2. Optional - Secure the earth ground terminal of the device to chassis
MAIN
ground or earth ground
MAIN
12-125V
GND
3. Insert the wired power connector into the terminal block on the device
DC1+
DC1-
The FGR-70F Series has optional dual DC inputs for failover
OPTIONAL:
redundancy. If a DC input fails, the second input will supply power.
18
GPS
DIV
COM1/COM2 1/2 3/4 WAN1/WAN2
– 3G/4G 1 – SIM – 2 – BYP GPS –
COM1/COM2
FortiGate Rugged 70F-3G4G
BLE
SFP1 SFP2
– 3G/4G 1 –
FortiGate Rugged 70F-3G4G
12-125V
DC1+ DC1+ DC1- DC1- DC2+ DC2+ DC2- DC2-
DC2-
DC2+
Refer to the
GPS
12-125V
3/4
1/2 WAN1/WAN2
SIM – 2 – BYP GPS –
BLE
SFP1
The FortiGate Rugged 70F provides an option in the BIOS menu to set the
CPU speed from high performance mode (default) to low power mode.
1. When prompted during bootup, press any key to enter the BIOS
2. Type F to set the CPU frequency, then follow the onscreen instructions
3. Press Q twice to exit and continue the bootup process
NOTE: See the admin guide on
Digital I/O Connector
– 3G/4G 1 – SIM – 2
Admin Guide for configuration settings.
FortiGate Rugged 70F-3G4G
DIV
Connector
Description
N1+ Alarm Input 1
REF Alarm Input 1/2 Reference Ground
N2+ Alarm Input 2
NC Normally Closed terminal
COM Common terminal
SFP2
NO Normally Open terminal
BIOS Options
