  • Page 1 NSTRUCTIONS KP-32 K EYPANEL EKP-32 E XPANSION ANEL LCP-32 L EVEL ONTROL ANEL 9350-7656-000 Rev H, 8/2004...

  • Page 2: Proprietary Notice

    PROPRIETARY NOTICE The RTS product information and design disclosed herein were originated by and are the property of Telex Com- munications, Inc. telex reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.

  • Page 3: Return Shipping Instructions

    If a repair is necessary, contact the dealer where this unit was purchased. If repair through the dealer is not possible, obtain a RETURN AUTHORIZATION from: Customer Service Department Telex Communications, Inc. Telephone: (800) 392-3497 Fax: (800) 323-0498 Factory Service: (800) 553-5992 DO NOT RETURN ANY EQUIPMENT DIRECTLY TO THE FACTORY WITHOUT FIRST OBTAINING A RETURN AUTHORIZATION.
  • Page 4 End-User License Agreement for Telex® Software IMPORTANT - Please read this document carefully before using this product. THIS DOCUMENT STATES THE TERMS AND CONDITIONS UPON WHICH TELEX COMMUNICATIONS, INC. (the “COMPANY”) OFFERS TO LICENSE THE INSTALLED SOFTWARE OR PROGRAM (the “SOFT- WARE”) FOR USE WITH THE PRODUCT IN WHICH IT WAS INSTALLED.

  • Page 5: Table Of Contents

    EKP-32 Expansion Keypanel........
  • Page 6 Talk + auto table ............3-4 All Call Key .
  • Page 7 MENU SYSTEM, KEY ASSIGN MENU......... . . 6-3 General Procedure to use the Key Assign Menu .
  • Page 8 Approvals: ............7-2 Connectors (Other connector options available) .

  • Page 9: Introduction

    E C T I O N NTRODUCTION HAPTER Description KP-32 keypanel front view.. Figure 1.1 The RTS™ Model KP-32 Keypanel fits in a standard 19" rack and is two rack spaces high. It has 32 lever keys: 30 keys are for intercom talk/listen assignment; one key is for call waiting response;...

  • Page 10: Options

    • Only 90 mm deep behind the front panel (approximately 130 mm with connectors): Perfect for consoles, OB vans, etc. • Digital Signal Processing (DSP): Improves microphone voice activation and limiting. Adds new mixing, metering, and filtering capabilities. • Binaural (5-pin) Headset Connector: Works with the DSP mixing feature. Lets you independently assign intercom, microphone, and program audio to left or right headphone.

  • Page 11: Ekp-32 Expansion Keypanel

    EKP-32 Expansion Keypanel Figure 1.4 EKP-32 expansion keypanel front view. Provides and additional 32 intercom keys for a total of up to 64 keys (62 intercom keys total). LCP-32/16 Level Control Panels Figure 1.5 LCP-32/16 level control panel front view.
  • Page 12 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 13: Installation

    E C T I O N NSTALLATION HAPTER Option DIP Switch Settings Switch 1: Latch Enable/Disable Default setting = Open: Enable. Description: An intercom key can always be turned on for momentary conversation by pressing and holding the key during the conversation. There is also an electronic latching feature that lets you tap intercom keys to turn them on or off.

  • Page 14: Switch 4: Call Flash Timeout

    Switch 4: Call Flash Timeout Default setting = Open: 15 Second Flash. Description: Whenever there is an incoming call and there is a talk key assigned to the caller, the talk LED next to that key will flash. The flash can be set for 15 second timeout, or until the caller's talk key is released.

  • Page 15: Address Setting For Zeus

    Address Setting for Zeus Intercom port connectors on the Zeus back panel are arranged in three groups of eight intercom ports. For each group, intercom port connectors are labeled ID 1, ID 2, etc. When you connect a KP-32 keypanel to Zeus, set the Address switch to match the corresponding ID number on the Zeus back panel.

  • Page 16: Adam Cs With 50-Pin Telco Back Panel

    Figure 2.1 Address number vs intercom port numbers for 8-Port Audio I/O Cards (ADAM AND ADAM CS Intercom Systems. ADAM CS with 50-pin Telco back panel: Determine the address setting from Figure 2.1. To use the table, locate the intercom port number to which the KP-32 will be connected.

