U-Line H-8719 Manual

H-8719
DELUXE SAFETY
TAPE APPLICATOR
1. Attach handle and extender together to mounting
post on applicator. (See Figure 1)
Figure 1
2. Turn large knob to adjust spacing between guide
panels for either 2", 3" or 4" wide tape. (See Figure 2)
Figure 2
3. Before loading roll
into applicator, ensure
tape unrolls off bottom
with adhesive side
facing up, not over
top of roll.
(See Figure 3)
PAGE 1 OF 6
1-800-295-5510
uline.com
SETUP
Figure 3
4. Insert tape roll between panels, ensuring round
supports fit securely into tape core. (See Figure 4)
Figure 4
NOTE: Panels may need to flex outward when
loading 4" wide tape.
5. Pull approximately
three feet of tape
forward. Peel
backer off tape
and pull it back
over top of roll
toward spool.
(See Figure 5)
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Figure 5
0325 IH-8719
