Dimensions
The FGR-70F and FGR-70F-3G4G share the same chassis dimensions. The FGR-70F and FGR-70F-3G4G share the same DIN bracket.
Edge Thickness,
Height
both sides,
80.5mm (3.17in)
Length
8.8mm (0.35in)
122.0mm (4.80in)
Length
76.6mm (3.02in)
Width
110.0mm
(4.33in)
Height
48.3mm
(1.90in)
Length w/ connector
140.5mm (5.53in)
For the FGR-70F-3G4G, the antenna dimensions are shown below.
The DIN plate thickeness is 2.4mm (0.09in).
NOTE:
Length
205mm (8.07in)
Width
25mm (.98in)