  • Page 17: Address Setting For Adam

    Each LCP-32/16 adjusts the listen levels for 16 keypanel keys, and you can connect as many LCP-32 panels as required to adjust all keys on the KP-32 and on an optional EKP-32 Expansion Panel. An interconnect cable is supplied with each LCP-32. Connect the first LCP-32 to the LCP connector on the KP-32.

  • Page 18: Power Supply Connector

    Figure 2.3 RJ12 Intercom Cable Wiring Power Supply Connector Align and insert the external power supply connector. Tighten the locking ring. Connect a power cord to the power supply and to an AC power source. The power supply accepts 100-240 VAC, 50/60 Hz.

  • Page 19: Panel Microphone Gain Adjustment

    Microphones. Insert the microphone and rotate the entire microphone body several turns to lock in place. Panel Microphone Gain Adjustment The gain of the panel microphone preamp can be adjusted via the recessed trim pot located on the back panel. Turn the pot clockwise to increase gain and counter-clockwise to decrease gain. The limits are ±20 dB from nominal.
  • Page 20 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 21: Basic Operation

    E C T I O N ASIC PERATION HAPTER Screen Saver Operation If the KP-32 is set for screen saver operation, the alphanumeric display automatically shuts off after several minutes of inactivity. The display reactivates on incoming call or when the keypanel operator actuates any control.

  • Page 22: Intercom Keys And Displays

    Intercom Keys and Displays Alphanumeric Display Indications for Intercom Keys Upper Case Letters: Upper case letters indicate keys that have any kind of talk assignment, with or without a corresponding listen assignment. Example: DIR1 Lower Case Letters: Lower case letters indicate keys that have only a listen assignment. Example: dir1 Dashes : Dashes indicate a key that has no talk or listen assignment.

  • Page 23: Flashing Green Talk Led & Display Alpha (On Time Equal To Off Time)

    at the remote location if your keypanel has the lower trunk IFB priority. IFB trunk priorities are set in ADAMedit. (Click the "KP" button on the ADAMedit toolbar to access Keypanels / Ports setup, then click the "Edit" button, then click the "Advanced" tab. Enter the desired IFB priority in the fields provided.

  • Page 24: Talk + Auto Reciprocal

    Talk + auto reciprocal Listen will always be on, and talk may be turned on or off. Talk + auto table If an IFB talk key has an auto-table listen assignment, talk and listen can be independently activated. The listen key listens to whatever is defined as the IFB Listen Source for the IFB that is assigned to the talk key.

  • Page 25: Muting The Microphone

    click the "Advanced" tab. Place a check next to "Port is TIF". Remember to send the change to the intercom system.) Muting the Microphone Tap the MUTE key to turn microphone muting on or off. The Vol. Sel. display alternates between (or between ) while the Hdst...
  • Page 26 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 27: Telephone Operation

    E C T I O N ELEPHONE PERATION HAPTER Telephone operations require an optional TIF-951 Telephone Interface. Also, you must first Note assign an intercom key to talk/listen to the TIF. We recommend a talk+auto listen assignment. Receiving A Phone Call When there is an incoming telephone call, the talk LED will flash red next to the KP-32 key that is assigned to the TIF.

  • Page 28: Kp9X Redial Sequence

    Dial the telephone number. Digits scroll in the display above the TIF key. When the far end answers, you can dial additional digits (to access a mail system or automated response system, etc.). When finished dialing, momentarily turn off the TIF talk key to end dialing mode (talk LED turns red).

  • Page 29: Dialing An Autodial Number Stored In The Tif-951

    Dialing an Autodial Number Stored in the TIF-951 Tap the PHONE key to activate dialing mode. Tap "down" on the TIF talk key to latch it in the on position. Tap CLR followed by the autodial number (01, 02, etc.). When finished dialing, click the PHONE key again to exit dialing mode.

