BVA Hydraulics ZP601S Instruction Manual

Hand pump
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
ZP601S-M0_112014
Hand Pump
Instruction Manual
MODEL: ZP601S
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
*
Fax: 816-891-6599
E-mail: sales@bvahydraulics.com
Website: www.bvahydraulics.com
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Maximum Operating Pressure 10,000 PSI
Model ZP601S
Printed in Taiwan

Advertisement

Table of Contents
loading

Related Manuals for BVA Hydraulics ZP601S

Summary of Contents for BVA Hydraulics ZP601S

  • Page 1 ZP601S-M0_112014 Hand Pump Instruction Manual MODEL: ZP601S SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-891-6599 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 2: Safety And General Information

    WARNING: Model ZP601S is operated with a non-vented reservoir. If the reservoir is subjected to high pressure, the cas- ing may rupture. Never attempt to return more oil to the reservoir than it is capable of holding.

  • Page 3: Specifications

    Capacity Holes Dis- (lbs) (lbs) (in) tance (in) Stage Stage Stage Stage Single- ZP601S 36.61 0.15 99.8 0.75 3.74 16.1 speed WARNING • Study, understand, and follow all • Do not subject the pump and its components to shock loads.

  • Page 4: Before Use

    2. Verify that the product and the application are compatible. Inspect before each use. Do not use if bent, broken, leaking or damaged components are noted. 3. Replace worn or damaged parts and assemblies with BVA Hydraulics Authorized Replacement Parts only (See Replacement Parts Section). Lubricate as instructed in Maintenance Section.

  • Page 5: Maintenance

    For best results, change fluid once a year. 1. Inspect hoses and connections daily. Replace damaged 1. With pump in its upright, horizontal position, remove oil filler components immediately with BVA Hydraulics Replacement plug/screw located on top of the reservoir, then pour used Parts only.
  • Page 6 Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. Parts Illustration Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized Replacement Parts only.
  • Page 7 Parts List Model ZP601S Item Part Number Description H18-6-2112-105 Handle Grip H54-6-2139-109 Handle H54-6-2138-107 H54-6-2137-105 H54-6-2136-103 Handle Socket 605-3-0080-102 Spring Washer 661-2-0080-014 430-6-1601-209 Piston 428-6-1104-203 Screw adjustment 513-3-0270-010 Washer 428-6-1103-100 Upper seal base V-oil seal V-oil seal V-oil seal 428-6-1102-209...

  • Page 8: Limited Lifetime Warranty

    • Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components.
