  • Page 1 AXIAL FANS Sileo Design OPERATION MANUAL...
  • Page 2 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Disconnect the fan from power supply prior to any connection, servicing and repair operations. Only duly qualified electricians with valid electrical permit for electric operations at the units with operating voltage up to 1000 V are allowed for mounting and maintenance after careful study of the present user's manual.
  • Page 3 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING While mounting the fan avoid the casing compression! Deformation of the casing may result in the motor jam and excessive noise. Misuse of the fan and any unauthorised modifications are not allowed. Take steps to prevent ingress of smoke, carbon monoxide and other combustion products into the room through open chimney flues or other fire-protection devices.
  • Page 4 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Do not use the fan in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the fan intake or extract vents in order to ensure the efficient stream.
  • Page 5 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING The product is allowed to be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge provided that they have been given supervision or instruction regarding a safe use of the product and understand the risks involved.
  • Page 6: Delivery Set

    Read the user's manual carefully before proceeding with installation works. Compliance with the manual requirements ensures reliable operation and long service life of the product. Keep the user's manual available as long as you use the product. You may need to re-read the information on the product servicing. DELIVERY SET 1.
  • Page 7: Maintenance

    OPERATION GUIDELINES The fan is rated for connection to single-phase AC power mains: 220 240 V / 50 Hz or 220 240 V / 60 Hz power supply, depending on the model type. For more detailed information, see the casing sticker. The fan is rated for operation at the ambient temperature ranging from +1 °C up to +45 °C.
  • Page 8: Transportation And Storage Rules

    TRANSPORTATION AND STORAGE RULES Transportation with any transportation vehicle in the manufacturer's original package. Store the delivered product in the manufacturer's original packing box in a dry ventilated premise with the temperature from +5 °C up to + 40 °C and relative humidity below 80 %. The storage environment must not contain dust, acid or alkali vapours that may cause corrosion of the product parts.
  • Page 9 External damage to the casing (excluding external modifications of the fan as required for its installation) and the internal components of the fan. Alteration of the fan design or engineering changes of the fan. Replacement and use of the assemblies, parts and components not approved by the manufacturer. Not intended use of the fan.
  • Page 10 openings for latches...
  • Page 12 Sileo Design 100 Fan does not run Switch is ON Fan runs Sileo Design 100 S Switch is OFF T/T1/ST T/ST Sileo Design 100 T/T1 Fan does not run Fan does not run Switch is ON Switch is ON Activation of turn-on delay...
  • Page 13 Sileo Design 100 H Sileo Design 100 H Fan does not run Switch is ON Humidity is above set point Fan runs Fan runs Switch is OFF Humidity is below set point Humidity is above Activation of turn-off delay set point...
  • Page 14 T/T1/ST/H/IR To adjust the humidity set point turn the control knob H clockwise to increase and counter-clockwise to decrease the humidity sensor set point, adjustable from 60 % up to 90 %. 60 % 90 % For H/SH To adjust the fan turn-on delay time, turn the control knob clockwise to increase and counter-clockwise to decrease the turn-on delay time respectively, adjustable from For T1...
  • Page 15 Latches...
  • Page 16: Acceptance Certificate

    ACCEPTANCE CERTIFICATE WARRANTY CARD Sileo Design 100 The fan is recognized as serviceable. Approval mark Manufacturing date Sold by (name of the vendor, stamp of the shop) Date of sale www.blaubergventilatoren.de Sileo_Design_B01EN-01...
