Summary of Contents for NIIMBOT B1

  • Page 1 Support Email : service@niimbot.com Official Website : www.niimbot.com Production Address : No. 1, Tianyang Road, Chuanlong Avenue, Hengdian Street, Huangpi District, Wuhan City, Hubei Province, China © 2022 NIIMBOT. All rights reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
  • Page 2 CONTENTS Quick Start Guide Kurzanleitung Guide de démarrage rapide Guía de inicio rápido Guida di avvio rapido...
  • Page 3: Package Contents

    01 · 02 Package Contents Smart Label Printer *1 Label Paper Roll *1 USB Type-C Cable *1 Quick Guide *1...
  • Page 4: Installation

    Installation Open Slide Press the Open Slide on the left to open the paper compartment. Print Side Fit the label paper into the compartment with the print side facing down. Tear-off Blade Paper Compartment Baffle Push the paper compartment baffle to the sides and fit the label paper into the paper compartment with the print side facing down.
  • Page 5 03 · 04 Paper Exit Slide the paper compartment baffle inwards to secure the label paper, pull the first paper out, make sure it sticks out of the paper exit. Power Button Indicator Light Close the paper compartment and long-press the Power Button to turn the printer on.
  • Page 6: Installing App

    Installing App 01.Download App Before using the printer, please install the NIIMBOT app from Google Play or the App Store. NIIMBOT Design & Print APP easy to download and use More information available on the NIIMBOT app. Sign in to NIIMBOT...
  • Page 7: Connecting And Printing

    05 · 06 Connecting and Printing Open NIIMBOT app and turn on Bluetooth on your phone. 8:30 Turn on Bluetooth NIIMBOT On Home, tap Connect smart label printer. Then select device model. Notice: If a PIN code is required, input 0000 or 1234.
  • Page 8: Basic Functions

    Basic Functions Function Operation Switch on Hold down the Power button for three seconds. Hold down the Power button for three seconds when Switch off the device is on. Print history Press the Power button once when the device is on. Print a test page Double-press the Power button when the device is on.
  • Page 9: Led Indicators

    07 · 08 LED Indicators Indicator Status Description Blue Blinking Hardware upgrading Blue Solid Standby Green Blinking Printing Green Solid Bluetooth connected Blinking Charging Paper compartment open/ Solid Out of paper/Paper exit error...
  • Page 10: Specifications

    Specifications Product Label Printer Model NIIMBOT B1 Dimensions 132*91.2*61.6mm Weight 293g Charging Time 3.5 - 4 hours Input 5V DC, 1A Battery Capacity 1500mAh Printing Method Thermal printing Printing Printing Width 203dpi 20-48mm Resolution Connectivity Bluetooth、Type-C Charge Type-C Operating Transmit Power 4dBm(Maximum) 5℃...
  • Page 11: Safety Precautions

    09 · 10 Safety Precautions Please read all the instructions and warnings in this manual carefully before using this product to ensure the proper functioning of the device and your safety. *Warnings Don't disassemble the product Do not wipe the product with Do not use the product without authorization.
  • Page 12 If smoke or smell comes from the product or the power adapter, please unplug the power adapter immediately and avoid any burns. *Important Please use NIIMBOT label paper to prevent print quality issues or printhead damage; Please stop using the product immediately when the battery cannot provide enough power;...
  • Page 13 11 · 12 Packungsinhalt Intelligenter Etikettendrucker *1 Papierrolle *1 USB Type-C Netzkabel *1 Schnelleinstieg *1...
  • Page 14: Schnelle Installation

    Schnelle Installation Öffnungstaste Drücken Sie die Öffnungstaste auf der linken Seite des Rumpfs, um die Abdeckung des Papierfachs zu öffnen. Druckseite Legen Sie bitte das Etikettenpapier mit der Druckseite nach unten in das Papierfach ein. Papierreißer Abdecke des Papierfachs Schieben Sie die Abdecke des Papierfachs zur Seite und legen Sie das Etikettenpapier mit der Druckseite nach unten in das Papierfach ein.
  • Page 15 13 · 14 Papierauslass Schieben Sie die Abdecke des Papierfachs von beiden Seiten nach innen, um das Etikettenpapier zu sichern. Ziehen Sie dann das erste Etikett heraus, bis Papierauslass freiliegt. Ein/Aus-Taste LED-Anzeige Schließen Sie die Abdeckung des Papierfachs. Halten Sie die Ein/Aus-Taste gedrückt, um den Drucken einzuschalten.
  • Page 16 App herunterladan 01.Mobile App herunterladen Bevor Sie dieses Produkt verwenden, laden Sie bitte die App „NIIMBOT“ herunter und installieren Sie sie. Sie können sie direkt durch Google Play oder Apple Store herunterladen. NIIMBOT Design & Print APP easy to download and use Weitere Produktanweisungen sind in der NIMBOT-App einsehbar.
  • Page 17 15 · 16 Zum Drucken verbinden Öffnen Sie zuerst die App „NIIMBOT“ und schalten Sie dann das Bluetooth Ihres Telefons ein. 8:30 Bluetooth einschalten NIIMBOT Klicken Sie auf der Startseite der APP auf „Intelligenter Etikettendrucker verbinden“ und wählen Sie das entsprechende Gerätemodell aus.
  • Page 18 Spezieller Hinweis Die Abbildungen von Produkten, Zubehör, Softwareschnittstellen usw. in diesem Schnelleinstieg sind schematische Diagramme und dienen nur als Referenz. Aufgrund von Produktaktualisierungen und Upgrades kann das tatsächliche Produkt geringfügig von der schematischen Darstellung abweichen. Bitte beziehen Sie sich auf das tatsächliche Produkt.
  • Page 19: Grundlegende Bedienung

