- Page 1 LYFT Install Manual Congratulations on the purchase of your LYFT UpDown Desk! You’ve made a significant investment into your health and wellbeing and your body will thank you for it.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page Package Contents Frame Assembly Desktop Installation Electrical Components Installation Attaching other Accessories Activating the Control Panel Control Panel Operation 12-14 Troubleshooting 15-16... -
Page 3: Package Contents
Contained within the box are the following: (x2) (x2) (x2) Crossbar Rail Left Crossbar Right Crossbar (x2) (x2) (x2) Wing Foot (x1) (x1) Control Box Control Panel (x4) (x16) (x8) (x2) (x5) (x12) (x2) M6 x 10 M6 x 112 M6 x 16 ST 3.5 x 13 ST 4.2x16... -
Page 4: Frame Assembly
Attaching the Crossbars to the Legs: You will need the following parts for this step; ○ 1x Leg ■ 1x Allen Key ■ screws (3mm long) ■ 1x Left Crossbar ■ 1x Right Crossbar ■ 1. Taking the Leg , use the Allen Key and tighten the 2x screws. - Page 5 Attaching the Wings: You will need the following parts for this step; ○ 1x Wing ■ screws ■ Anti-Vibration Pads ■ Allen Key ■ 4. Attach Wing to the assembled legs using 2x screws. 5. Attach 6x Anti-Vibration Pads to the Crossbars and Wings as shown below. 6.
- Page 6 Attaching the Feet: You will need the following parts for this step; ○ 1x Foot ■ screws ■ Allen Key ■ 7. Attach the Foot to the leg using 4x screws. 8. Gathering the same parts, repeat the above process to attach the other foot. Unpack your desktop: We recommend you put a protective cloth or towel between the ground and your desktop.
- Page 7 Adjusting the Frame and attaching the Crossbar Rail: You will need the following parts for this step; ○ Desktop ■ 2 x Crossbar Rails ■ screws ■ Allen Key ■ 9. With the desktop face down, place the Legs, one on each side of the desktop - as shown below. 10.
-
Page 8: Desktop Installation
Attaching the Frame to the Desktop: You will need the following parts for this step; ○ 12 x screws ■ Phillips Head screwdriver or power drill ■ 14. Attaching the assembled desk frame to the desktop, use screws which will align with the pre-drilled desktop holes and the mounting holes in the Wings and Crossbars - as shown. - Page 9 Attaching the Control Box: You will need the following parts for this step; ○ screws ■ Phillips Head screwdriver or power drill ■ 18. Attach the Control Box onto the desktop using the 2x screws, into the pre-drilled pilot holes. Attaching the Control Panel: You will need the following parts for this step;...
-
Page 10: Attaching Other Accessories
We suggest attaching any accessories you have purchased while the desk is still upside ○ down. For specific details on installing each accessory, refer to individual setup guides; UpDown Desk setup guide page. Attaching the Cable Clips: You will need the following parts for this step;... -
Page 11: Activating The Control Panel
Continue to hold the buttons until it emits another beep and the desk will move upward a little and the display will show the current desk height. The most important step of all… ENJOY YOUR NEW UPDOWN DESK! -
Page 12: Control Panel Operation
CONTROL PANEL OPERATIONS Indicator Light USB - A Charging Port Timer Up & Down Memory Screen Lock Display Screen The desk can be raised manually by pressing the Up / Down buttons or pre-setting the memory. Memory positions: To save a memory position: ●... -
Page 13: Advanced Function Settings
ADVANCED FUNCTION SETTINGS Setting a Minimum / Maximum Height: If you have an obstruction in the area that you are looking to place your desk and need the desk not to hit that obstruction (such as drawers underneath or a shelf above the desk), you can set a minimum or maximum height, so the desk won't lower or raise above that setting;... - Page 14 ○ Child Lock: The LYFT desk has a safety feature that prevents accidental height adjustments, particularly useful for families with young children or pets. It locks the height adjustment mechanism, ensuring the desk stays at its current position, until the child lock is turned off.
-
Page 15: Troubleshooting
LYFT- Troubleshooting Error Code Fault and Solution Reset code Hold together and long press the "Up" and "Down" buttons together until a beep sounds. E01 / E07 Electrical problem has occurred Turn power off at power point. Unplug Power Cable from power point. - Page 16 LYFT- Troubleshooting Error Code Fault and Solution E14 / E24 Hall wires may be damaged Check the cords are connected correctly. - E14 corresponds to M1 connector - E24 corresponds to M2 connector Replace cords if damaged. E15 / E25 Short circuit Replace the motors or leg columns.