  • Page 30: Autodial

    After the far end answers, you may dial additional digits (to retrieve voice mail, log onto an Note automated answering system, etc.). 5 If there is no answer, or to hang up when finished talking, tap PGM to hang up. Occasionally, you may receive intercom an intercom caller name in the Call waiting window Note while you are talking on the phone.

  • Page 31: Kp9X Series Keypad Programming

    E C T I O N KP9X S ERIES EYPAD ROGRAMMING HAPTER A summary of the keypad programming sequences is located at the back of the manual for quick Note reference. KEYPAD PROGRAMMING, DISPLAY REQUESTS Display requests let you view information about the keypanel configuration. You can display information by two methods: either by entering sequences on the programming keypad, or by scrolling the names of display requests in the Call waiting window and then selecting the desired display request.

  • Page 32: Display Setup Page Assignments

    Additional setup pages are assigned to any connected expansion panels, and are referred to as "Expansion 1", "Expansion 2", etc.). Since the KP-32 requires 2 setup pages, it uses the main page assignments and also one expansion page (Figure 5.1). The EKP-32 uses two additional expansion pages.

  • Page 33: Tone Generator Activation (Func-Display-7)

    =KP-32 bottom row keys. =KP-32 top row Epnl key. =EKP-32 bottom row keys. =EKP-32 top row keys. PGM: After selecting this item, tap up on any listen key with a point-to-point or party line Gain assignment. The current listen gain from this keypanel to the intercom port or party line displays in the Call waiting window.

  • Page 34: Keypad Programming, Assigning Intercom Keys

    • The same setup page cannot be assigned in more than one place. If a setup page is already Notes assigned somewhere else, you must clear or change that assignment first. With the exception of the main row assignment, you can clear any page assignment from a row of keys by entering E-PNL 0 PGM, then pressing any key in the row.

  • Page 35: Programming Key Assignments Using Copy

    3 Auto mute (listen keys only) 4 Auto reciprocal (listen keys only) 5 All call (talk level 1 only) 6 DIM (talk level 2 only, for point-to-point key, must enter 00 first) 7 Auto table (listen only, when talk level 1 is an IFB assignment) 4 Trunked intercoms only: (Skip when assigning auto functions or local key assignments.) Select an intercom matrix (tap 1 , or 2 etc.).

  • Page 36: Programming Key Assignments Using Alpha Scrolling

    If a key will not accept an assignment, the destination that you are trying to assign may not have Note scrolling enabled in ADAMedit. Or, the key that you are trying to assign may be restricted in ADAMedit. Programming Key Assignments Using Alpha Scrolling Alpha scrolling lets you scroll through a list of names of ports, party lines etc.

  • Page 37: Clearing A Key Assignment

    Tap down on an intercom key to assign talk, or tap up to assign listen. Clearing a Key Assignment There are two ways to clear a key assignment: Method 1: Clearing the Call waiting Window and Copying it to a Key Clear the Call waiting window, if necessary, by tapping up one or more times on the Call waiting key.
  • Page 38 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 39: Menu System

    E C T I O N KP-32 M YSTEM HAPTER A chart of the menu system is located at the back of the manual for quick reference. Note MENU SYSTEM, MENU ACCESS Clear all names from the Call waiting display (if not clear) by tapping "up" one or more times on the Call waiting key.

  • Page 40: Display Menu, Chans On

    • AC: All-call key. For descriptions of the various key assignment types, see the "GLOSSARY". Note Display Menu, Chans On Displays an alpha list, in the Call waiting window, of all intercom ports that currently have talk crosspoints closed to this keypanel. Chans On is typically used to locate an open mic or other open audio source that needs to be shut off.

  • Page 41: Menu System, Key Assign Menu

    MENU SYSTEM, KEY ASSIGN MENU Use this menu to assign intercom keys, to adjust listen levels for point-to-point keys and party line keys, and to assign setup pages. General Procedure to use the Key Assign Menu Clear the Call waiting window if necessary, by tapping upward one or more time on the Call waiting key.

  • Page 42: Key Assign Menu, Matrix

    8 When the requested list is displayed, press ↓↓ or −− , to locate the desired assignment. 9 Tap PGM or FWD to select the assignment. should now display in the Call waiting window. Press ↓↓ or −− if necessary to Talk Lvl 1 select a different option.