    17 · 18 Grundlegende Bedienung Funktion Befehle Einschalten Halten Sie die „Ein/Aus-Taste“ drei Sekunden lang gedrückt Halten Sie im eingeschalteten Zustand die „Ein/Aus-Taste“ Ausschalten drei Sekunden lang gedrückt Drücken Sie im eingeschalteten Zustand auf die Druckverlauf „Ein/Aus-Taste Selbsttestseite Doppeldrücken Sie im eingeschalteten Zustand auf die drucken „Ein/Aus-Taste...
  • Page 20 Blinker Blinker Status Beschreibung Blau Blinkt Firmware-Upgrade läuft Blau Immer an Standby-Modus Grün Blinkt Druckvorgang läuft Grün Immer an Bluetooth verbunden Blinkt Ladevorgang läuft Abdeckung des Papierfachs nicht geschlossen/ Immer an Papier leer/Papierausgabe ist abnormal...
  • Page 21: Technische Daten

    19 · 20 Technische Daten Produkt Etikettendrucker Modell NIIMBOT B1 Maße 132*91.2*61.6mm Gewicht 293g Zeit für Aufladung 3.5 - 4 stunden Nenneingang 5V DC, 1A Batteriekapazität 1500mAh Druckweise Thermodruck Druckgenauigkeit 203dpi Druckbreite 20-48mm Verbindungsmethode Bluetooth,Type-C Lademethode Type-C Sendeleistung 4dBm(Maximum) Betriebstemperatur 5~40℃...
  • Page 22 Sicherheitsvorkehrungen Um eine ordnungsgemäße und sichere Verwendung dieses Produkts zu gewährleisten und Personen- oder Sachschäden zu vermeiden, lesen Sie bitte alle Produktanweisungen und Warnungen im Handbuch sorgfältig durch, bevor Sie dieses Produkt verwenden. *Warnungen Demontieren Sie dieses Produkt Wischen Sie dieses Produkt Verwenden Sie dieses Produkt nicht selbst.
  • Page 23 Sie das Netzteil sofort vom Stromnetz, um Verbrennungen zu vermeiden. *Wichtig Bitte verwenden Sie Original-Etikettenpapier von NIIMBOT, da es sonst zu schlechter Druckqualität oder Schäden am Druckkopf des Geräts kommen kann. Wenn die Batterie dieses Produkts die Leistungsanforderungen nicht erfüllen kann, stellen Sie die Verwendung bitte sofort ein.
  • Page 24: Contenu De L'emballage

    Contenu de l'emballage Imprimante d'étiquettes Rouleau de papier d'étiquettes intelligente Câble USB de type C Guide rapide...
  • Page 25: Installation Rapide

    23 · 24 Installation rapide Bouton d’ouverture Appuyez sur le bouton d’ouverture situé à gauche pour ouvrir le compartiment à papier. Face d'impression La face d’impression du papier d’étiquettes doit être orientée vers le bas. Coupe-papier Butée de papier Écartez la butée des deux côtés et placez le papier d’étiquettes en orientant la face d’impression vers le bas.
  • Page 26 Sortie papier Faites glisser la butée des deux côtés pour fixer le papier d’étiquettes, puis tirez la première languette pour sortir le début du papier. Bouton Marche/Arrêt Voyant lumineux Fermez le capot du compartiment à papier et maintenez le bouton Marche/Arrêt appuyé pour démarrer l’imprimante.
  • Page 27: Télécharger L'application

