HT81x V2 - Administration Guide
PRODUCT OVERVIEW
The HT81x V2 analog telephone adapters (ATA) allow users to create a high-quality and manageable IP telephony solution for
residential and office environments. Their ultra-compact size, voice quality, advanced VoIP functionality, security protection,
and auto provisioning options enable users to take advantage of VoIP on analog phones and allow service providers to offer
high-quality IP service. The HT81x V2 are ideal ATAs for individual use and large-scale commercial IP voice deployments since
it will enable small and medium businesses to create integrated IP and PSTN telephony systems that efficiently manage
communication costs. HT81x V2's inclusion of an integrated NAT router and dual 10/100/1000Mbps Ethernet WAN and LAN
ports enables a shared broadband connection between multiple Ethernet devices and the extension of VoIP services to analog
phones.
Feature Highlights
The following table contains the major features of the HT81x V2:
HT812 V2
HT814 V2
HT818 V2
HT81x V2 Technical Specifications
The following table resumes all the technical specifications including the protocols/standards supported, voice codecs,
telephony features, languages, and upgrade/provisioning settings for the HT81x V2.
Interfaces
Two (2) RJ11 FXS ports for HT812 V2.
Telephone
Four (4) RJ11 FXS sports for HT814 V2.
Interfaces
Eight (8) RJ11 FXS ports for HT818 V2.
Network
Two (2) 10/100/1000 Mbps Ethernet port (RJ45).
Interface
LED Indicators
POWER, LAN, WAN, PHONE1, PHONE2 for HT812 V2.
POWER, LAN, WAN, PHONE1, PHONE2, PHONE3, PHONE4 for HT814 V2.
● Support 2 SIP profiles through 2 FXS ports for HT812 V2, 4 FXS port for HT814 V2
and 8 FXS port for HT818 V2.
● Support dual 10/100/1000Mbps Ethernet port.
● Support 3-way voice conferencing.
● Support wide range of caller ID formats.
● Support advanced telephony features, including call transfer, call forward, call-
waiting, do not disturb, message waiting indication, multi-language prompts,
flexible dial plan and more.
● Support T.38 Fax for creating Fax-over-IP.
● TLS and SRTP security encryption technology to protect calls and accounts.
● Automated provisioning options include TR-069 and XML Config files.
● Failover SIP server automatically switches to secondary server if main server loses
connection.
● Use with Grandstream's UCM series of IP PBXs for Zero Configuration provisioning.
● Strong AES encryption with security certificate per unit.
● GR-909 Line Testing Functionalities.
● Exceptional voice quality with wide-band HD codec.
HT81x V2 Features at a Glance
