- Page 1 Instructions for use. maxi. The confident therapy chair.
-
Page 2: Many Thanks
User Manual may differ from your product due to its specific configuration. We reserve the right to make technical modifications. Important information! Ensure that this User Manual remains with the product. Your Schuchmann - Team... -
Page 3: Table Of Contents
Contents. 1. Preparation................. 05 1.1 Delivery ..........................05 1.2 Safety measures prior to use ................05 1.3 Safe disposal .......................05 1.3.1 Packaging ......................05 1.3.2 Product ........................05 1.4 Where to store the User Manual ...............06 2. Product description..............06 2.1 Material information ....................06 2.2 Handling / transport ....................06 2.3 Application areas, intended purpose ............06 2.3.1 Indications ......................06... - Page 4 Contents. 4.7 Plug-in foot support ....................18 4.8 Wooden therapy table ..................19 4.9 Knee abduction wedge ..................19 4.10 Armrests including therapy table insert ............19 4.11 Fold-down armrests including therapy table insert ....... 19 4.12 Harness ........................20 4.12.1 Strap assembly kits for the seat and back area ......20 5.
-
Page 5: Preparation
1. Preparation. 1.1 Delivery Please check the product upon receipt for completeness, defects and any potential transport damage. Inspect the goods in the presence of your forwarder. If transport damage is detected, please ensure that a report (record of defects) is prepared in the presence of the forwarder. Please send a complaint in writing to the specialist dealer responsible. -
Page 6: Where To Store The User Manual
(fold up foot support, set lowest seat height etc.). 2.3 Application areas, intended purpose The maxi. Therapy chair is a medical device in risk class 1 and is designed for use at home and at school. It can be used for all age groups. Individu- ally adjustable seat dimensions and supporting pelotte pads allow a sta- ble and upright sitting position. -
Page 7: Contraindications
• Only use accessories and replacement parts from Schuchmann to avoid compromising user safety. • Only use the therapy chair if all components have been correctly mounted and adjusted. -
Page 8: Usage And Safety Guidelines
2. Product description. 2.4.1 Usage and safety guidelines • Only individuals with adequate experience and knowledge of motor components should operate these parts. • Individuals with physical or mental impairments may only use motor components under supervision or after receiving thorough instructions from a responsible person. -
Page 9: Safety Instructions For The Battery
2. Product description. • Fastening screws and bolts must be properly tightened. • The specifications on the label must not be exceeded under any cir- cumstances. • Unauthorized persons must not open the motor. • Use the drive only within the specified load range. •... -
Page 10: Equipment For Basic Model
2. Product description. • Only use the supplied charger to charge the battery. • Recharge the battery before storage if it is fully discharged. • The battery is not designed for use outdoors, in swimming pools, or other harsh environments. •... -
Page 11: List Of Accessories
2. Product description. 2.6 List of accessories • Standard headrest - padded, adjustable in height and angle • Headrest with lateral guide - padded, adjustable in height and angle • Headrest in shell shape - padded, adjustable in height and angle •... -
Page 12: Product Overview
Only have the user get in and out of the product on stable and flat ground! 2.9 Transfer The maxi. can also be moved carefully and slowly during use (e.g. to other rooms) thanks to the castors. -
Page 13: Settings
3. Settings. Settings and adjustments to the product or accessories may only be made by people who have been given the necessary instructions by a medical product advisor. Ensure that no extremities of the user or caregiver are in the adjustable area during any adjustments to minimize the risk of injury. All adjustments can be made with standard tools (e.g. -
Page 14: Seat Height
3. Settings. 3.1.2 Seat height The seat surface height is adjusted via the man- ual control unit. If the hand control unit is locked, unlock it by pressing the release key (see Point 3.1.1). The height of the seat is adjusted by press- ing the buttons (A) in row 1. -
