P5735SS | P5735WS
GB | Wireless Doorchime
Contents
Safety Instructions and Warnings ....................................................................................2
Technical Specifications ....................................................................................................3
Description ........................................................................................................................4
Installation and Assembly .................................................................................................6
Mobile App .........................................................................................................................8
Controls and Functions ...................................................................................................10
Troubleshooting FAQ ........................................................................................................13
GB | 1
zdroj: 3402128000_31-P5735SS_00_01_WEB_KNIHA
Advertisement
Related Manuals for Emos P5735SS
Summary of Contents for Emos P5735SS
-
Page 1: Table Of Contents
P5735SS | P5735WS GB | Wireless Doorchime Contents Safety Instructions and Warnings ..................2 Technical Specifications ....................3 Description ........................4 Installation and Assembly ....................6 Mobile App .........................8 Controls and Functions ....................10 Troubleshooting FAQ ......................13 GB | 1 zdroj: 3402128000_31-P5735SS_00_01_WEB_KNIHA... -
Page 2: Safety Instructions And Warnings
Children must always be supervised to ensure they do not play with the appliance. EMOS spol. s r.o. hereby declares that radio device type P5735SS and P5735WS complies with directive 2014/53/EU. -
Page 3: Technical Specifications
Pairing the chime with buttons: self-learning function Pairing capacity: maximum of 8 buttons per 1 chime, maximum of 2 buttons per 1 chime in the EMOS GoSmart app Number of ringtones: 52 38 mm 19 mm Transmission frequency: 433.92 MHz, 10 mW e.r.p. -
Page 4: Description
Description Chime Description 1 – bell LED 2 – speaker 3 – volume setting button 4 – ringtone setting button GB | 4... -
Page 5: Button Description
Button Description 1 – ring button 2 – button LED 3 – nameplate cover 4 – hole for opening the battery cover 5 – mounting pad GB | 5... -
Page 6: Installation And Assembly
Installation and Assembly Pairing the Button with the Chime 1. Plug the doorbell into a 230 V AC/50 Hz socket. 2. Then, long-press the pairing button on the chime for ca. 5 seconds. 3. The chime LED will light up; release the button. - Page 7 Installing the Chime (Receiver) 1. The chime is designed for indoor use only. When running, it must be plugged in a 230 V AC/50 Hz socket and with free space around it so that it is always accessible. 2. The transmission range (max. 150 m) is influenced by local conditions, such as the number of walls through which the signal passes, metal door frames and other elements which affect the transmission of radio signals (presence of other radio devices operating at a similar frequency, such as wireless thermometers, gate controls etc.).
-
Page 8: Mobile App
Mobile App The chime can be controlled using a mobile app for iOS or Android. Download the EMOS GoSmart app for your device. Tap the Log In button if you’ve used the app before. Otherwise, tap the Sign Up button and register. - Page 9 Tap Add Device in the app. Tap the GoSmart list on the left and tap the Doorchime silver P5735SS / Doorchime white P5735WS icon Follow the instructions in the app and enter the name and password for your 2.4 GHz Wi-Fi network.
-
Page 10: Volume Settings
Controls and Functions App Menu 1 – ring history 2 – button settings 3 – advanced settings 4 – pairing of the button with the app 5 – ring notification settings Button Settings 1 – save settings 2 – ordinal number of the button 3 –... -
Page 11: Ringtone Settings
Ringtone Settings You can set a different ringtone for each button paired with the app to better identify which button was pressed to ring the chime. Set the ringtone using the slider or the left/right arrow icon. Save the setting using the button at the bottom. Pairing the Button with the Chime in the App Tap the icon;... - Page 12 Advanced Settings • Device Information – basic information about the device • Tap-To-Run and Automation – scenes and automations assigned to the device • Create Group – creates a group of similar devices • Check Device Network – Wi-Fi network test •...
-
Page 13: Troubleshooting Faq
Troubleshooting FAQ The chime does not ring • The chime may be out of range. • Change the distance between the button and the chime; the range may be affected by local conditions. • The button’s battery may be low. •... - Page 14 GB | 14...
