- Page 1 User Manual ---Apply to WL-R200 Series Industrial 3G/4G Router User Manual ---Apply to WL-R200 Series Industrial 3G/4G Router http://www.wlink-tech.com April, 2016V3.1 http://www.wlink-tech.com April, 2016...
- Page 2 Due to product updates or functional upgrading, we may renew the content of this file, and this file only for reference. All statement, information, suggestion.etc in this file does not compose any form of guarantee and we WLINK reserves the right of final explanation. Shenzhen WLINK Technology Company Limited Add：...
-
Page 3: Table Of Contents
3 Router Configuration ......................... 12 3.1 Local Configure ......................12 3.2 Basic Configuration......................13 3.3 WLAN Setting ......................... 19 3.4 Advanced Network Setting ................... 23 3.5 VPN Tunnel ........................29 3.6 System Management ....................34 3.7 Debugging Setting ......................42 www.wlink-tech.com... - Page 4 R200 Industrial Cellular Router User Manual 3.8 “RST” Button for Restore Factory Setting ..............45 3.9 Appendix (For advanced optional features only) ............46 www.wlink-tech.com...
-
Page 5: Product Introduction
Model introduction WLINK industrial grade router series have single module / single SIM card, single module / double SIM card, double module / double SIM card design, support multi-band frequency WCDMA, HSPA+, 4G FDD/TDD etc., and downward compatibility to GPRS、EDGE、... - Page 6 R200 Industrial Cellular Router User Manual Table 1-1 Router partial model table www.wlink-tech.com...
-
Page 7: Product Appearance
Typical Application Diagram WLINK 4G/3G Router widely used in Telecom, economic, advertisement, traffic, environment protection business area. For example, in economic area, R200 Series Router connect server by IPSec & GRE to ensure data security, tiny design makes it could installed into ATM machine. All these technology ensured safe and reliable data transmission, and minimize the probability of network disconnection, and maximize the usability of economic business like ATM, POS .etc. -
Page 8: Features
R200 Industrial Cellular Router User Manual Figure 1-1 Network Topology WLINK industrial router is based on mobile wireless public network or private network, build wireless data channel in mature network, to lower down the cost of wireless data transmission and technique. -
Page 9: Hardware Installation
This chapter is mainly for installation introduction, there would be some difference between the scheme and real object. But the difference doesn’t have any influence to products performance. Panel: Table 1-1 WLR200 -Structure WLINK R200 series Tech. Front Rear There are some different for Antenna interface and indicator light for the expanded Wi-Fi, GPS series. -
Page 10: Led Status
WLAN port isn’t opened Dark Green Solid light connect ok Green Blinking Data Sending Green Dark Not connected There are some difference among the LED indicator of expanded Wi-Fi, GPS function and single module/double SIM, double module/double SIM series products. www.wlink-tech.com... -
Page 11: Dimension
Before connecting, please disconnect any power resource of router 2.4.4 Power Supply In order to get high reliability, WLINK Series Router adapt supports wide voltage input range: +5V～+36VDC, support hot plug and complex application environment. www.wlink-tech.com... - Page 12 Please connect the antenna before connect the power cable, otherwise the signal maybe poor because of impedance mismatching. Notice: Step 1 Check antenna connection. Step 2 Check SIM/UIM card, confirm SIM/UIM card is available. Power on the industrial Router Step 3 ----END www.wlink-tech.com...
-
Page 13: Router Configuration
Refer to the figure below. Figure 3-3 Network Connection Step 2 Obtain a IP address automatically or set up IP address,192.168.1.xxx(XXX can be any number between 2～254) Step 3 Run an Internet Explorer and visit “http://192.168.1.1/”, to enter identify page. www.wlink-tech.com... -
Page 14: Basic Configuration
Different software version have different web configuration interface, below take R200 2.6.0.1 version as example. After visit the WEB interface, you can check the current status of Router, or modify router configuration via web interface, below is the introduction for the common setting. www.wlink-tech.com... - Page 15 Figure 3-5 Router Status GUI 3.2.1 WAN Configure Step 1 Single Click Basic Network-> WAN, you can modify relevant parameter according to the application. Figure 3-1 WAN Settings GUI Table 3-1 Cellular Setting Parameter Instruction Parameter Instruction Backup mode 4 options for WAN www.wlink-tech.com...
- Page 16 If IP2 is also unreachable, router will implement Check IP1 rule as 1 second interval, 4seconds timeout and retry 2times. 3.2.2 Cellular Network Configure Step 1 Single Click Basic Network-> Cellular, you can modify relevant parameter according to the application. www.wlink-tech.com...
-
Page 17: Lan Setting
The ICMP Check IP is a public IP or company server IP address. Step 2 After Setting, please click “save” icon. ----End 3.2.3 LAN Setting Step 1 Single Click “ Basic Network>LAN” to enter below interface www.wlink-tech.com... - Page 18 Dynamic allocation IP service, after enable, it will show the IP address range and options of lease IP Address Range IP address range within LAN Lease The valid time Step 2 After setting, please click “save” to finish, the device will reboot. ----End www.wlink-tech.com...
