  • Page 1 S320 ocket arcode canner Uide...
  • Page 2 able of onTenTs Package Contents Optional Charging Accessories Product Information Attach Wrist Strap Charge the Battery Power Adapter Powering On/Off Scanning Barcodes Bluetooth Connection Modes 11-12 Bluetooth Connection Roles Data Mode-For SPP Mode Only Bluetooth ReConnection How to setup your scanner: Download our Companion App 16-18 Setup using Application Mode...
  • Page 3 able of onTenTs AA NiMH Battery Replacement 27-28 Quick Programming 29-34 Status Indicators 35-38 Helpful Resources Battery Warning, Safety, Bluetooth, Compliance & Warranty 40-50...
  • Page 4 The Bluetooth Technology word mark and logos are registered trademarks owned by the ® Bluetooth SIG, Inc. and any use of such marks by Socket Mobile, Inc. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 5 harge the attery Charging connector The S320 must be fully charged before first use. Please allow 8 hours uninterrupted charging for the initial battery charge. The reader can be battery operated for up to 4 hours or connected to power for all day business use.

  • Page 6: Powering On/Off

    owering on *Power button Powering On: Press and hold down the power button until the top LED light turns Green and the S320 plays a melody. The S320 automatically turns on when connected to power. When disconnected, double tap the power button to initiate a scan.

  • Page 7: Connection Modes

    luetooth onneCtion odes Operating System Connection Options Bluetooth Apple Bluetooth Operating Serial Devices Systems (OS) Specific Support (MFi Mode) Android Android 4.0.3 & later Apple iOS iPod, iPhone, & iPad Windows PC Windows 10 & later Mac OS X, Mac OS Mac Books, Mac Mini, &...
  • Page 8 Use with an App developed for iOS devices Software installation is required Use this mode with an Mode to use for iOS applications that support Apple app designed for Socket Mobile readers Socket Mobile barcode readers. Android/Windows Application Mode Software installation is required...
  • Page 9 luetooth onneCtion oles Initiator Configures the barcode reader to initiate a connection to a computer/device with the Bluetooth Device Address specified in the barcode. The barcode must be formatted in Code 128 and contain the data #FNIaabbccddeeff# such that aabbccddeeff is the Bluetooth device address of the computer/device you want to connect to the barcode reader.
  • Page 10 App Mode, so it can be controlled by other apps, such as Shopify and Square, to name a couple of the 1000+ apps available. The Socket Mobile Companion app is designed to ensure you get the maximum utility benefits from your Socket Mobile devices.
  • Page 11 OS A etup pple i pplicAtiOn Scan QR Code using your host device to download Socket Mobile Companion app to pair your barcode reader. Watch how to set up using the Socket Mobile Companion app for demonstration. Launch your barcode reader-enabled Application. The barcode reader will beep once indicating that it is connected to the appropriate application.

  • Page 12: App Mode

    Scan QR Code using your host device to download Socket Mobile Companion app to pair your barcode reader. Launch your barcode reader-enabled Application. The barcode reader will beep once indicating that it is connected to the appropriate application.
  • Page 13 4. Launch Companion from icon in the task tray. In the pop-up menu, click Open. 5. Click the “Start” button and follow the instructions in the wizard. 6. Once complete, you will be ready to scan using Socket’s keyboard emulation (this should be turned off if you have an application that supports the CaptureSDK).
  • Page 14 ow to replace your battery What you’ll need: • Phillips screwdriver • Rechargeable battery How to replace your battery: 1. Loosen screw with a screw driver. 2. Remove battery door. 3. Remove and replace battery. 4. Attach battery door and tighten screw. Battery life may vary with usage and work environment.
  • Page 15 eep and olume ettingS Scan one of the barcodes to enable/disable beep and control the volume level. Note: The reader will not beep, play a melody or power off when scanning the command barcodes below. Volume 0 Volume 1 Volume 2 Volume 3 (default) Volume 4 Volume 5...

  • Page 16: Status Indicator

    ower tatuS ndIcator On Battery Event Power LED Battery capacity Solid Green 100% Battery capacity Solid Yellow Battery capacity <10% Solid Red Quick Blinking Red (1 per Battery capacity<5% second) Unknown state Flashing in Red (new battery) On External Event Power LED power supply Breathing Amber...

  • Page 17: H Elpful R Esources

    +44 (800) 0487363 apan +81 (800) 9190303 9:00 - 5:00 Warranty Checker: https://www.socketmobile.com/support/warranty-checker Socket Mobile Developer Program: Learn more at: https://sckt.tech/capturesdk The User’s Guide (full installation and usage instructions) and Programming Guide (Advanced Barcode reader Configurations) can be download at: https://sckt.tech/downloads...

  • Page 18: H Andling I Nformation

    Socket Mobile technical support at https://sckt.tech/HardwareSupport Changes or modifications of this product, not expressly approved by Socket Mobile may void the user’s authority to use the equipment. Do not charge the reader/writer using an AC adapter when operating the unit outdoors, or in the rain.
  • Page 19 luetooth evice niteD tateS FCC ID: LUBS320 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 20 luetooth evice niteD tateS FCC Guidelines for Human Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. Radio Frequency Interference Requirements This device complies with Part 15 of the FCC Rules.
  • Page 21 luetooth evice anaDa IC ID: 2925A-S320 Industry Canada This Class B digital apparatus complies with Canadian ICES-003 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference and (2) this device must accept any interference, including interference that may cause undesired operation of the device...
  • Page 22 luetooth evice urope UKCA & United Kingdom Compliance Products intended for sale within the United Kingdom are marked with a UKCA, which indicates compliance to applicable Directives and European Normes (EN), as follows. Amendments to these Directives or ENs are included: Normes (EN), as follows: UKCA Directives: Electromagnetic Compatibility Regulations 2016, SI 2016 No.
  • Page 23 JAPAN luetooth evice Telec Marking Compliance Products intended for sale within the country of Japan are marked with a Telec mark, which indicates compliance to applicable Radio Laws, Articles and Amendments. R 020-230035...

  • Page 24: Warning Statements

    Your device contains a rechargeable Lithium-Ion battery which may present a risk of fire or chemical burn if mistreated. Do not charge Socket Mobile data readers in temperatures above 100°F/40°C, as the reader may not charge properly. • Never throw the battery into a fire, as that could cause the battery to explode.
  • Page 25 attery arning tatementS Product Disposal Your device should not be placed in municipal waste. Please check local regulations for disposal of electronic products. WEEE...
  • Page 26 egulatoRy omplianCe UKCA Markings and United Kingdom Compliance Testing for compliance to UKCA requirements was performed by an independent laboratory. The unit under test was found compliant with all the applicable Directives, 2004/108/EC and 2006/95/EC. Waste Electrical and Electronic Equipment The WEEE directive places an obligation on all EU-based manufacturers and importers to take-back electronic products at the end of their useful life.

  • Page 27: Warranty

    Socket Mobile Incorporated (Socket) warrants this product against defects in material and workmanship, under normal use and service, for one (1) year from the date of purchase. Product must be purchased new from a Socket Authorized Distributor or Reseller. Used products and products purchased through non-authorized channels are not eligible for this warranty support.
  • Page 28 xtEndEd arranty SocketCare SocketCare Extended Warranty Coverage Purchase SocketCare within 60 days from the date of purchase of the reader. Product Warranty: The barcode reader’s warranty period is one year from the date of purchase. Consumables such as batteries and charging cables have a limited warranty of 90 days.
