Page 2: Table Of Contents
1.3 Connecting a PC to the Product .......... 32 Using a LAN Cable ................ 32 Using a USB Cable................ 33 1.4 System Configuration ............. 34 Installing the Mimaki Driver.............. 35 Installing RIP Software ............... 35 Obtaining Color Profiles.............. 35 Setting Up RIP Software.............. 35 1.5 Ink Replacement Method............
Page 3 2.4 Loading the Media .............. 51 Media .................... 51 Take-up unit.................. 52 Feeding unit .................. 56 Loading the Roll Media ............... 61 Registering the Media................. 80 2.5 Test Printing................ 81 Changing the Layout Direction for Test Printing ......... 81 Ejection Failures ................. 82 2.6 Head Cleaning ................
Page 4 4.3 Replacement of Consumable Item ........ 124 Consumable Item Replacement Timing.......... 124 Wiper Replacement ................ 125 Wiper Cleaner Replacement............. 126 Cap Replacement ................ 128 Replacing the Absorber Around the Station ........ 130 Blowing Fan Filter Replacement............ 132 Ink Supply Unit Ink Absorber Replacement ........ 133 Waste Ink Tank Replacement............
Page 5: Introduction
Adobe, the Adobe logo, Acrobat, Illustrator, Photoshop, and PostScript are the trademarks or registered trademarks of Adobe Incorporated in the United States and other countries. RasterLink and TxLink are trademarks or registered trademarks of Mimaki Engineering Co. Ltd. in Japan and other countries.
Page 6 Use of this product in residential areas may cause harmful interference. If so, the user is responsible for rectifying such interference. • Use only the cables recommended by Mimaki Engineering when connecting to the machine. Use of other cables may cause the product to exceed the restrictions stipulated by FCC regulations.
Page 7: To Ensure Safe Use
To Ensure Safe Use To Ensure Safe Use Symbols In this manual, symbols indicate and explain precautions. Make sure you fully understand the meaning of each symbol and use the machine safely and correctly. Explanation Warning Indicates a potential hazard that may result in death or serious injury if handled improperly or if instructions are disregarded.
Page 8: Usage Precautions
To Ensure Safe Use Usage Precautions l In the event of abnormal conditions • In the event of abnormal conditions such as smoke or unusual odor, turn off the main power immediately and turn off the breaker. Continuing to use the machine under these conditions may result in failure, electric shock, or fire.
Page 9: Power Supply Precautions
To Ensure Safe Use l Power supply precautions • Do not damage or modify the power cable. Do not place heavy objects on, heat or stretch it. Doing so may damage the cable, leading to electric shock or fire. • Do not use the power cable if it is damaged or broken or if the core wire is exposed. Otherwise there is a risk of failure, electric shock, or fire.
Page 10: Disposing Of The Product
To Ensure Safe Use l Caution regarding moving parts • Keep parts of the body such as the face and hands away from moving parts. Also keep clothing (e.g., loose clothing and accessories) that may impede work away from the machine. Failure to do so may result in injury.
Page 11: Usage Restrictions
• Take steps to keep people other than those who have received Mimaki safety training or who have been trained by them out of the hazardous area. There is a danger of injury from moving parts such as the carriage or tension bar while printing is in progress if untrained personnel are allowed within the restricted area while the machine is operating.
Page 12: Notes On Handling Ink Or Any Other Liquid Used With The Machine
Thoroughly read them and make sure you understand the contents. • Be sure to read the safety data sheet (SDS) before use. https://mimaki.com/supply/sds/ • Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when handling ink, maintenance liquid, waste ink, or other solutions used with the machine.
Page 13: Ink Specifications
IC chip read error. • Printing is disabled if a different ink IC chip is used. Ink Specifications Item Tx330-1800B Type Special Dye Sublimation Ink Sb420 (Mimaki Special Pigment Trasnfer Ink TP410 (Mimaki Engineering product) Engineering product) Color Blue (BL)
Page 14: Restrictions Concerning The Expiration Date Of Ink Used In The Machine
Notes on Handling Ink or any Other Liquid Used with the Machine Restrictions Concerning the Expiration Date of Ink Used in the Machine Example: When the expiration date is April 20xx • May 20xx: Replace with new ink or use up as quickly as possible. Printing is possible. •...
