MODELS: PG70M3N05 & PG70M4N05
SFA Companies
E-mail: sales@bvahydraulics.com
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Maximum Operating Pressure 10,000 PSI
Model PG70M3N05 & PG70M4N05 (Honda Engine)
The engine exhaust from this product contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive harm.
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
*
WARNING
!
Gas Engine Pumps
Instruction Manual
Fax: 816-448-2142
Website: www.bvahydraulics.com
PG70M3N05-M0_102018
Printed in Taiwan
Advertisement
Table of Contents
Related Manuals for BVA Hydraulics PG70M3N05
Summary of Contents for BVA Hydraulics PG70M3N05
- Page 1 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Maximum Operating Pressure 10,000 PSI Model PG70M3N05 & PG70M4N05 (Honda Engine) WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
-
Page 2: Safety And General Information
PRODUCT DESCRIPTION BVA Hydraulics Gas Engine Pump is engineered to meet most industrial standards for Performance and Safety. These pumps provide hydraulic power when electricity and air power are not available. These pumps supply compressed hydraulic fluid to compatible applications i.e. -
Page 3: Specifications
Number (lb) (gal) (hp) Threads 1st Stg 2nd Stg 1st Stg 2nd Stg Manual, 3-way, PG70M3N05 3-position 3/8"- 10,000 Honda 18NPT Manual, 4-way, PG70M4N05 3-position BEFORE USE 1. Visually inspect all components for shipping damage. Do not use if any damaged parts are found. - Page 4 WARNING • Read, understand, and follow all • Do not operate this device in an extreme temperature, instructions provided with and on this explosive atmosphere or in the presence of conductive device before use. liquids. • All WARNING statements must be •...
-
Page 5: Operation
WARNING: ALWAYS monitor pressure, load or position using suitable equipment. Pressure may be monitored by means of an optional manifold and gauge (contact BVA Hydraulics). Load may be monitored by means of a load cell and digital indicator. Correct application position can only be determined by the operator of the equipment. - Page 6 Gas Engine Pump Service Parts MODEL: PG70M3N05 & PG70M4N05 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 7 Gas Engine Pump Service Parts MODEL: PG70M4N05 (Honda Engine) SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Model No. E5595 Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 8 PG70 Engine Pump Body Service Parts MODEL: PG70M3N05 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of Model No.
- Page 9 Gas Engine Pump Service Parts MODEL: E55-4-3011-106 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 Model No. E55-4-3011-106 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 10 Gas Engine Pump Service Parts Model No. E15-4-4000-104 MODEL: E15-4-4000-104 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 11 Gas Engine Pump Service Parts MODEL: E05-4-6030-105 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Model No. E05-4-6030-105 Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
- Page 12 Gas Engine Pump Service Parts MODEL: E05-4-8000-106 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Model No. E05-4-8000-106 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence.
-
Page 13: Troubleshooting Guide
TROUBLESHOOTING GUIDE The following information is intended as an aid in determining if problem exists. Pumps should be repaired only by authorized BVA Service Center. For repair service, contact service center in your area. Symptom Possible Causes Corrective Action • Overload condition •... -
Page 14: Limited Lifetime Warranty
Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components. - Page 15 Note Page Contact: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816) 448-2142 E-Mail:sales@bvahydraulics.com BVA Website: http://www.bvahydraulics.com...
- Page 16 Note Page Contact: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816) 448-2142 E-Mail:sales@bvahydraulics.com BVA Website: http://www.bvahydraulics.com...
