Summary of Contents for McLelland XA2-200SB
- Page 1 SUBWOOFER XA2-200SB AMPLIFIER OWNERS MANUAL...
-
Page 3: Specification
Its tabletop design is compatible with many other popular electronic devices or McLELLAND XA2-250BT amplifier to have 2.1 channel sound systems. The XA2-200SB offers its owner the freedom to use a stand-alone, high quality amplifier to operate a subwoofer speaker. -
Page 4: Rear Panel
The front panel switch will Adjusts the low-pass frequency 1. POWER SWITCH: 3. CROSSOVER: manually turn the power on or off. from 35 Hz to 160 Hz. When using the POWER LED Left/Right inputs, GREEN: The amplifier is turn on. the adjustment will allow you to properly RED: The amplifier is in Standby mode. -
Page 5: Connection Diagram
CONNECTION DIAGRAM Subwoofer TRIGGER IN XA2-250BT... - Page 6 CONNECTION DIAGRAM TRIGGER IN PRO500D...