  • Page 43: Key Assign Menu, Party Line

    Key Assign Menu, Party Line Assigns a key that talks and/or listens to a party line. The key will have no effect until members have been assigned to the party line in ADAMedit. Note that party lines members are usually non- keypanel devices that cannot activate talk and listen paths.

  • Page 44: Key Assign Menu, Key Gain

    • Auto Mute (AM, for listen keys only) • Auto Recip (AR, for listen keys only) • All Call (AC, for talk level 1 only) • Dim ( Dim Table function, for talk level 2 on point-to-point keys only) Press FWD or PGM to select the desired auto function. displays.

  • Page 45: Key Assign Menu, Setup Page

    Key Assign Menu, Setup Page Use this menu item to change the setup page assignments on the KP-32 or EKP-32. One setup page is used for the top row of keys, and another setup page is used for the bottom row.

  • Page 46: Removing The Chime Option From A Key

    Tap any keys where you want to add a chime tone. Both LEDs will light red for the selected keys. Tap CLR to exit. Run Service Menu, Save Cfg, to store Chime settings. The chime option will continue on a key even if you change the key assignment. Note Removing the chime option from a key Repeat the procedure to add chime, but tap any keys where the LEDs are lit red to turn them off.

  • Page 47: Key Option Menu, Solo

    Key Option Menu, Solo A solo key will cause all other keys to turn off when activated. You can assign one solo key. Select then tap PGM. Solo displays. Tap Key Tap a key. Both LEDs for the key will light red to confirm the assignment. Tap the key again if you made a mistake and want to remove the assignment.

  • Page 48: Service Menu, Dim

    Auto Baud displays. To select the baud rate, press ↓↓. The choices are Auto Baud, 9600 Baud, or 76.8 Baud. Tap PGM to select the baud rate. Tap CLR to exit when finished. The new baud rate is now set. Run Service Menu, Save Cfg to store the Baud Rate setting.

  • Page 49: Service Menu, Dsp Func

    : Good when ambient light is bright. Bright : Recommended only for very bright ambient light, such as outdoors. Uses maximum Maximum power and decreases display life. : Overrides the normal screen saver timeout period and immediately places the Scr Saver keypanel in screen saver mode.

  • Page 50: Metering

    Microphone Matrix Aux 1 Aux 2 Tap PGM. displays. Gating Tap PGM. → displays. The arrow indicates that gating is now selected. Gating Tap CLR to exit. Run "Service Menu, Save Cfg", to save the change. Metering Metering lets you use the Vol. display as an LED bar graph meter to monitor an audio signal for about 1 minute.

  • Page 51: Service Menu, Hdst Sel

    Figure 6.1 For example, you may not want to use LCP-32s with the KP-32 but do want to use them with an EKP-32. In this case, you must turn off LCP usage for keys 1-32 as follows: Select , then tap PGM.

  • Page 52: Service Menu, Local Gpio

    Tap CLR to exit. Run "Service Menu, Save Cfg", to store the new LCP-32 settings. Service Menu, Local GPIO If your KP-32 has an optional Connector Module, you can use this menu item to assign the GPIO inputs and outputs. Inputs can be assigned to activate intercom keys (including group master keys and a solo key).

  • Page 53: Adding Or Removing A Gpi Output Key Assignment

    Press ↓↓ or −− if necessary to select Input Tap PGM. Press ↓↓ or −− .to display the GPI input that you want to remove. Tap PGM. Press ↓↓ to select Not Asgnd Tap PGM. → displays. The arrow indicates that "Not Assigned" is the new selection. Not Asgnd Tap CLR to exit.

  • Page 54: Service Menu, Min Volume

    ADAMedit, appear to be in the wrong positions on the keypanel or expansion panel. The KP-32 and EKP-32 use module ID numbers (Mod ID numbers) to define the address of each key and display module. See Figure 6.2. By default, Mod 1 is always assigned to the right half of the KP-32 and this never changes, since this module has the keypad and is unique.

