Fibre Optic Cable
The marking head is connected to the actual laser source in the laser
rack via an approx. 2.1 m long fibre optic cable. The fibre optic cable is
enclosed with the jumper cables in a black protective tube for
protection. In order not to damage the filaments, do not bend the cable
by a radius of more than 66 mm. The tube should also not be subject
to any mechanical stresses.
If necessary, the cable and the fibre optic cable may be disconnected
from the marking head. As this will expose sensitive optical surfaces,
this may only be performed by trained service personnel.
Laser rack and PC
The laser rack and the PC should be located next to or directly above
one another if possible in order for the modules to be connected to
one another with the cables provided.
When installing in a control cabinet or rack, ensure there is sufficient
ventilation. Both the laser rack and the PC require a sufficient supply
of air. The air should be sucked in from the front and blown out at the
rear.
When installing the laser rack, also ensure the minimum radius of
curvature of the fibre optic cable (black tube) is not exceeded on the
rear side.
Galvo controller card
The enclosed galvo controller card needs to be installed in a
Computer.
The Installationmanual is enclosed in the accessory.
Softwareinstallation
The software will be installed by starting the SETUP.exe from the
SoftwareCD. Please follow the steps on the Screen.
The correct configurations files must be installed after the Software
Setup is finished.
The Installationmanual is enclosed in the accessory.