Page 15: Installation Precautions
Installation Precautions Installation Precautions • Adhesive and releasing agents may contain flammable constituents such as thinner. This machine is not explosion proof. There is a risk of explosions. • Do not install the machine in a place close to fire. •...
Page 16: Installation Space
Installation Precautions Installation Space Provide the following space around the machine to allow safe and proper replacement of ink and media: l Tx330-1800B Size Tx330-1800B At least 4,230 mm (3,230 mm) Width At least 3,912 mm (1,912 mm) Depth Height...
Page 17: Safety Interlocks
Safety Interlocks Safety Interlocks The machine is equipped with interlocks to ensure safety during use. Printing will abort if you open the covers while printing is underway. The RIP data will need to be resent. • Safety interlock locations...
Page 18: Emergency Stop Switches
Emergency Stop Switches Emergency Stop Switches Press one of the switches to stop the machine immediately for safety. Two emergency stop switches are located at the front of the machine and two at the rear. Front Rear • Do the following after an emergency stop switch has been pressed. (1) Unplug the machine from the power outlet and resolve the problem.
Page 19: Warning Label
Warning Label Warning Label Make sure you fully understand the details indicated on the various warning labels. If any of the warning labels becomes dirty and illegible or peel off, contact your local dealer or our service office to request new warning labels.
Page 20 Warning Label Order code Label Details M910931 Beware of opening and closing parts. Injury may result if hands become trapped. M907833 Indicates dangerous moving parts. M903330 Wear safety glasses and gloves while working. M913867 Indicates dangerous moving parts. M913939 Indicates dangerous moving parts. M905811 Indicates dangerous moving parts.
Page 21: Chapter 1 Before Use
Using a USB Cable ........3 3 Carriage ............. 24 System Configuration ........3 4 Station ............24 Installing the Mimaki Driver ......3 5 Power Supply Switch ......... 25 Installing RIP Software......... 3 5 Operating Panel ......... 26 Obtaining Color Profiles ....... 3 5 Connecting the Power Cable......29...
Page 22: Part Names And Functions
Chapter 1 Before Use 1.1 Part Names and Functions Front Name Overview Ink cartridge Each tank contains an ink of a particular color. Front cover Open the cover to load media or replace consumables. Printing and automatic maintenance are not possible while the covers are open. Maintenance cover Open the cover to perform maintenance on locations such as the carriage underside.
Page 23: Rear And Right Side View
Chapter 1 Before Use Rear and Right Side View Name Overview Blowing fan Blows air to dry ink after printing. Pressure roller Applies pressure to keep media adhering to the feeding belt. Fabric roller Helps keep cloth media clean by removing any ink on the pressure roller. Curved bar Makes sagging media taut.
Page 24: Carriage
Chapter 1 Before Use Carriage The carriage includes a print head for ejecting ink, and a jam sensor for stopping the carriage when media clogs. Printing occurs as ink is ejected while traversing left and right. Station The station includes a cap for preventing the print head nozzle surface from drying out, and a wiper required for print head maintenance.
Page 25: Power Supply Switch
Chapter 1 Before Use Power Supply Switch l Main power switch This is located at the rear on the right-hand side of the product. Main power switch • Do not turn off the main power supply. Turning off the main power supply will disable the automatic maintenance function (including nozzle clogging prevention function and ink discharge channel cleaning function).
Page 26: Operating Panel
Chapter 1 Before Use Operating Panel This is used to control the product and make/change settings. xxxx TEST PRINT MENU REMOTE CLEANING Name Overview Display "Display"(P. 27) [SEL] key Selects the function for the corresponding [FUNCTION] key. [FUNCTION] key Used for test printing, head cleaning, and editing settings. "[FUNCTION] key"(P.