-
Page 19: Dynamic Dns Setting
Table 3-4 DDNS Setting Instruction parameter Instruction Default is standard DDNS protocol, for customized protocol, please IP address contact Wlink engineer. Usually, use default IP 0.0.0.0 Auto refresh Set the interval of the DDNS client obtains new IP, suggest 240s or time above Service Select the DDNS service provider that listed. -
Page 20: Wlan Setting
Step 2 Please Click “ Save “ to finish. WLAN Setting It’s mainly for router which support Wi-Fi, you can modify and configure WLAN parameter through Web GUI, below is the common setting 3.3.1 Basic Setting Step 1 Click “WLAN->Basic Setting” to configure relative parameter www.wlink-tech.com... - Page 21 The channel of wireless network, suggest keep the default Channel Width 20MHZ and 40MHZ alternative Security Support various encryption method Step 2 Please click “Save” to finish. ----End 3.3.2 Wireless Filter Setting Step 1 Single click “WLAN > Wireless Filter”. www.wlink-tech.com...
-
Page 22: Advanced Wireless Setting
Block the follow Prevent the listed MAC address to connect to router by wireless Client Step 2 Please click ”save” to finish ----End 3.3.3 Advanced Wireless Setting Step 1 Please click “WLAN> Advanced Wireless” to check or modify the relevant parameter. www.wlink-tech.com... - Page 23 R200 Industrial Cellular Router User Manual Figure 3-8 Advanced Wireless Setting GUI Step 2 Please click ”save” to finish. ----End 3.3.4 Wireless Survey Step 1 Please click “WLAN> Wireless Survey” to check survey. www.wlink-tech.com...
-
Page 24: Advanced Network Setting
Figure 3-9 Wireless Survey Setting GUI ----End Advanced Network Setting 3.4.1 Port Forwarding Step 1 Please click “Advanced Network > Port Forwarding” to enter the GUI, you may modify the router name, Host name and Domain name according to the application requirement. www.wlink-tech.com... -
Page 25: Dmz Setting
Step 1 Please click “Advanced Network> DMZ” to check or modify the relevant parameter. Figure 3-11 DMZ GUI Table 3-9 “DMZ” Instruction parameter Instruction Destination The destination address inside the LAN. Address Source If no IP address inside, it will allow all IP address to access. www.wlink-tech.com... - Page 26 Forwarded Ports are the WAN to LAN ports that are Ports opened if the "trigger" is activated. Note Port triggering opens an incoming port when your computer is using a specified outgoing port for specific traffic. Step 2 Please click ”save” to finish. ----End www.wlink-tech.com...
-
Page 27: Firewall Setting
Table 3-11 “Firewall” Instruction Parameter Instruction Applies To White list. Blocked Black list. Resources Step 2 Please click ”save” to finish. 3.4.5 Serial App. Setting Step 1 Please click “Advanced Network> Serial App” to check or modify the relevant parameter. www.wlink-tech.com... - Page 28 Send heart beat to the defined server to keep router online. Content Meantime, it’s convenient to monitor router from server. Heart beat Heart beat interval time Interval Baud Rate 115200 as default Parity Bit None as default Data Bit 8bit as default Stop Bit 1bit as default www.wlink-tech.com...
- Page 29 Step 1 Please click “Advanced Network> Upnp/NAT-PMP” to check or modify the relevant parameter. Figure 3-15 UPnp/NAT-PMP Setting GUI Step 2 Please click ”save” to finish. 3.4.7 Static DHCP Setting Step 1 Please click “Advanced Network> Static DHCP” to check or modify the relevant parameter. www.wlink-tech.com...
-
Page 30: Vpn Tunnel
Step 1 Please click “VPN Tunnel> GRE” to check or modify the relevant parameter. Figure 3-17 GRE Setting GUI Table 3-13 “GRE” Instruction Parameter Instruction GRE tunnel number Tunnel Address GRE Tunnel local IP address which is a virtual IP address. Tunnel Source Router’s 3G/WAN IP address. www.wlink-tech.com... - Page 31 Step 2 Please click ”save” to finish. 3.5.2 VPN Client Setting Step 1 Please click “VPN Tunnel> VPN Client” to check or modify the relevant parameter. Table 3-14 “VPN Client” Instruction parameter Instruction VPN Mode VPN Mode for PPTP and L2TP www.wlink-tech.com...
- Page 32 MRU is 1450bytes as default Local IP Defined Local IP address for tunnel Address Step 2 Please click ”save” to finish. 3.5.3 IPSec Setting 3.5.3.1 IPSec Group Setup Step 1 Please click “IPSec> Group Setup” to check or modify the relevant parameter. www.wlink-tech.com...