Page 15: Charging Process
3. Settings. 3.2 Charging process On the back of the maxi. on the seat, the is a magnetic charging socket (A). By plug- ging in the counterpart (B), the maxi. starts to charge up. The charging socket flashes green during the charging process. It lights up solid green once the charging process has completed. -
Page 16: Accessories
4. Accessories. 4.1 Headrest All headrests can be removed as standard. The headrest (A) can be adjusted in height and angle. To adjust the angle, loosen the screw (B) and set the required angle of the support. Then retighten the screw (B). By loosening the twist grip (C), the headrest height can be adjusted. -
Page 17: Adjustable Pelvic Guide
4.3 Adjustable pelvic guide To adjust the pelvic guide (A) please loosen the two Allen screws (B) on the back of the maxi. The pelvic guide can also be adjusted in angle by loosening the screws (C). After each adjustment, please retighten all screw connections! 4.4 Thigh guide... -
Page 18: Central Locking Brake Of The Rear Castors
A safety switch is installed in case of a collision between the foot support and floor. If this is triggered, the maxi. automatically moves up in the oppo- site direction for two seconds. After each adjustment, please retighten the screw connections! 4.6.1 Calf attachment for foot support... -
Page 19: Wooden Therapy Table
4. Accessories. 4.8 Wooden therapy table The therapy table (A) can easily be fitted to the therapy chair. To do this, simply guide first the long tube (B) and then the short tube (C) into the holder under the armrests. Fold- ing down is not possible. -
Page 20: Harness
4. Accessories. 4.12 Harness There is a range of straps available for maxi., which allow even better posi- tioning of the user. The harness should be mounted using the strap assembly kits for the seat or back area. You have the choice between a... -
Page 21: Cleaning And Maintaining
Please also pay attention to our general cleaning and Velcro séparément dans un sac de lavage hygiene advice. This can be found at www.schuchmann. de/mediathek. 5.1.2 Disinfection Various products can be used for surface disinfection of metal and plastic parts. -
Page 22: Maintenance Plan
5. Cleaning and maintaining. • Damages to the frame, mounting parts and accessories (cracks, breaks, corrosion, bent or missing parts) • Strength of the connections (tighten loose screws, replace missing screws) • Functionality of the adjustment elements (screws, release lever, foot pedal) •... -
Page 23: Spare Parts
5. Cleaning and maintaining. 5.4 Spare parts Use only original accessories and original spare parts from Schuchmann, as otherwise the safety of the user is endangered and the warranty ex- pires. Should you wish to order spare parts, please contact the specialist dealer who supplied you with the product, stating the serial number of the prod- uct (see Point 8.4). -
Page 24: Technical Data
6. Technical data. 6.1 Dimensions Dimensions Size 1 Size 2 Size 3 Seat depth 30 – 42 cm 38 – 48 cm 45 – 55 cm Seat width 28 – 38 cm 36 – 48 cm Height short back 42 – 54 cm Height long back 53 –... -
Page 25: Electrical Components (For Electrical Height Adjustment)
6. Technical data. 6.2 Electrical components (for electrical height adjustment) Component designation Lithium-ion battery Control Linear drive Hand control unit Charger General ambient conditions Application temperature +0° C to 40° C -10°C to +50°C (+10 °C to +25 °C recommended). Battery modules must be Storage temperature stored in a suitable storage room, protected from direct sunlight. -
Page 26: Guarantee
6. Technical data. Control Maximum power is 120 W for a maximum of 2 minutes Drive Input voltage 12/24 V Protection class IP66 Hand control unit Protection class IP20 or IPX6 External charger Input voltage 100 - 240V AC Output voltage 29V DC 3.75A Temperature range 5 - 45°C... -
Page 27: Identification
• info@schuchmann.de • Fon +49 (0) 5402 / 40 71 00 Product labelling in accordance with MDR 8.2 Product version The maxi. therapy chair is available in three sizes and can be supplement- ed through a diverse range of accessories (see Point 4). 8.3 Issue of the document maxi. - Page 28 schuchmann.de...