Page 27: Menu Mode
Chapter 1 Before Use Display SETUP 1 MENU mode <setting type number> Connected cable type Head height Detected media width 1620mm PRINT POST 35°/40° 40°/40° Ink status TEST PRINT Function name assigned to MENU REMOTE CLEANING [FUNCTION] key MENU mode Four menu modes are available.
Page 28 Chapter 1 Before Use [FUNCTION] key This section describes the functions and roles assigned to the [FUNCTION] key. Icon Overview Displays the various menu screens. "Setup"(P. 93) Displays maintenance functions such as test printing and cleaning. Switches from LOCAL mode to REMOTE mode. Displays adjustment functions such as feed adjustment and drop position adjustment.
Page 29: Connecting The Power Cable
Chapter 1 Before Use 1.2 Connecting the Power Cable Check to confirm that the main power supply is turned off. Connect the cable band to the machine. Connect the power cable to the inlet of the machine. Secure the power cable to the cable band. •...
Page 30: Turning Off The Power
Chapter 1 Before Use Press the [END/POWER] key to turn on power. • The firmware version appears on the display, and the initial operation is executed. The machine will then enter the Media Select mode, and is ready for use. [END/POWER] key Turn on the power for the connected PC.
Page 31 Chapter 1 Before Use • Do not turn off the main power supply. Turning off the main power supply will disable the automatic maintenance function (including nozzle clogging prevention function and ink discharge channel cleaning function). This increases the risk of ejection failures (such as nozzle clogging or deflection).
Page 32: Connecting A Pc To The Product
Chapter 1 Before Use 1.3 Connecting a PC to the Product Connect the machine to the RIP PC. The following cables can be used: "Using a LAN Cable"(P. 32) (Recommended) "Using a USB Cable"(P. 33) When using the USB cable •...
Page 33: Using A Usb Cable
USB Connection Precautions • When connecting more than one Tx330-1800B to a PC – If the PC has more than one USB port, try connecting to a different USB port to check whether the product is correctly recognized.
Page 34: System Configuration
Chapter 1 Before Use 1.4 System Configuration Use RIP software to request to print data created using applications like Illustrator or Photoshop. [Ethernet connection] RIP-PC Receiving Print Data Generating RIP Data [Local network] Preparing RIP Data Print request...
Page 35: Installing The Mimaki Driver
Internet. For more information, refer to "Installing Profiles" in the RasterLink Series installation guide. https://mimaki.com/download/software.html [RasterLink Series used] > [Manuals] • Color profiles for Mimaki RIP software (RasterLink) are available on the Mimaki website. https://mimaki.com/download/inkjet.html [Tx330-1800B] > [Profile] Setting Up RIP Software The explanation here applies to MIMAKI RIP software (RasterLink).
Page 36 Chapter 1 Before Use Register Tx330-1800B. (1) Click [Add]. (2) Set the specifics for Tx330-1800B. • Model: Select the model. For models using normal ink sets, select [Tx330]. For models using hybrid ink sets, select [Tx330-Hybrid]. • Color: Select the ink set filled.
Page 37: Ink Replacement Method
Chapter 1 Before Use 1.5 Ink Replacement Method When Ink Near End is Displayed Ink levels are low. We recommend replacing with new ink as soon as possible, because the ink packs are nearly empty. Printing is still possible but continuous printing is not, and some maintenance functions such as cleaning are disabled.
Page 38: Replacing Ink
Chapter 1 Before Use Replacing Ink Ink replacement procedure l Removing Ink Eco-cases Push down the lever on the pedestal, and remove the ink Eco-case. Open the ink eco-case, then remove the ink pack. Remove the ink IC chip.
Page 39 Chapter 1 Before Use Wipe off any ink adhering to the ink eco-case opening. • Check to confirm no foreign matter such as dust or paper towel matter is adhered to the opening. If foreign matter is present, this may block the ink path and lead to leakage. •...