  • Page 55: Service Menu, Output Level

    Figure 6.2 Mod ID assignments for the KP-32 and EKP-32. You do not need to run Save Cfg after changing Mod assignments. Note Service Menu, Output Level Allows the adjustment of the nominal audio output level to the matrix from 0 dB to +8 dB.

  • Page 56: Service Menu, Reset Cfg

    Service Menu, Reset Cfg Reset Cfg restores all custom settings to the defaults and erases all stored autodial numbers. Service Menu, Save Cfg PGM saves custom settings that you have made in the Key Option or Service menus. Save Cfg made in the After customizing settings in the Key Option and Service menus, run Save Cfg to store your custom settings in non-volatile memory.

  • Page 57: Kp9X Display Sequences

    PGM: Display setup page assignments. =KP-32 top row keys. =KP-32 bottom row key. Epnl =EKP-32 top row keys. =EKP-32 bottom row keys. PGM: Port / party line listen gain. Turn on listen key. ↓↓ or − − to change gain. Gain PGM: Reset all port / party line gains to 0dB.
  • Page 58 Tap PGM. Tap any key in top row to assign page to top row. Tap any key in bottom row to assign page to bottom row. KEY ASSIGNMENTS USING KEYPAD NUMERIC ENTRY For talk level 2 assignment only: Tap 0 Select the key assignment type: NUM Intercom port.
  • Page 59 KP9X Dial Sequence Activate the TIF listen key (listen LED green). Make sure the TIF talk key is off (Talk LED off). On the keypad, tap CLR-PHONE-PGM. Activate the TIF talk key (talk LED turns green). The "ON" LED at the TIF-951 will activate, and you should hear dial tone at the KP-32.
  • Page 60 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 61: Specifications

    E C T I O N PECIFICATIONS HAPTER Microphone Preamplifier Electret Mic Input Level @ 1 kHz: -42 dB, 150 ohms Dynamic Mic Input Level @ 1 kHz: -50 dBm, 150 ohms Output Level (to matrix): +8 dBu, ± 0.2 dBu Max Voltage Gain, Mic to Line: 70 dB, ±...

  • Page 62: Intercom Input/Output

    Speaker Rating: 4 watts max Intercom Input/Output Input: Nominal: +8 dBu. Peak: ± 20 dBu max. Output: +8 dBu, ± 2 dBu nominal External Line Input: (Program Input) Input Level +8 dBu nominal General AC Supply: External, switching type, 100-240 VAC, 50/60 Hz with locking DIN connector for attachment to the keypanel and universal IEC connector for connection to various AC mains cords Environmental: Storage:...

  • Page 63: Power Input Connector

    Pin 4: Headphone left high Pin 5: Headphone right high Power Input Connector Type: 5-pin locking DIN Pin-out: Pin1: Common Pin2: Common Pin3: +5VDC, 1.50A Max. Pin4: -15VDC, 0.150A Max. Pin5: +15VDC, 0.5A Max. Intercom Connectors: Parallel-wired DE9S and RJ12 Connectors Type: DE9S...

  • Page 64: Gpi Module Conntectors (Optional)

    GPI Module Conntectors (Optional) Aux 1 In (Auxiliary program input 1) Type: 3-pin female XLR Pin-out: Pin 1: Ground Pin 2: Input + Pin 3: Input - Aux 2 In (Auxiliary program input 2) Type: 3-pin female XLR Pin-out: Pin 1: Ground Pin 2: Input + Pin 3: Input - Balanced input, +8dBu nominal...

  • Page 65: Opto 1-4 In (Opto-Isolated Control Inputs)

    Pin 9: +5 VDC The relay 1 and 2 contacts are electrically separate, but operate in unison. The relay 3 and 4 Notes contacts are electrically separate, but operate in unison. The +5 VDC pins are connected internally through 1K resistors to +5 VDC and can source 5 mA. This voltage can be used with the relay contacts to create an active high output for some devices that require a +5 VDC signal to activate.

  • Page 66: Foot Switch/Speaker

    Pin 4: N/A leave unconnected Pin 5: Balanced dynamic mic input + Pin 6: Gnd Pin 7: Headset Listen Out Left Pin 8: Headset Listen Out Right Pin 9: Balanced dynamic mic input - Mic input -60 dBu nominal. Headset out 0.325 watts into 8 ohms. Note Foot Switch/Speaker Type:...