    Vous trouverez d'autres instructions d'utilisation dans NIIMBOT APP. Connectez-vous à Centre d’aide Instructions d'utilisation NIIMBOT APP 02.Télécharger la version PC Vous pouvez télécharger et installer la version PC de NIIMBOT à partir de la page de téléchargement du site officiel NIIMBOT (www.niimbot.com).
  • Page 28 Connecter l’imprimante Ouvrez NIIMBOT APP, puis activez le Bluetooth de votre téléphone. 8:30 Activer Bluetooth NIIMBOT Sur la page d’accueil, cliquez sur « Imprimante d'étiquettes intelligente connect », sélectionnez le modèle de l’appareil. Remarque : en cas de demande de code PIN, saisissez 0000 ou 1234.
  • Page 29 27 · 28 Remarques Les illustrations de produits, d'accessoires et d’applications dans ce guide rapide sont fournies à titre indicatif uniquement. En raison des mises à jour et des mises à niveau, le produit réel peut être légèrement différent des illustrations, veuillez vous reporter au produit réel.
  • Page 30: Fonctionnement De Base

    Fonctionnement de base Fonction Commande Marche Appuyez sur le bouton Marche/Arrêt pendant trois secondes. Appuyez sur le bouton Marche/Arrêt pendant trois secondes Arrêt lorsque l’appareil est allumé. Imprimer Cliquez sur le bouton Marche/Arrêt lorsque l'appareil est l'historique allumé. Imprimer une Double-cliquez sur le bouton Marche/Arrêt lorsque page d'autotest l’appareil est allumé.
  • Page 31 29 · 30 Instructions relatives au voyant Couleur État Instruction Bleu Clignotant Mise à niveau du programme en cours Bleu Fixe En veille Vert Clignotant Impression en cours Vert Fixe Bluetooth connecté Rouge Clignotant En cours de chargement Le capot du compartiment à papier n' e st pas Rouge Fixe fermé/papier insuffisant/La sortie papier est...
  • Page 32: Caractéristiques Du Produit

    Caractéristiques du produit Imprimante Nom du produit Modèle NIIMBOT B1 d'étiquettes Dimensions 132*91.2*61.6mm Poids 293g Puissance Temps de charge 3.5 à 4 heures 5V DC, 1A nominale Capacité de la Mode Impression 1500mAh batterie d'impression thermique Précision Largeur 203dpi 20-48mm...
  • Page 33: Précautions De Sécurité

    31 · 32 Précautions de sécurité Afin d'assurer une utilisation correcte et sûre du produit et d'éviter des blessures ou des dommages matériels, veuillez lire attentivement les instructions et les avertissements du manuel avant d'utiliser le produit. *Avertissement Ne démontez pas le produit Ne pas utiliser de produits Ne pas utiliser le produit à...
  • Page 34 Veillez à ne pas vous brûler. *Important Utilisez du papier d' é tiquettes original NIIMBOT, sinon car cela peut entraîner une mauvaise qualité d'impression ou endommager la tête d'impression de l’appareil ;...
  • Page 35 33 · 34 Elementos del paquete Una impresora de etiquetas Una rollo de papel inteligente Un cargador USB Type-C Una guía rápida...
  • Page 36: Instalación Manual

    Instalación manual Botón de apertura de la tapa Pulse el botón de apertura situado en el lado izquierdo de la máquina para abrir la tapa de la bandeja de papel. La cara de impresión Nota: La cara de impresión hacia abajo.
  • Page 37 35 · 36 Salida de papel Deslice los deflectores de la bandeja de papel hacia adentro desde ambos lados para mantener el papel de etiquetas en su lugar, luego tire de la primera etiqueta para que quede expuesta en la salida del papel. Botón de encendido Indicador luminoso Cierre la tapa y mantenga pulsado el botón de encendido...
  • Page 38 Descarga de APPs 01.Descargar la aplicación para el móvil Antes de utilizarla, descargue e instale la NIIMBOT APP, que puede obtenerse en Google play o Apple store. NIIMBOT Design & Print APP easy to download and use Para más información sobre el uso, consulte la NIIMBOT APP.
  • Page 39 Nota: Las ilustraciones de la impresora, accesorios y de la NIIMBOT APP en esta guía son sólo de referencia. Debido a las actualizaciones, el producto real puede diferir ligeramente de la ilustración, por favor,...
  • Page 40: Instrucciones Básicas

    Instrucciones básicas Funciones Pasos Mantenga pulsado el "botón ON/OFF" durante tres segundos. Mantenga pulsado el "botón ON/OFF" durante tres segundos mientras está encendido. Imprimir la historia Pulse el "botón ON/OFF" mientras está encendido. Imprimir página Haga doble clic en el "botón ON/OFF" mientras de autocomprobación está...
  • Page 41 39 · 40 Instrucción del LED Colores Estado Descripción Azul Parpadeo Firmware actualizando Azul Brillado En espera Verda Parpadeo Imprimiendo Verda Brillado Bluetooth conectado Rojo Parpadeo Cargando La tapa de la bandeja de papel Rojo Brillado abierta/falta de papel/La salida de papel es anormal...
  • Page 42: Parámetros Del Producto

