70mm
Product Manual
Label Printer
Smart
110mm
Notice:
If the device cannot be turned on, please charge for one hour.
Wuhan Jingchen Intelligent ldentificationTechnology Co., Ltd.
Support Email : service@niimbot.com
Official Website : www.niimbot.com
Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu
West Road,Hongshan District,Wuhan, China
NIIMBOT B4
© 2024 NIIMBOT. All Rights Reserved.
NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
Advertisement
Table of Contents
Related Manuals for NIIMBOT B4
Summary of Contents for NIIMBOT B4
- Page 1 Support Email : service@niimbot.com Official Website : www.niimbot.com Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu West Road,Hongshan District,Wuhan, China NIIMBOT B4 © 2024 NIIMBOT. All Rights Reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
-
Page 2: Product Manual
Support Email : service@niimbot.com Official Website : www.niimbot.com Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu West Road,Hongshan District,Wuhan, China NIIMBOT B4 © 2024 NIIMBOT. All Rights Reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd. -
Page 4: Table Of Contents
01 · 02 CONTENTS Package Contents Installation Download software Connecting to Print Product Description Specifications Safety Precautions... -
Page 5: Package Contents
Package Contents Smart Label Printer *1 Label Paper Roll *1 USB Type-C Cable *1 Product Manual *1... -
Page 6: Installation
03 · 04 Installation Power button Indicator light Press and hold the power button for 2-3 seconds to turn on the device. Paper compartment release button Press the paper compartment release button to open the paper compartment cover. - Page 7 Printing surface The printing surface of the label paper should be inserted face-down in the paper compartment. Roll holders Push the roll holders to either side, then load the paper roll in between the roll holders with the printing surface face down.
- Page 8 05 · 06 Finally, adjust the position of the label paper so that 2-3cm of the first label sheet is protruding from the paper outlet, then close the paper compartment cover.
-
Page 9: Download Software
Download software 01.Download the app To use this product, please download and install the NIIMBOT app, available from Google Play or the App Store on Apple devices. NIIMBOT Design & Print APP easy to download and use More instructions can be viewed in the NIIMBOT app... -
Page 10: Connecting To Print
Android phones. 8:30 Turn on Bluetooth NIIMBOT Open the app and search for Bluetooth devices to connect to. Note: If it asks for a PIN, enter 0000 or 1234 then press OK. Once successfully connected, go to the Drawing Board. -
Page 11: Product Description
Product Description Power button Indicator light Operation Steps Function Process Turn on Press and hold the power button for three seconds Press and hold the power button for three seconds Turn off while powered on Feed paper Press the power button once while powered on Print testing page Press the power button twice while powered on Label/ Press the power button three while powered on,the... -
Page 12: Power Indicator Light
09 · 10 Indicator light Color Status Meaning Solid Powered on but not connected Blue Flashing quickly Upgrading firmware Solid Bluetooth connected Green Flashing quickly Printing The paper compartment is not closed;out Solid of paper; or paper output error Power Indicator Light Power Indicator light Color Status... -
Page 13: Specifications
Specifications Product Smart Label Printer Model NIIMBOT B4 Dimensions 135*157*69mm Weight 757g Charging Time 3 - 4 hours Input 5V DC, 2A Battery Printing 2000mAh Thermal printing Capacity Method Printing Printing 203dpi 104mm Resolution Width Connectivity Bluetooth, Type-C Charge Type-C... -
Page 14: Safety Precautions
11 · 12 Safety Precautions Read all instructions and warnings in this guide carefully before using the product to ensure proper and safe use of the product and to avoid personal injury or damage to property. *Warning Do not disassemble the Do not use corrosive chemical Do not use the product in product yourself. - Page 15 Purchasing the product through other channels may mean you buy a pirated product or a product not adapted to your region or country of use which may lead to usage issues. In such cases, NIIMBOT may be unable to provide you with further assistance.
- Page 16 13 · 14 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