Page 40 Chapter 1 Before Use Shake the ink pack to the left and right slowly at least 20 times. • Shake the bottle slowly from left to right to ensure that the ink moves inside, holding the ink pack opening with a paper towel. Repeat •...
Page 41 Chapter 1 Before Use l Mounting the ink The order of the ink eco-cases to be set varies depending on the ink set you are currently using. Check the ink slot numbers, then insert the correct color ink eco-cases. Ink set Ink positions Sb420 (4-color) Sb420 (6-color)
Page 42 Chapter 1 Before Use Insert the new ink IC chip into the ink IC chip slot. • Insert the ink IC chip with the metal side facing up. Inserting it in the wrong way may cause failure of the machine or damage the ink IC chip. •...
Page 43: Chapter 2 Printing
Chapter 2 Printing This chapter This chapter describes printing procedures and settings. Print Process ...........44 Head Cleaning..........8 3 Adjusting Print Head Height ......47 Feed Correction..........8 4 Feed Correction Procedure......8 4 Setting Up the Fabric Roller ......49 Correcting the Drop Position ......8 6 Loading the Media ...........51 Drop Position Correction Procedure ....
Page 44: Print Process
Chapter 2 Printing 2.1 Print Process Turn on the power. "Turning On the Power"(P. 29) [END/POWER] key Connect a RIP PC to the machine. "Using a USB Cable"(P. 33) "Using a LAN Cable"(P. 32) Setting Up RIP Software "Installing RIP Software"(P. 35) (required first time only) "Obtaining Color Profiles"(P.
Page 45 Chapter 2 Printing Loading the Media "Loading the Media"(P. 51) Check the state of the print head nozzles. "Test Printing"(P. 81) Good example Bad example Nozzle Deflection Nozzle clogging Clean the head to clear malfunctioning nozzles. There are three different head cleaning methods. Choose the head cleaning method based on test print results.
Page 46 Chapter 2 Printing Printing RIP data "Printing"(P. 90)
Page 47: Adjusting Print Head Height
Chapter 2 Printing 2.2 Adjusting Print Head Height Adjust the height of the print head according to the thickness of the media you are using. Range Gap between print head and platen 3.0 mm (default setting) Low-Middle 4.0 mm Middle 5.0 mm Middle-High 6.0 mm...
Page 48 Chapter 2 Printing • Check the head height indicated on the display. Readjust the height using the height adjustment lever if it is not at the set height. SETUP 1 Head height 1620mm PRINT POST 35°/40° 40°/40° TEST PRINT MENU REMOTE CLEANING...
Page 49: Setting Up The Fabric Roller
Chapter 2 Printing 2.3 Setting Up the Fabric Roller When printing on to coarse cloth, ink remaining on the back of the cloth may adhere to the tension roller and dirty the cloth media. Attaching the fabric roller helps to prevent the cloth media from becoming dirty by removing any ink adhering to the tension roller.
Page 50 Chapter 2 Printing Wind cloth around the fabric roller. (1) Align the cloth with the roller. Fabric roller (2) Secure the cloth to the roller with adhesive tape. Tape (3) Wind the cloth around the roller, then secure with adhesive tape. Attach the fabric roller with the cloth wound on it.
Page 51: Loading The Media
Media l Media handling precautions • Use Mimaki-approved media to ensure consistent high-quality printing. • Assign at least two persons to load roll media. (Assign up to six persons to this task depending on the media weight.) •...
Page 52: Take-Up Unit
Chapter 2 Printing Take-up unit Use the switch on the take-up unit to change the media take-up direction. Direction selector switch On/off button Name Overview Direction Up (reverse) Taken up with the printed surface inside selector switch Down (forward) Taken up with the printed surface outside On/off button Activates/deactivates take-up.
Page 53 Chapter 2 Printing Attach the torque limiter. (1) Insert the torque limiter. Torque limiter (2) Attach the torque limiter so that the surface is flush with the end of the take-up/feeding unit shaft, as shown. • Efficient media take-up is not possible unless the end of the shaft and the torque limiter surface are flush.
