Atel ATELV810AD Quick Start Manual

Meet Your Device
ATELV810AD
4G LTE Fixed Wireless Access
Router
Models Covered:
Model V810AD
B2/4/5/12/13/14/66/71
LTE Bands
B2/4/5/12/13/14/66/71
Version 3.4
A quick look at your device:
3 4
1 2
1. LCD Display
Displays Home, Device Information,
Hotspot login information, and Online
Portal login information.
2. Power Button
Power the V810AD On/Off by
pressing and holding this button for
up to 10 seconds. Short press to wake
up the screen.
3. Battery port
Battery port used to connect to the
NiMH rechargeable battery pack
(may be sold separately).
4. Reset Button
Use a pin to push and hold this
button for 3 seconds for a factory
reset.
6 7
5
5. SIM Card Slot
Insert your 4FF SIM card into this
spring-loaded SIM slot. To
remove a SIM, press the edge of
the SIM inward and the SIM
would pop outward from the SIM
slot.
6. Type-C Port
Insert an ethernet cable to this port
and plug the other end into
your computer for internet
access.
7. Ethernet Port (RJ45)
Insert an ethernet cable to this port
and plug the other end into your
computer for internet access.
8. Antenna Connector
Install an optional antenna (may sold
separately) to increase signal
strength. You may have to pull off the
back rubber cover prior to installing.
8