- Page 33 Remote IPSec remote subnet and mask. Subnet/Mask Remote Forwarding-firewalling for Remote subnet Firewall Step 2 Please click ”save” to finish. 3.5.3.2 IPSec Basic Setup Step 1 Please click “IPSec >Basic Setup ” to check or modify the relevant parameter. www.wlink-tech.com...
- Page 34 Phase 2 SA IPSec Phase 2 SA lifetime Life Time Preshared Key Preshared Key Step 2 Please click ”save” to finish. 3.5.3.3 IPSec Advanced Setup Step 1 Please click “IPSec >Advanced Setup ” to check or modify the relevant parameter. www.wlink-tech.com...
-
Page 35: System Management
IPSec advanced setting such as left/right ID. Options Step 2 Please click ”save” to finish. ----End System Management 3.6.1 Identification Setting Step 1 Please click ”Administrator> Identification” to enter the GUI, you may modify the router name, Host name and Domain name according to self-requirement. www.wlink-tech.com... - Page 36 Default is router, can be set maximum 32 character Domain name Default is empty, support maximum up to 32 character, it is the domain of WAN, no need to configure for most application. Step 2 Please click ”save” to finish ----End www.wlink-tech.com...
-
Page 37: Time Setting
Step 1 Please click “Administrator> time” to check or modify the relevant parameter. Figure 3-19 System Configuration GUI If the device is online but time update is fail, please try other NTP Time Server. Step 2 Please click “save to finish. ----End www.wlink-tech.com... - Page 38 In this page, you can configure the basic web parameter, make it more convenient for usage. Please note the “password” is the router system account password. Figure 3-20 Admin Setting GUI Step 2 Please click save iron to finish the setting ----End www.wlink-tech.com...
-
Page 39: Snmp Setting
Step 1 Please click “Administrator>Schedule Reboot” to check and modify relevant parameter. Figure 3-21 Scheduler Reboot Setting GUI Step 2 Please click save iron to finish the setting ----End 3.6.5 SNMP Setting Step 1 Please click “Administrator>SNMP” to check and modify relevant parameter. www.wlink-tech.com... - Page 40 Figure 3-22 SNMP Setting GUI Step 2 Please click save iron to finish the setting ----End 3.6.6 M2M Access Setting (Apply to M2M management platform installation only) Step 1 Please click “Administrator>M2M Access” to check and modify relevant parameter. www.wlink-tech.com...
-
Page 41: Backup Setting
Step 1 Please click “ Administrator> Back up Configuration ” to do the backup setting Figure 3-24 Backup and Restore Configuration GUI Restore Default would lose all configuration information, please be careful. Step 2 After setting the backup and restore configuration. The system will reboot automatically. ----End www.wlink-tech.com... -
Page 42: System Log Setting
Step 1 Please click “Administrator> Logging” to start the configuration, you can set the file path to save the log (Local or remote sever). Figure 3-25 System log Setting GUI Step 2 After configure, please click “Save” to finish. ----End www.wlink-tech.com... -
Page 43: Debugging Setting
“Yes” or “NO” before the next step. Step 2 If choose “yes”, the system will restart, all relevant update configuration will be effective after reboot. ----End Debugging Setting 3.7.1 Logs Setting Step 1 Please click “Debugging>Logs” to check and modify relevant parameter. www.wlink-tech.com... - Page 44 Step 1 Please click “Debugging>Logs” to check and modify relevant parameter. Figure 3-28 Ping GUI Step 2 After configure, please click “Save” to finish. ----End 3.7.3 Trace Setting Step 1 Please click “Debugging>Trace” to check and modify relevant parameter. www.wlink-tech.com...
- Page 45 R200 Industrial Cellular Router User Manual Figure 3-29 Trace GUI Step 2 After configure, please click “Save” to finish. ----End www.wlink-tech.com...
- Page 46 The system will be restored to factory. Table 3-19 System Default Instruction Parameter Default setting LAN IP 192.168.1.1 LAN Subnet Mask 255.255.255.0 DHCP server Enable User Name admin Password admin After reboot, the previous configuration would be deleted and restore to factory settings. www.wlink-tech.com...
-
Page 47: Gps Setting
Figure 3-30 GPS Setting GUI Table 3-20 “GPS” Instruction parameter Instruction GPS Mode Enable/Disable GPS Format NMEA and M2M_FMT(WLINK) Server IP/Port GPS server IP and port Heart-Beat If choose M2M_FMT format, heart-beat ID will be packed into GPS data. Interval GPS data transmit as the interval time. - Page 48 Speed over ground, units is km/h. gps_degrees numeric 91.5 Course over ground, unit is degree. gps_FS digit Position Fix Status Indicator, gps_HDOP numeric HDOP, Horizontal Dilution of Precision gps_MSL numeric 97.5 MSL Altitude, units is meter. -- The end www.wlink-tech.com...