  • Page 67: Menu Access

    E C T I O N KP-32 M YSTEM UICK EFERENCE HAPTER MENU ACCESS Clear all names from the Call waiting display (if not clear) by tapping "up" one or more times on the Call waiting key. Tap MENU to activate the menu system. Press ↓↓...
  • Page 68 This Page Left Blank Intentionally K P - 3 2 U s e r M a n u a l...

  • Page 69: Mode 2 Operation

    E C T I O N PERATION HAPTER Section 2 Switch 4: Call Flash Timeout* When the switch is closed the menu and indefinite talking is disabled. Switch 5: Footswitch Enable / Disable* Amber talk LEDs indicate a latched talk key. Section 3 LED Indications for Intercom Keys Talk LED Indications...

  • Page 70: Solid Red Talk Led & Flashing Display Alternating Pattern Of Alpha & (-**-) ("Busy")

    Solid Red Talk LED & Flashing Display Alternating Pattern of Alpha & (-**-) ("Busy") You cannot talk at this time. This indication occurs when you activate a local IFB key that is already in-use by a keypanel with a higher IFB priority. It also occurs when you activate any key assigned to a remote destination, but there are currently no trunks available.

  • Page 71: Glossary

    E C T I O N LOSSARY HAPTER For talk key assignment only. Activating an All Call key will also activate all talk keys to the left All Call of the All Call key (up to, but not including another All Call key). Alphas are the user-changeable names which identify destinations (intercom ports, party lines, Alpha etc).
  • Page 72 The term "Crosspoint", like the term "Matrix" is inherited from intercom systems, such as the Crosspoint RTS CS9500, CS9600, and CS9700, that use a switching matrix to route intercom audio. In those systems, the crosspoints are the actual switches that close or open to connect or disconnect talk and listen paths.
  • Page 73 music can be interrupted while someone is talking over the PA.IFB's are set up by defining the IFB inputs and outputs using the intercom system configuration software. The intercom output port is called the IFB output and the program input port is called the IFB input. IFBs can also be given names which are meaningful to keypanel operators.
  • Page 74 button in ADAMedit, then press F1 on the computer keyboard if you need help.)Intercom Data Groups and Port Number CalculationFor data routing purposes, port numbers are arranged in groups of 8 sequential intercom ports. In an ADAM or ADAM CS Intercom System, each Audio I/O card comprises one data group.
  • Page 75 Talk level 1 is the normal talk key assignment. This is the assignment that normally appears in the Talk Level 1 alphanumeric display (on keypanels so equipped). You may add a talk level 2 assignment to activate a second device along with talk level 1. Talk level 2 is used with stacked talk keys.
  • Page 76 This Page Left Blank Intentionally 11-6 K P - 3 2 U s e r M a n u a l...
  • Page 77 RVON 1 RTS Voice Over Network Interface Card for the KP-32 and KP-812 Family of Keypanels ADDENDUM...
  • Page 78 RVON-1 User Manual...
  • Page 79 Return Shipping Instructions Procedure for Returns The RTS product information and design disclosed herein If a repair is necessary, contact the dealer where this unit was were originated by and are the property of Telex Commu- purchased. nications, Inc. Telex reserves all patent, proprietary...
  • Page 80 RVON-1 User Manual...
  • Page 81 Contents General Description of the RVON-1 Voice Over Network Card ............7 Features ..............................7 Specifications ............................8 Digital ..............................8 Connections ............................8 Dip Switches ............................8 Compatibility Requirements for the RVON-1 Card ................9 Flash Chip Replacement ........................9 Installation of the RVON-1 Card (cont.) ....................11 RVON-1 Relay ...........................11 Addresses and the RVON-1.......................11 Configure the RVON-1 from the KP-32 ....................12...
  • Page 82 This Page Intentionally left blank. RVON-1 User Manual...