Page 54 Chapter 2 Printing Adjusting the torque limiter The left and right take-up units are fitted with a torque limiter. Turn the torque limiter adjustment nut to adjust take-up tension. When adjusting the torque limiters, be sure to adjust to the same torque for both the left and right take-up units. Mid (recommended) Adjustment nut Torque scale...
Page 55 Chapter 2 Printing Removing the roll media after printing l Procedure Cut the media. • Use scissors or the like to cut away the printed portion. • With paper media, be careful to avoid paper cuts from the cut edge. Use the switch on the take-up unit to take up the printed media.
Page 56: Feeding Unit
Chapter 2 Printing Feeding unit The switches on the feeding unit can be used to change the media feed direction. Direction selector switch On/off button Name Overview Direction Up (reverse) • To feed media printed on the inner surface, using the tension bar selector switch •...
Page 57 Chapter 2 Printing Media/printing conditions Action • The media sags and is not taken up smoothly. The media is insufficiently tensioned. Increase the counterweights to increase the weight on the tension bar to suit the media being used. Counterweights • The machine is not shipped with counterweights attached. •...
Page 58 Chapter 2 Printing Attaching weight-adjustment springs Loosen the screw and remove the bracket holding the weight-adjustment shaft. Screw Weight-adjustment shaft bracket Pull out the weight-adjustment shaft. • Rotate the hole on the weight-adjustment shaft sideways, then raise the tension bar. Weight-adjustment shaft Remove the weight-adjustment spring currently attached.
Page 59 Chapter 2 Printing With the hole of the weight-adjustment shaft facing the side, insert the shaft and push the bracket all the way in. Hole Tighten the screw. Attaching counterweights for tension bar weight adjustment • If the counterweights shown below are included (28 weights, 50 g each), they can be attached as follows.
Page 60 Chapter 2 Printing Roll holder setting position A label showing the roll holder setting position is placed on the leg stay. Use it as a reference to move the roll holder, then secure using the knob screw. Setting position for 3-inch paper core Set the roll holder reference line within the area indicated by the arrows as shown below.
Page 61: Loading The Roll Media
Chapter 2 Printing Loading the Roll Media Rolls of cloth media can be loaded on the printer with or without using tension bars. The media is detected as you load it. • When loading the media in the center, use the take-up extension cable. •...
Page 62 Chapter 2 Printing Secure the feeding tension bar by setting it in the locked position. Lock position Tension bar Attach reversing bars to suit the media you will load. • To stabilize feeding-side tension, attach reversing bars at suitable positions for the media you will load.
Page 63 Chapter 2 Printing Insert a roll bar through the roll. • Insert a roll holder that fits the paper core and tighten the screws. Media Roll holder Roll bar • Be sure to insert the roll holder all the way in. Incorrect insertion may cause the paper core to be gouged.
Page 64 Chapter 2 Printing • When loading roll media, be careful to avoid dropping it on your feet. Heavy media may cause injury. • At least two people must work together to load roll media. Working alone may result in back injury from the weight of rolls. Slide the bar holder and tighten the screws.
Page 65 Chapter 2 Printing Load the media in the machine. Media path (1) Load media, referring to the media path. • Pass the media over the tension and reversing bars to ensure suitable tension. • Pass the media over the smoothing roller and curved bar, then under the pressure roller handle.
Page 66 Chapter 2 Printing • Be careful when handling the pressure roller, which is heavy. Press the [ENTER] key. • The feeding tension bar is activated to detect and adjust media tension on the feeding side. • After media detection on the feeding side, the media take-up diameter is detected. Smooth out any wrinkles in the media.
Page 67 Chapter 2 Printing Load the empty paper core in the take-up unit and adjust the take-up legs to stabilize them on the floor. • After mounting the paper core, set up the take-up legs on the floor. Paper core Take-up unit Secure the media on the take-up unit.
Page 68 Chapter 2 Printing Press the take-up unit switch to take up the media a little, about one revolution. Direction selector switch On/off button (1) Take up the media by setting the take-up direction selector switch at left and then pressing the on/off button at right to activate it.
