Page 1: User Guide
PAM-32 User Guide Up to and including firmware version 1.1.1 9350-7791-000 Rev E 06/2006... - Page 2 ROPRIETARY OTICE The product information and design disclosed herein were origi- nated by and are the property of Telex Communications, Inc. Telex reserves all patent, proprietary design, manufacturing, reproduc- tion, use and sales rights thereto, and to any article dislcosed therein, except to the extent rights are expressly granted to others.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 Introduction ...3 PAM-32 Production Audio Monitor General Description ...3 Features ...3 Connections ...4 Keypanel Connections ...4 Specifications ...5 General ...5 Connectors (other connector options available) CHAPTER 2 Installation ...7 Option DIP Switch Settings ...7 Power Up ...8... -
Page 5: Chapter 1 Chapter
General Description The RTS™ Model PAM-32 keypanel fits in a standard 19” rack and is two rack spaces high. It has 32 push button keys; 30 of which are monitoring inputs; one key for copying from alpha scroll lists; and one is for headset/speaker. It adds significant new features such as digital signal processing and binaural headset operation with left/right assignment of audio signals. -
Page 6: Connections
*When connecting to an ADAM CS backpanel, use only low-profile cable connectors such as AMP Part No. 747516-3 (Telex Part No. 59926-678) 9-pin intercom cable wiring diagram and RJ-12 intercom wiring diagram (PAM-32) FIGURE 1. Headphone Connector Specification: Connector Type: 3-conductor, 1/4 inch plug... -
Page 7: Specifications
Specifications Specifications The PAM-32 is a 32-key (push button) monitor panel, with both headset and speaker outputs. General AC Supply: External, switching type, 100-240 VAC, 50/60 Hz with locking DIN connector for attachment to the keypanel and Environmental Storage -40°C to 60°C (-40°F to 140°F) Operating -10°C to 41°C (14°F to 105.8°F) - Page 8 Introduction Power Input Connector Type: Pin Out Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Intercom Connectors: Parallel-wired DE9S and RJ-12 Connectors Type Pin Out Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 Pin 9 Type...
-
Page 9: Chapter 2 Installation
In this mode, the panel replies to the intercom at two separate polling IDS. For example, if the polling ID is set to6, in split mode, the PAM-32 will respond at IDs6 and 7. Keys on the two sides of the panel operate independently. With this mode, the audio for the second intercom port could see the AUX IN of the keypanel, and the audio for the two ports could be routed separately to the left and right headset channels. -
Page 10: Power Up
In Zeus, ADAM CS, and ADAM Intercom Systems, intercom ports are arranged in groups of eight. All ports in a group share a common data port. Each PAM-32 keypanel is uniquely identified on the data port by the setting of it Address switch. The Listen Key ON - Solid Green LED Listen Key Locked ON (in “one”... -
Page 11: Address Setting For Zeus
Intercom port connectors on the Zeus back panel are arranged in three groups of eight intercom ports. For each group, intercom port connectors are labeled ID1, ID2, etc. When you connect a PAM-32 keypanel to Zeus, set the Address switch to match the corresponding ID number on the Zeus backpanel. - Page 12 Installation...
-
Page 15: Chapter 3 Basic Operation
Screen Saver Operation If the PAM-32 is set for screen saver operation, the alpha numeric display automatically shuts off after a user defined period of inactivity. The display reactivates on incoming call or when the keypanel operator actuates any control. DIP switch 3 enables and disables the screen saver operation. -
Page 16: Intercom Keys And Displays
Basic Operation Intercom Keys and Displays Alphanumeric Display Indications for Intercom Keys Upper Case Letters: Upper case letters indicate keys that have an assignment. Dashes ----: Dashes indicate a key that has no talk or listen assignment. Flashing Alphanumeric Display: This means the key is activated to listen to an IFB, ISO or TIF. NOTE: The flashing alphanumeric display for TIF keys, remote IFB keys, and remote ISO keys can be disabled by placing a check mark next to “Don’t generate tallies for TIF and trunk use”... -
Page 17: Pam-32 Menu System
In this case, use the ⎠⎠ and −− keys to scroll through the list of names. You can than press the Call waiting key to ask the person at the other end to turn off their talk key. PAM-32 Menu System SL ... Special List GPI Out... -
Page 18: Display Menu, Matrix
Display Menu, Version Displays the firmware version of the keypanel. NOTE: For firmware upgrades, contact our intercom system dealer. The PAM-32 firmware can be upgraded from AZedit. Menu System, Key Assign Menu Use this menu to assign intercom keys, to adjust listen levels for point-to-point keys and party line keys, and to assign setup pages. -
Page 19: Key Assign Menu, Matrix
NOTE: You do not need to Save Cfg after resetting key gains. These settings are stored in the intercom setting. Key Assign Menu, Setup Page Use this menu item to change the setup page assignments on the PAM-32. One setup page is used for the top row of keys, an another setup page is used for the bottom row. -
Page 20: Service Menu
Tap CLR to exit when finished. The new dimming level is now set. Run Service Menu, Save Cfg. to store the DIM setting Service Menu, Baud Rate This item sets the baud rate for the PAM-32. Select Baud, then tap PGM. Auto Baud displays. -
Page 21: Service Menu, Dsp Func
Service Menu Press ⎠⎠ to select any of the following: Auto Baud: Senses what the Matrix is running, and sets the PAM accordingly. 9600 Baud 76.8 K Baud NOTE: Run Service Menu, Save Cfg to store the settings. Service Menu, DSP Func This item increases the digital signal processing features. -
Page 22: Service Menu, Lcp-32
KP12 OKP4 ANDY KP32 DAN KP96 TIF1 KP12 LCP-32 Keys 1-16 For example, you may not want to use LCP’s with the PAM-32 but do not want to use them with an EKP-32. In this case, you must turn off LCP usage for keys 1-32 as follows: Select LCP-32, then tap PGM. -
Page 23: Service Menu, Mod Assign
The PAM-32 and the EKP-32 use module ID numbers (Mod ID numbers) to define the address of each key and display module. By default, Mod 1 is always assigned to the right half of the PAM-32 and this never changes, since this module has the keypad and is unique. -
Page 24: Service Menu, Reset Cfg
Service Menu, RVON Setup NOTE: To use the RVON-1 with the PAM-32, the PAM must be at firmware version 1.0.0 or higher. The RVON-1 card, when shipped has a default IP Address already configured. This must be changed in order for the RVON-1 card to function properly because the pre-configured IP Address may not work with your network. -
Page 25: Service Menu, Save Cfg
A screen saver is an animated image that is activated on a display when no user activity has been detected for a certain time. To set the screen saver delay time, do the following: On the PAM-32, press Menu. Display appears in the keypanel display. -
Page 26: Service Menu, Test Panel
PAM-32 Menu System 8 hr 10 hr 12 hr Service Menu, Test Panel Test Panel PGM lets you check the operation of all keys and displays. All alphanumeric displays show a% symbol. Pressing down on any key (except the Headset/Vol Sel. key) will cause OK to display.
