Sealevel Systems ULTRA COMM+2.PCI
PCI Serial Interface Module
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
$
595
.00
In Stock
Qty Available: 1
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/79316-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the ULTRA COMM+2.PCI and is the answer not in the manual?

Questions and answers

Summary of Contents for SeaLevel ULTRA COMM+2.PCI

  • Page 1 Sealevel Systems ULTRA COMM+2.PCI PCI Serial Interface Module In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/79316-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 ULTRA COMM+2.PCI Users Manual Part # 7201 Sealevel Systems, Inc. Telephone: 864.843.4343 PO Box 830 Fax: 864.843.3067 Liberty, SC 29657 USA www.sealevel.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3: Table Of Contents

    Contents ........................1 NTRODUCTION .............................. 1 VERVIEW ’ ..........................1 NCLUDED ......................... 1 ACTORY EFAULT ETTINGS ..........................2 ETUP RS-485 E ......................... 2 NABLE ODES ....................... 3 DDRESS AND SELECTION ..........................4 ERMINATION ....................... 5 LECTRICAL NTERFACE ELECTION ............................6 LOCK ODES ............................
  • Page 4 Figure 10 - Clocking Mode ‘Divide By 1’ ......................6 Figure 11 - Asynchronous Communications Bit Diagram................17 © Sealevel Systems, Inc. SL9058 Revision 7/2006 Sealevel Systems, Incorporated. All rights reserved. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 5: Introduction

    RS-485 driver enable. UART upgrades are available providing 32,64 and 128 byte FIFOs. What’s Included The ULTRA COMM+2.PCI is shipped with the following items. If any of these items are missing or damaged, contact the supplier. •...
  • Page 6: Card Setup

    RS-485 as RTS enable or RTS block mode transfer. One of the unique features of the ULTRA COMM+2.PCI is the ability to be RS-485 compatible without the need for special software or drivers. This ability is especially useful in Windows, Windows NT, and OS/2 environments where the lower level I/O control is abstracted from the application program.
  • Page 7: Address And Irq Selection

    Figure 5 - Headers J1B and J2B, RS-485 ‘RTS’ Enabled, with ‘Echo’ Address and IRQ selection The ULTRA COMM+2.PCI is automatically assigned I/O addresses and IRQs by your motherboard BIOS. Only the I/O address may be modified by the user.
  • Page 8: Line Termination

    Connects the TX- to RX- for RS-485 two wire operation. P P T L L Figure 6 - Headers J1A and J2A, Line Termination Sealevel Systems ULTRA COMM+2.PCI Page 4 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 9: Electrical Interface Selection

    Electrical Interface Selection Each port on the ULTRA COMM+2.PCI has the ability to be used in either RS-232 or RS-422/485. This is selectable via four 24 pin DIP-shunts at E1-E4. Please use the following illustration to aid in the configuration of your electrical interface.
  • Page 10: Clock Modes

    Card Setup Clock Modes The ULTRA COMM+2.PCI employs a unique clocking option that allows the end user to select from divide by 4, divide by 2 and divide by 1 clocking modes. These modes are selected at Headers J1C through J4C.
  • Page 11: Baud Rates And Divisors For The 'Div1' Mode

    Choose this Divisor 1200 bps 2400 bps 4800 bps 9600 bps 19.2K bps 38.4K bps 57.6K bps 115.2K bps 230.4K bps 460.8K bps Sealevel Systems ULTRA COMM+2.PCI Page 7 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 12: Baud Rates And Divisors For The 'Div2' Mode

    Choose this Divisor 1200 bps 2400 bps 4800 bps 9600 bps 19.2K bps 38.4K bps 57.6K bps 115.2K bps 230.4K bps Sealevel Systems ULTRA COMM+2.PCI Page 8 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 13: Installation

    Sealevel Systems CD. This file contains valuable information on installing your adapter in the QNX6 Neutrino OS, as well as the files required to ensure a flawless implementation. Also provided on the Sealevel Systems CD are implementation instructions for QNX4. These are found in D:\software\seacom\Other\QNX4\QNX_COM.txt.
  • Page 14: Physical Installation

    Replace the screw. (This is required to ensure FCC Part 15 compliance.) Replace the cover. Connect the power cord Installation is finished. Sealevel Systems ULTRA COMM+2.PCI Page 10 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 15: Technical Description

    IRQs as well as show typically free IRQs. In these early days of PC’s Sealevel Systems decided that the ability to share IRQs was an important feature for any add-in I/O card. Consider that in the IBM XT the available IRQs were IRQ0 through IRQ7. Of these interrupts only IRQ2-5 and IRQ7 were actually available for use.
  • Page 16: Connector Pin Assignments

    Output Receive Data Positive Input Receive Data Negative Input CTS+ Clear To Send Positive Input CTS- Clear To Send Negative Input Sealevel Systems ULTRA COMM+2.PCI Page 12 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 17: Specifications

    10 to 90% R.H. Non-Condensing Manufacturing All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. Power Consumption...
  • Page 18: Appendixa - Troubleshooting

    I/O address. 3. Make sure the Sealevel Systems adapter is using a unique IRQ. While the Sealevel Systems adapter does allow the sharing of IRQs, many other adapters (i.e. SCSI adapters & on-board serial ports) do not. The IRQ is typically selected by the BIOS or Operating system.
  • Page 19: Appendixb - How T O Get Assistance

    When calling for technical assistance, please have your user manual and current adapter settings. If possible, please have the adapter installed in a computer ready to run diagnostics. Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many common questions. This section can be found at http://www.sealevel.com/faq.asp.
  • Page 20: Appendixc - Electrical Interface

    (ground) to determine binary logic states. The RS-232 and the EIA/TIA-574 specification define two types of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The ULTRA COMM+2.PCI is a DTE device. RS-422 The RS-422 specification defines the electrical characteristics of balanced voltage digital interface circuits. RS-422 is a differential interface that defines voltage levels and driver/receiver electrical specifications.
  • Page 21: Appendixd - Asynchronous Communications

    The communication parameters are baud rate, parity, number of data bits per character, and stop bits (i.e. 9600,N,8,1). Sealevel Systems ULTRA COMM+2.PCI Page 17 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 22: Appendixe - Silk -Screen

    Appendix E - Silk-Screen Appendix E - Silk-Screen 5.0" 4.2" Sealevel Systems ULTRA COMM+2.PCI Page 18 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 23: Appendixf - Compliance Notices

    Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. Sealevel Systems ULTRA COMM+2.PCI Page 19 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 24: Warranty

    Sealevel Systems assumes no liability for any damages, lost profits, lost savings or any other incidental or consequential damage resulting from the use, misuse of, or inability to use this product. Sealevel Systems will not be liable for any claim made by any other related party.