  • Page 83: General Description Of The Rvon-1 Voice Over Network Card

    KP-32 or KP-812 keypanel, the RVON-1 brings a new level of enterprise-wide and remote access functionality to your RTS™ Matrix Intercom. The RVON-1 card is configurable through the keypanel service menu and Telex’s AZedit configuration software. It is also fully compatible with internationally recognized standards and supports the following protocols: G.711, G.729 AB, and G.723 (2 bit rates).

  • Page 84: Specifications

    Specifications Digital Compression Audio Bit Rate Coding Delay Playout Delay IP Bandwidth 125 µ s G.711 20-60ms 160-224 kbps G.729AB 10ms 20-120ms 32-112 kbps G.723 5.3k/6.3k 30ms 60-120ms 29-45 kbps * Data depends on CODEC selection Note: The Playout Delay and Bandwidth depend on the configured amount of audio per packet. Connections - RJ-45 Ethernet via backcard - 14-pin KP Compatible Expansion Connector...

  • Page 85: Flash Chip Replacement

    Firmware Compatibility Requirements for the RVON-1 Card l l o l l o Table 1. Compatibility Requirements for the RVON-1 Card Flash Chip Replacement The KP32, KP-32J , KP-632, and KP-832 must upgraded to 4MB flash chips that are programmed in the factory.
  • Page 86 Power HEADSET PANEL Closed MIC GAIN Address TELEX COMMUNICATIONS, INC. Frame Exp. MADE IN U.S.A. Figure 2. Knock out positions for the RVON-1 card on the KP-32. Holds the spacer to the backplate of the Holds the spacer to the RVON-1 card Figure 3.

  • Page 87: Installation Of The Rvon-1 Card (Cont.)

    Installation of the RVON-1 Card (cont.) In the KP-32 keypanel, the RVON-1 card connects to the KP-32 by way of the J2 connector on the RVON-1 attached to J4 on the KP-32 header. Gently secure the board in place. See Figure 4. Figure 5.
  • Page 88 Configure the RVON-1 from the KP-32 To use the RVON-1 with the KP-32, the KP-32 firmware must be at V 2.0.0 or higher. In turn, the firmware requires that larger flash chips be used as well. For more information, see page 9. TOP LEVEL MENU, SERVICE, RVON SETUP Set the IP Address from the Service Level Menu The RVON-1 card, when shipped has a default IP Address already configured.
  • Page 89 NOTE: Once you have entered the Netmask, you may need to enter the Gateway IP Address. A Gateway is a node (for example, a computer) on a network that serves as an entrance to another network. Press PGM. The actual Gateway IP Address appears. Enter the first number in the Gateway IP Address.
  • Page 90 Configure the RVON-1 from the KP-812 TOP LEVEL MENU, SERVICE, RVON SETUP Set the IP Address from the Service Level Menu The RVON-1 card, when shipped has a default IP Address already configured. This must be changed in order for the RVON-1 card to function properly because the pre-configured IP Address may not work with your network.
  • Page 91 NOTE: Once you have entered the Netmask, you may need to enter the Gateway IP Address. A Gateway is a node (for example, a computer) on a network that serves as an entrance to another network. Tap the encoder knob. The actual Gateway IP Address appears.

  • Page 92: Configure The Rvon-8 Using Azedit To Contact The Rvon-1

    Configure the RVON-8 using AZedit to contact the RVON-1 To configure the RVON-1 card, do the following: From the Status menu, select I/O Cards. The I/O Card Status screen appears showing the types of installed cards . Right click on an RVON-8 card and select RVON-8 Configuration. The RVON-8 Configuration screen appears .

