TM SERIES MIXER
TMS
OPERATION & PARTS MANUAL
P/N 108116 R5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Finish Thompson TM Series

Summary of Contents for Finish Thompson TM Series

  • Page 1 TM SERIES MIXER OPERATION & PARTS MANUAL P/N 108116 R5...

  • Page 2: Eu Declaration Of Conformity

    EU Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified by the EU Directives listed. The product may not be taken into service until it has been established that the drive motor for the centrifugal pump complies with the provisions of all relevant EU Directives.

  • Page 3: Declaration Of Conformity

    Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified be the UKCA Directives listed. The product may not be taken into service until it has been established that the drive motor for the Drum and Container Pump complies with the provisions of all relevant UKCA Directives.
  • Page 4 Introduction This manual pertains to the TM Series stainless steel drum mixer and accessories. Finish Thompson Inc. thanks you for choosing our products. We believe the use of our products will be fully satisfactory. When properly installed and operated, your Finish Thompson motor and mixer will provide long, trouble-free service; therefore, please read this manual carefully before carrying out any operations on the mixer/motor unit.
  • Page 5 In any and all events, manufacturer’s liability shall not exceed the purchase price of the product and/or accessories. Warranty Registration Thank you for your purchase of this quality Finish Thompson product. Be sure to take a minute to register your pump at Finishthompson.com/warranty. Simply provide the model number, serial number and a few other pieces of information.
  • Page 6 The personnel in charge of the installation, the operation, and the maintenance of the mixer must be qualified and able to per- form the operations described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of personnel and for the fact that they are not fully aware of the contents of this manual.
  • Page 7 IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons caused by improper use of the equipment. WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids.
  • Page 8 MIXER SPECIFICATIONS MODEL TMS Outer Tube Diameter 2” (5.1 cm) Max. Viscosity 100- 1500 cP (Dependant on motor used) -20°F Min. to 200°F Max. Min./ Max. Fluid Temperature (-29°C Min. to 93°C Max.) Wetted Materials 316 Stainless Steel, PTFE 1 1/4" 43"...

  • Page 9: Installation

    2. Insert the mixer tube into the fluid to be mixed prior to starting the motor. Bung adapters are available to provide a tighter fit between the mixer tube and bung opening of a standard drum. Check drum pump accessories at www.finishthompson.com or contact your local Finish Thompson distributor for bung adapter info.
  • Page 10 Inspection 1. Measure the inside diameter of the shaft hole on the bottom bearing (item 12) and the center bearing (item 10). If it is more than .425 it should be replaced. 2. Visually inspect the turbine assembly (item 11) for wear and replace if needed. 3.
  • Page 11 TMS SPARE PARTS EXPLODED VIEW...
  • Page 12 SPARE PARTS LIST ITEM DESCRIPTION PART NUMBER COUPLING INSERT J100014 COUPLING HALF J100013 BEARING ASSEMBLY W/ ROLL PIN A101672 SEAL ASSEMBLY A100284 LOCK WASHER #8 BRASS J100823 SCREW #8-32 X 1/4 BRASS PAN HEAD M/S J100822 TUBE ASSEMBLY 40” - 316 STAINLESS STEEL A101192-1 SLEEVE 316 STAINLESS STEEL...
  • Page 13 DRUM MIXER TROUBLESHOOTING General Notes: • Do not mix liquids containing metallic particles or other foreign material. • Always store the pump upright as used. • Contact our Technical Service Department at 1-800-888-3743 or by email at techservice@fi nishthompson.com if you have any questions regarding product operation or repair. No or Insu cient Discharge: •...
