Summary of Contents for NIIMBOT M2 H
- Page 1 Product Manual Label Printer Smart NIIMBOT M2_H...
-
Page 3: Table Of Contents
01 · 02 Package Contents Specifications Product Description Operation Instruction The Control Panel Maintenance Safety Precautions Related Statements... -
Page 4: Package Contents
Package Contents Smart Label Printer *1 USB Type-C Cable *1 Label Paper Roll *1 Thermal Transfer Ribbon *1 Product Manual *1... -
Page 5: Specifications
03 · 04 Specifications Product Label Printer Model NIIMBOT M2_H Dimensions 108*178*74mm Weight 764g Charging Time 3 - 4 hours Input 5V DC, 2A Thermal Transfer Battery Capacity 2000mAh Printing Method Printing Printing Printing Width 300dpi 20-50mm Resolution Connectivity Bluetooth﹑Type-C... -
Page 6: Product Description
Product Description 03-1 Label Printer Monitor Screen Paper Blade Charging Port Open Cover Power/Menu Paper Feed/Select 03-2 The Carbon Ribbon Parts Ribbon Cassette Unlock Switch Ribbon Cassette... -
Page 7: Operation Instruction
05 · 06 Operation Instruction 04-1 Loading Paper Open Compartment Button Press the Open Compartment Button. Print Side Fit the label paper into the compartment with the print side facing down. Adjust the paper guide to insert the label paper. - Page 8 Label Paper Pull the label paper out of the paper compartment and close the compartment cover. 04-2 Carbon Ribbon Installation Instructions Carbon Ribbon Cartridge Unlock Switch Carbon Ribbon Cartridge Unlock Switch...
- Page 9 07 · 08 Carbon Ribbon Cartridge Unlock Switch Insert the carbon ribbon cartridge, holding it with one hand while securing the lock with the other.
- Page 10 04-3 Software Download 01.Download the NIIMBOT APP Before using the printer, please install the NIIMBOT app from Google Play or the App Store. NIIMBOT Design & Print APP easy to download and use More information available on the NIIMBOT app.
-
Page 11: Special Notes
After downing the APP, make sure your phone’s Bluetooth is on. Note: For Android phones, location permission must be granted. 8:30 Turn on Bluetooth NIIMBOT Open the APP, search and connect to the device through Bluetooth. Notice: If a PIN code is required, input 0000 or 1234. -
Page 12: The Control Panel
The Control Panel 05-1 Interface Description Bluetooth Connection Status Information Display Power Level Paper Type USB Connection Status Device ID M2_H-AB01000001 Interval Connected Four-Grid Display Black mark Transparent Blink While Charging Black gap Connected to PC Paper Types Interval: There is a gap between two label papers. Black mark: Two label papers are connected, and there is a black mark on the back of the label paper. - Page 13 11 · 12 Power/Menu Paper Feed/Select 05-2 Operation Instructions 1.The Power/Menu Button: Menu Selection. 2.The Paper Feed/Select Button: Function Selection. 04-3 Function Description Main Menu Secondary Menu Tertiary Menu Function Description Calibrate when encountering Paper Calibration —— —— paper feed issues. Print Density 1/2/ 3/4/5 ——...
- Page 14 Main Menu Secondary Menu Tertiary Menu Function Description Interval Select the type of label paper Black mark Paper Types Transparent in use Advanced Black gap Settings Select and restore to factory Restore to factory —— default settings default settings...
-
Page 15: Maintenance
13 · 14 Maintenance 06-1 Charging Make sure the product and your hands are dry; plug the USB Type-C cable into the charging port, connect it to the power adapter (purchased separately), and turn on the power. When the device is out of power, the monitor screen will display “The battery level is low. - Page 16 06-2 Cleaning Print Head and Roller Please clean the print head and roller if one of the following situations occurs: Unclear printing. Noise during paper rolling. Foreign objects on the print head. Clean the print head and roller in the following procedures: ①...
- Page 17 15 · 16 Print Head Roller 06-3 FAQs Q：Do I need to enable permission to obtain location information? A：Due to Android’s requirement, you need to enable location to turn on the Bluetooth. Q：What is a PIN code? A：Based on the Android system, most default PIN codes are ‘0000’;...
- Page 18 Q：What to do if the printing is not clear? A：1. Press the power button once and print one page, and then print again; 2. Double-press the power button to print a test page, and then send a picture of the test page to our support team.
- Page 19 17 · 18 4. On the "Paper Calibration" page, press the "Feed/Select" button to perform paper calibration. 5. If the above issues persist, it indicates a sensor malfunction. Please contact customer service for assistance. Q：How to fix wrinkled ribbon? A：Remove the ribbon and rotate the ribbon spool to tighten it. Carbon Ribbon Spool...
-
Page 20: Safety Precautions
Safety Precautions Please read all the instructions and warnings in this manual carefully before using this product to ensure the proper functioning of the device and your safety. *Warnings Don't disassemble the product Do not wipe the product with Do not use the product without authorization. - Page 21 If smoke or smell comes from the product or the power adapter, please unplug the power adapter immediately and avoid any burns. *Important Please use NIIMBOT label paper to prevent print quality issues or printhead damage; The product comes with a built-in rechargeable battery. Do not throw it into fire or heat it.
-
Page 22: Related Statements
Related Statements FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 23 EU member states. This device can be used in European Union. Hereby, [Wuhan Jingchen Intelligent Identifification Technology Co., Ltd.] declares that the radio equipment type [NIIMBOT M2_H] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following...
- Page 24 Support Email : service@niimbot.com Official Website : www.niimbot.com Production Address : No. 1, Tianyang Road, Chuanlong Avenue, Hengdian Street, Huangpi District, Wuhan City, Hubei Province, China © 2023 NIIMBOT. All Rights Reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