  • Page 93: Download Rvon-1 Firmware Through Azedit

    From the Device Channel drop down list, select Channel 1. There may be two channels listed, but the connection can only be made through channel 1. From the CODEC Type drop down list, select the CODEC type. From the Packet Size drop down list, select the size of each audio packet. NOTE: A CODEC is an algorithm used to compress audio.
  • Page 94 Using the Browse feature, browse to the file to be downloaded. Click Open. The Download Device Firmware screen appears. Click Begin Download. The download begins. Click OK. The RVON-1 firmware download is complete. This takes a minute or two to occur. WARNING! - Do NOT power down the keypanel until you have verified the new version information from AZedit.
  • Page 95 Appendix A Basic Network Configuration This section covers basic network configuration set up and testing. Also covered are basic concepts and operations, including the difference between LAN and WAN networks and how IP Addressing is used. In a networked environment, such as a company, typically there are many computers connected together using a router or a switch (for more information router or switch in the definitions section).
  • Page 96 A wide area network connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several branch offices in Nebraska and Arkansas over the wide area network. The largest WAN in existence is the Internet.
  • Page 97 IP address for the URL you are requesting (http:// www.telex.com). To obtain this address, the computer contact a DNS server (Domain Name Server). Once the IP address is found, it tries to connect to the http port of the network device (port 80). See Table 1 for a list of the more well-known port numbers.
  • Page 98 i t l i l p l i a l a i e l i e l i l i a l l e - t f e i l Table 3. Well-Known TCP Port Numbers RVON-1 User Manual...
  • Page 99 IP Addresses ® If you do not know your IP Address, you can open a DOS screen in Windows - based environment and bring up the ipconfig screen. To find your IP Address using ipconfig, do the following: From the Start Menu, open a Command Prompt window. At the prompt, type ipconfig, then press Enter.
  • Page 100 Ping a Computer Pinging a computer on the network makes sure it is able to be “seen” and receive messages on the network. Note: You can also ping your RVON-8 card to verify that it is responding over the network by putting the cards IP address in place of the computer IP address.
  • Page 101 Possible Pitfall with Routers, Gateways, and Switches Anytime computers communicate through routers, gateways, and switches, they may be allowed or denied the connection. Network interface devices can be configured to block specific outgoing requests, as well as incoming requests, based on the IP address and/or port. This is one of the security mechanisms of a router. This also happens when broadcast messages are sent and received.
  • Page 102 RVON-1 Specific Configuration RVON-1 cards use ports for communication of audio and control packets. Because routers can be configured to block certain incoming and outgoing requests, you will need to open the following ports in your network to allow WAN connections to and from a Network Interface Device. See Table 4 for the ports that need to be opened for the RVON-1 card to operate properly.
  • Page 103 - A DNS Server is an Internet service that translates domain names (for example, in the URL http://www.telex.com, the domain name is telex.com) into IP Addresses. The Internet is based on IP Addresses which are numeric and since domain names are alphabetic, they are easier to remember.
  • Page 104 A wide area network connects two or more LANs and can span a relatively large geographi- cal area. For example, Telex Headquarters in Burnsville, MN is connected to several of its branch offices in Nebraska and Arkansas over the wide area network. The largest WAN in existence is the Internet.
  • Page 105 Appendix B Telnet & Serial Port Programming of the RVON-1 Card RVON Serial and Telnet Commands RVON-1 card programming can also be done via a direct serial or Telnet connection. There are two physical connections to an RVON-1 board: • Direct serial through a custom debug cable (J3 6-pin bottom front) The custom debug cable always functions as the general-purpose debug tool.
  • Page 106 3. Press Enter. The RVON login screen appears. In the logon field, type the RVON login (default = Telex). Press Enter. In the password field, type the RVON password (default = password). Press Enter. A prompt appears. Type dbgcmd to access the debug command screens.
  • Page 107 At the command prompt type: set rvon ip_address 10.3.210.12 2. Set the destination channel type to RVON-1. At the command prompt type: set chan dest_type 0 3. Set the RVON user to Telex At the command prompt type: set rvon user Telex RVON-1 User Manual...
  • Page 108 e l i t t i Codec: Determines how the audio is compressed/decompressed and the name given to the defined algorithm. Codec Rate: Actual bits per second of the audio in compressed form. This is sent over the network through various data packets.
  • Page 109 All are “set channel #” commands because they are for each audio channel. c i t / I - e l i Typing, “sys_printenv” from the “MXP” Debug system prompt shows these settings. RVON-1 User Manual...
  • Page 110 Jumpers and Connections A selectable RS232/485 serial port is at connector J1. Jumper connections on J10, J11, and J12 select the signal mode on J1. • When J10, J11, and J12 are jumped from pins 1 to 2 - J1 is configured for RS485. •...
