Air Hydraulic Pumps
Instruction Manual
MODELS: PA1500, PA1500A, PA2000 & PA3801
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
*
Fax: 816-448-2142
E-mail: sales@bvahydraulics.com
Website: www.bvahydraulics.com
Maximum Operating Pressure 10,000 PSI
PA1500, PA1500A
PA3801
Date: 2021.02.25
File name: A5706_2102OUT
PA2000
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BVA Hydraulics A1500
Summary of Contents for BVA Hydraulics A1500
- Page 1 PA1500-M0_082021 Air Hydraulic Pumps Instruction Manual MODELS: PA1500, PA1500A, PA2000 & PA3801 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Maximum Operating Pressure 10,000 PSI PA1500, PA1500A PA3801 wn By: Frank Date: 2021.02.25 File name: A5706_2102OUT PA2000...
-
Page 2: Safety And General Information
SAFETY AND GENERAL INFORMATION PRODUCT DESCRIPTION Save these instructions. For your safety, read and BVA Hydraulics Air Hydraulic Pumps are engineered to meet understand the information contained within. The owner most Industrial Standards for Performance and Safety. Its and operator shall have an understanding of this product... - Page 3 WARNING • Study, understand, and follow all • Use only approved accessories and approved hydraulic instructions provided with and on this fluid. device before use. • Never attach ANY component not authorized by • No alteration shall be made to this device. manufacturer.
-
Page 4: Specifications
SPECIFICATIONS Output Flow Rate Usable Oil Rated Input Air Output Port Input Port Model Weight (lbs /min) Capacity Pressure Pressure Thread Threads Number w/fluid) (psi) (psi) (Oil) (Air) No Load Load PA1500 91.5 18.1 PA1500A 91.5 18.7 10,000 110 - 175 3/8”... -
Page 5: Maintenance
MAINTENANCE 3. Wipe up any spilled fluid and reinstall the air vent screw. Changing Hydraulic Fluid NOTICE: Use only good quality hydraulic fluid. Never use 1. For best results, change fluid once a year or every 300 brake fluid, transmission fluid, turbine oil, motor oil, alcohol, hours of use. - Page 6 Air Hydraulic Pump Service Parts MODELS: PA1500, PA1500A SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 7 Air Hydraulic Pump Service Parts MODELS: PA1500, PA1500A SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 8 Air Hydraulic Pump Service Parts MODEL: A57-3-1001-105 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 9 Air Hydraulic Pump Service Parts MODEL: A57-3-1032-106 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 10 Air Hydraulic Pump Service Parts MODEL: PA2000 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 11 Air Hydraulic Pump Service Parts MODEL: PA2000 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 12 Air Hydraulic Pump Service Parts MODEL: A58-3-1001-102 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 13 Air Hydraulic Pump Service Parts MODEL: PA3801 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 14 Air Hydraulic Pump Service Parts MODEL: PA3801 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 15 Air Hydraulic Pump Service Parts MODEL: A57-3-0011-103 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 16 • Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components.
