Microphone Hub
COM-MIC-HUB
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior
to starting the installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing pre-made cables.
Basic Wiring Diagram
Copyright © 2024 WyreStorm ProAV Corporation |
COM-MIC-HUB Quickstart Guide | 240923
section for important wiring
KEY
CAT Cable
Control
Audio
USB
wyrestorm.com
In the Box
1x COM-MIC-HUB
1x DC 12V 2A Power Supply (US/EU/UK/AU)
3x 5-pin Phoenix Male Connector
2x 3-pin Phoenix Male Connector
3x 2-pin Phoenix Male Connector
4x Mounting Brackets
1x Quickstart Guide (This Document)
APO-SKY-MIC
Amplifier
Control System
Laptop
Wireless Microphone
Receiver
1 of 4
Quickstart Guide
INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
support@wyrestorm.com
