  • Page 1 Support Email : service@niimbot.com Official Website : www.niimbot.com Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu West Road,Hongshan District,Wuhan, China NIIMBOT B31 © 2024 NIIMBOT. All Rights Reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
  • Page 2: Package Contents

    Package Contents Smart Label Printer *1 Label Paper Roll *1 USB Type-C Cable *1 Product Manual *1...
  • Page 3: Installation

    01 · 02 Installation Power Button Press and hold the Power button for three seconds to switch on the printer. Open Slide Press the Open Slide on the left to open the paper compartment.
  • Page 4 Print Side Paper Compartment Baffle Push the paper compartment baffle to the sides and fit the label paper into the paper compartment with the print side facing down. Slide the paper compartment baffle inwards to secure the label paper, pull the first paper out, make sure it sticks out of the paper exit.
  • Page 5 03 · 04 Power Button Indicator Light Close the paper compartment and long-press the Power Button to turn the printer on.
  • Page 6: Installing App

    Installing App 01.Download App Before using the printer, please install the NIIMBOT app from Google Play or the App Store. NIIMBOT Design & Print APP easy to download and use More information available on the NIIMBOT app. Sign in to NIIMBOT...
  • Page 7: Connecting And Printing

    After downing the APP, make sure your phone’s Bluetooth is on. Note: For Android phones, location permission must be granted. 8:30 Turn on Bluetooth NIIMBOT Open the APP, search and connect to the device through Bluetooth. Notice: If a PIN code is required, input 0000 or 1234.
  • Page 8: Product Description

    Product Description Power Button Indicator Light Button Function Description Function Operation Switch on Hold down the Power button for three seconds. Hold down the Power button for three seconds when Switch off the device is on. Feeding Paper Press the Power button once when the device is on. Print a test page Double-press the Power button when the device is on.
  • Page 9: Indicator Light Description

    07 · 08 Indicator Light Description Color Status Description Solid On Powered on, but not connected Blue Blinking Fast Firmware upgrading Solid On Bluetooth connected Green Blinking Fast Printing Solid On Device abnormality Power Indicator Power Indicator Description Color Status Description Blinking Slowly Charging...
  • Page 10: Specifications

    Specifications Product Label Printer Model NIIMBOT B31 Dimensions 132*118*69mm Weight 308g Charging Time 3 - 4 hours Input 5V DC, 1A Battery Printing 1500mAh Thermal printing Capacity Method Printing Printing 203dpi 72mm Resolution Width Connectivity Bluetooth, Type-C Charge Type-C Operating 0℃...
  • Page 11: Safety Precautions

    09 · 10 Safety Precautions Please read all the instructions and warnings in this manual carefully before using this product to ensure the proper functioning of the device and your safety. *Warnings Don't disassemble the product Do not wipe the product with Do not use the product without authorization.
  • Page 12 If smoke or smell comes from the product or the power adapter, please unplug the power adapter immediately and avoid any burns. *Important Please use NIIMBOT label paper to prevent print quality issues or printhead damage; The product comes with a built-in rechargeable battery. Do not throw it into fire or heat it.
  • Page 13 11 · 12...
  • Page 14 Con la presente, [Wuhan Jingchen Intelligent Identification Technology Co., Ltd.] and (2) this device must accept any interference received, including interference dichiara che il tipo di apparecchiatura radio [NIIMBOT B31] è conforme alla that may cause undesired operation. Direttiva 2014/53/UE. Il testo completo della dichiarazione di conformità dell'UE è...
  • Page 15 Cet appareil peut être utilisé dans l'Union européenne. Par la présente, [Wuhan Jingchen Intelligent Identification Technology Co., Ltd] déclare que l'équipement radio de type [NIIMBOT B31] est conforme à la directive 2014/53/UE. Le texte intégral de la déclaration de conformité de l'UE est disponible sur le site web suivant : http://www.niimbot.com.
