Setting Instruction Parameter Instruction Radio Mode 2.4G+5G mode as default. Support 2.4G, 5G modes optional. 2.4G+5G model, Wi-Fi bandwidth for 683Mbps 2.4G model, Wi-Fi bandwidth for 300Mbps... -
Page 18: Advanced Network Setting
WL-ODU350 QuickStart Advanced Network Setting Port Forwarding Step 1 Advanced Network > Port Forwarding to enter the GUI, you may modify the router name, Host name and Domain name according to the application requirement. Table 2-5 Port Forwarding Instruction Parameter... -
Page 19: Ip Passthrough Setting
WL-ODU350 QuickStart Table 2-6 DMZ Instruction parameter Instruction Destination The destination address inside the LAN. Address Source If no IP address inside, it will allow all IP address to access. Address If define IP address, it will just allow the defined IP address Restriction to access. -
Page 20: Triggered Setting
WL-ODU350 QuickStart Table 2-7 IP Passthrough Instruction parameter Instruction Enable Enable IP Passthrough MAC Address Enable DHCP of device. Configure device Mac. Device will be assigned SIM IP. Gateway If WL-G200 connect to multiple device, input other device gateway. The device might access to router GUI. -
Page 21: Captive Portal
Ex-storage: Captive portal file is in extended storage such as SD card. Web Host Configure domain name for the captive portal access. For example, Configure as wlink.tech.com, we might directly access to captive portal page in the website as wlink.tech.com Portal Host Reserved. -
Page 22: Bandwidth Control Setting
WL-ODU350 QuickStart Parameter Instruction MAC Whitelist No captive portal page for Wi-Fi device. Download QoS Enable to apply the Download and Upload per user limits. Upload Qos Maximum download speed available to each user. Step 2 Please click ”save” to finish. -
Page 23: Vrrp Setting
WL-ODU350 QuickStart Table 2-10 Bandwidth Control Instruction Max Available Download Speed limit for router. Max Available Upload Speed limit for router. IP/ IP Range/ Limit devices speed for specified IP/IP Range/ MAC MAC Address Address. DL Rate Mix Download rate... -
Page 24: Static Dhcp Setting
WL-ODU350 QuickStart Step 2 Please click ”save” to finish. ----End Static DHCP Setting Step 1 Advanced Network> Static DHCP to check or modify the relevant parameter. Step 2 Please click ”save” to finish. ----End VPN Tunnel GRE Setting Step 1 VPN Tunnel> GRE to check or modify the relevant parameter. -
Page 25: Openvpn Client Setting
WL-ODU350 QuickStart Table 2-11 GRE Instruction Parameter Instruction GRE tunnel number Tunnel Address GRE Tunnel local IP address which is a virtual IP address. Tunnel Source Router’s 3G/WAN IP address. Tunnel Destination GRE Remote IP address. Usually a public IP address Keep alive GRE tunnel keep alive to keep GRE tunnel connection. - Page 26 WL-ODU350 QuickStart...
- Page 27 WL-ODU350 QuickStart Table 2-12 Basic of OpenVPN Instruction Parameter Instruction Start with WAN Enable the Openvpn feature for 4G/3G/WAN port. Interface Type Tap and Tun type are optional. Tap is for bridge mode and Tunnel is for routing mode. Protocol UDP and TCP optional.
- Page 28 WL-ODU350 QuickStart Parameter Instruction Encryption As the configuration requested. Compression As the configuration requested. TLS Renegotiation TLS negotiation time. -1 as default for 60s. Time Connection Retry Openvpn retry to connection interval. Time Verify server As the configuration requested. certificate Custom As the configuration requested.
- Page 29 WL-ODU350 QuickStart Table 2-15 Status of OpenVPN Instruction Parameter Instruction Status Check Openvpn status and data statistics. Step 2 Please click ”save” to finish. ----End PPTP/L2TP Client Setting Step 1 VPN Tunnel> VPN Client to check or modify the relevant parameter.
- Page 30 WL-ODU350 QuickStart Table 2-17 L2TP Advanced Instruction L2TP Advanced enable Name L2TP Tunnel name Accept DNS As the configuration requested. MTU is 1450bytes as default MRU is 1450bytes as default Tunnel Auth. L2TP authentication Optional as the configuration requested. Tunnel As the configuration requested.
-
Page 31: Ipsec Setting
WL-ODU350 QuickStart IPSec Setting IPSec Group Setup Step 1 IPSec> Group Setup to check or modify the relevant parameter. Table 2-20 IPSec Group Setup Instruction parameter Instruction IPSec Support Standard IPSec, GRE over IPSec, L2TP over Extensions IPSec Local Security... - Page 32 WL-ODU350 QuickStart parameter Instruction Local Firewall Forwarding-firewalling for Local subnet Remote IPsec peer IP address/domain name. IP/Domain Remote IPSec remote subnet and mask. Subnet/Mask Remote Forwarding-firewalling for Remote subnet Firewall Step 2 Please click ”save” to finish. IPSec Basic Setup Step 1 IPSec >Basic Setup to check or modify the relevant parameter.
- Page 33 WL-ODU350 QuickStart parameter Instruction Encryption Phase 1 Support HASH MD5 and SHA Authentication Phase 1 SA IPSec Phase 1 SA lifetime Life Time Phase 2 DH Select Group1, Group2, Group5 from list. It must be Group matched to remote IPSec setting.
- Page 34 WL-ODU350 QuickStart Table 2-22 IPSec Advanced Setup Instruction parameter Instruction Aggressive Default for main mode Mode ID Payload Enable ID Payload compress Compress To enable DPD service ICMP ICMP Check for IPSec tunnel IPSec Custom IPSec advanced setting such as left/right ID.
