2. G
eneral
2 . 1 Description
B
oilers of this type are composed of a cast-iron
exchanger, consisting in sections assembled by means of
nipples. Their heat transfer surfaces have been specially
designed to reach high efficiency. The exchanger is insulated
by a glass wool layer lined by lacquered steel casing panel,
itself insulated to reduce heat losses to a minimum.
These pressurized boilers must be fitted with jet-oil or blown-
gas burners, provided operating characteristics are compati-
ble with the combustion chamber size and pressure condi-
tions.
They heat premises, and, for Domestic Hot Water (D.H.W.)
production, can be coupled with a D.H.W. tank located next
to it.
2 . 2 Standard supplies
• Fire chamber cast-iron sections not assembled,
• Accessories: smoke box, optimizing baffles, flue ways
hinged door, opening chamber door with burner plate,
welding flanges for tubes Ø 76,
• Insulated casing and cleaning brush,
• Depending on the order, this boiler is fitted with a Stan-
dard or Ecocontrol,
• the "S" control panel includes :
- a water thermometer
- a 1st-stage control thermostat
- a 2nd stage control thermostat
- a limit thermostat
- a "power on" light
- a boiler warning light
- a burner on/off switch
- a press button to control limit thermostat and burner
- a 6.3 A fuse
- the general electrical wiring, with connection to the
operation and control devices.
• For supply of ECOCONTROL panel refer to the instructions
delivered with the latter.
2 . 3 Supplied on request
• Heating body delivered assembled,
• Two extra power economizers,
• Starter sleeve with finger button for remote control sensor
and ¾" ∅ tapped opening with plug (not assembled),
• Return sleeve with finger button for remote control sensor
and ¾" ∅ drainage valve (not assembled),
• Adjustable feet for levelling body,
• Control panel options,
Control panel options
Smoke thermometer
1A and 2A burner cables
Hour meters
Controllers: : according to
recommendations
• OIL or GAS burner, depending on matching prescriptions,
• Domestic Hot Water calorifer (PIM 250-350-500-800)
2 . 4 Shipping, Packaging
Packaging is as follows :
Package
Heating exchanger not assembled
Heating exchanger assembled
Optimizing baffles
Heating exchanger accessories
Control panel wired
Casing
Extra accessories
Tie-rods
exchanger not Nb of parcels
assembled Total weight kg
exchanger Nb of parcels
assembled Total weight kg
3
S ECOCONTROL
X X
X
X
Boiler
Boiler
assembled
not assembled
X
X
X X
X X
X
X
X X
X
X
34 35 36 37 38
7 7 7 7 7
612 730 849 963 1082
5 5 5 5 5
612 730 848 950 1068
Réf. : CI - 405 - A
39
7
1198
5
1184