    Parámetros del producto Impresora de Nombre Modelo NIIMBOT B1 etiquetas Tamaño 132*91.2*61.6mm Peso 293g Tiempo de 3.5 - 4 horas Entrada nominal 5V DC, 1A carga Método de Batería 1500mAh Impresión térmica impresión Precisión 203dpi Anchura 20-48mm Método de Método de...
  • Page 43: Precauciones De Seguridad

    41 · 42 Precauciones de seguridad Para garantizar el uso correcto y seguro de este producto y evitar daños corporales o materiales, lea atentamente todas las instrucciones y advertencias en la guía antes de utilizarlo. *Advertencia No desmonte la impresora. No limpie la impresora con No la utilice cerca de materiales Los productos desmontados no...
  • Page 44 Tenga cuidado para evitar quemaduras. *Importante Utilice papel original de NIIMBOT para garantizar la calidad de la impresión y no dañar el cabezal de impresión de la máquina; Deje de usar el producto en caso de que se dañe la batería;...
  • Page 45: Contenuto Della Confezione

    43 · 44 Contenuto della confezione 1 Stampante intelligente per etichette 1 Rotolo di etichette 1 Cavo Type-C 1 Guida rapida...
  • Page 46: Installazione Rapida

    Installazione rapida Levetta di apertura Aprire il coperchio abbassando la levetta di apertura sul lato sinistro della stampante. Il lato di stampa Nota: inserire il rotolo di etichette posizionandolo con il lato di stampa rivolto verso il basso. Seghetto per tagliare etichette Separatore del portarotolo Spostare i separatori verso entrambi i lati e posizionare il rotolo di etichette con il lato di stampa rivolto verso il basso...
  • Page 47 45 · 46 Apertura dell’uscita di etichette Far scorrere i separatori verso l'interno da entrambi i lati per fissare il rotolo di etichette, poi tirare la prima etichetta fuori dall'apertura dell’uscita di etichette. Tasto di accensione Spia Chiudere il coperchio e accendere la stampante tenendo premuto il tasto di accensione.
  • Page 48: Installazione Dell'app

    Installazione dell'APP 01.Scaricare l’APP dal cellulare Prima di usare questo prodotto, si prega di scaricare e di installare l' A PP NIIMBOT disponibile su Google play o Apple store. NIIMBOT Design & Print APP easy to download and use Ulteriori istruzioni sul prodotto possono essere visualizzate nell' A PP NIIMBOT.
  • Page 49 47 · 48 Collegamento alla stampante Accedere all' A PP NIIMBOT e attivare il Bluetooth. 8:30 Attivare il Bluetooth NIIMBOT Nella home page dell' A PP, cliccare il tasto per connettersi a una stampante per etichette e selezionare il modello di dispositivo corrispondente.
  • Page 50: Operazioni Fondamentali

    Operazioni fondamentali Funzioni Operazioni Accensione Tenere premuto "il tasto di accensione" per 3 secondi. Tenere premuto il "tasto di accensione" per 3 secondi Spegnimento mentre il dispositivo è acceso. Stampa della Fare un clic sul "tasto di accensione" mentre il cronologia dispositivo è...
  • Page 51 49 · 50 Indicazioni della spia Colore della spia Stato Indicazione Aggiornamento di firmware Lampeggia in corso Rimane In attesa costantemente accesa Verde Lampeggia Stampa in corso Rimane Verde Connesso al Bluetooth costantemente accesa Rosso Lampeggia In carica Il coperchio della stampante non Rimane è...
  • Page 52 Parametri del prodotto Stampante per Nome Modello NIIMBOT B1 etichette Dimensione 132*91.2*61.6mm Peso 293g Tempo di 3.5 - 4 ore Input standard 5V DC, 1A ricarica Capacità di Tecnologia di 1500mAh Termica batteria stampa Larghezza di Densità di punti 203dpi...
  • Page 53: Avvertenze Di Sicurezza

    51 · 52 Avvertenze di sicurezza Per garantire un uso corretto e sicuro di questo prodotto ed evitare lesioni personali o danni ai beni, si prega di leggere attentamente tutte le istruzioni e le avvertenze sul prodotto nella guida prima di utilizzarlo.
  • Page 54 *Attenzione Si prega di utilizzare il rotolo di etichette originale di NIIMBOT, per evitare di causare scarsa qualità di stampa o danni alla testina di stampa del dispositivo; Quando la batteria non è in grado di soddisfare i requisiti di prestazione, interromperne immediatamente l'utilizzo;...
  • Page 55 EU member states. This device can be used in European Union. Hereby, [Wuhan Jingchen Intelligent Identifification Technology Co., Ltd.] declares that the radio equipment type [NIIMBOT B1] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following...