Page 69 Chapter 2 Printing Adjusting the reversing bars To print with suitable tension for the media, adjust the positions and quantity of reversing bars. • The head height should also be adjusted to suit the cloth thickness when thick cloth is held by the cloth holders.
Page 70 Chapter 2 Printing The media path when loading cloth media without tension bars is shown in the following figure. Understanding the media path before loading will make loading easier. Media path • Before loading cloth media, make sure the area around the grit roller is clean. Clean this area if it is dirty.
Page 71 Chapter 2 Printing Setting the media edge guides After loading media, move the media edge guides on the left and right sides until they touch the edges of the media lightly. Media edge guide Media edge guide • Set the guides so that the media edges rise 5 to 10 mm. •...
Page 72 Chapter 2 Printing Loading media without using peeling • Take-up using a torque limiter may not be possible when using media that clings strongly, or if the paper core on the take-up side is warped due to heavy media. In this case, we recommend activating peeling and using a direct-connection unit for take-up.
Page 73 Chapter 2 Printing Press the [ENTER] key. • Next, a screen is displayed for entering the position of the left edge of the media. This screen is not displayed and the setting is finished if you select media width input mode in step 2. LEFT EDGE POSITION 40°...
Page 74 Chapter 2 Printing l Adjustment if media clings weakly Attach the included weights in the area outlined in red in the figure (at left and right). • Pressure roller ballast weights: 40 pcs. (20 for each side) • Always attach the included grommet after loading weights. Grommet Pressure roller ballast weights Adjusting the peeling sensor position...
Page 75 Chapter 2 Printing Recommended sensor positions l Adjustment if media clings strongly Adjust the lower sensor upward to avoid false detection of sensor errors. Media Adjust the lower sensor upward Peeling roller Belt l Adjustment if media clings weakly (especially with large-diameter rolls) Adjust the upper sensor downward.
Page 76 Chapter 2 Printing Using the curved bar to make sagging media taut Always use the curved bar to make sagging cloth media taut if gummed left and right media edges are quite short compared to the center. (In this case, the center sags significantly when the media is spread out on the floor).
Page 77 Chapter 2 Printing l When the curved bar is not used • If the curved bar will not be used, remove both tilt adjustment screws (at left and right) and loosen the retaining screws (at left and right). Next, rotate the curved bar so that it no longer touches the media, then retighten the screws.
Page 78 Chapter 2 Printing Loosen the knob screws on the left and right ends of the smoothing roller and shift the coils as needed. Knob screws • See "Shifting Coils" for details on shifting coils. Reinstall the smoothing roller. l Shifting coils You can reposition the central area of the coils as shown in the following figure.
Page 79 Chapter 2 Printing Slide coils left to fill up the empty space, tighten the knob screw, then remove the knob screw on the right end. Using the coils removed in step 1, add the coils to the shaft from the right end. Tighten the knob screw.
Page 80: Registering The Media
Chapter 2 Printing Registering the Media When the clamp lever is lowered with media being loaded, the Select Use Media screen is displayed. Registration is required to use media that is not registered on the machine. • To set print conditions for a single use, select "Temporary". The conditions set in "Temporary" are cleared when the machine is restarted.
Page 81: Test Printing
Chapter 2 Printing 2.5 Test Printing Head 1 Head 1 Print a test pattern to confirm that the ink prints correctly. Perform head cleaning if you observe any ejection Head 2 Head 2 failures (e.g., nozzle clogging or deflection). "Head Cleaning"(P. 83) [For Sb420 ink] Head 1 Head 1...
Page 82: Ejection Failures
Chapter 2 Printing Ejection Failures Typical examples of ejection failures (e.g., nozzle clogging, deflection) are as shown below. In order to prevent printing in such a state, check whether the ink has been properly ejected regularly before printing. Nozzle Deflection Nozzle clogging Ink drips Mist...
Page 83: Head Cleaning
Chapter 2 Printing 2.6 Head Cleaning The following head cleaning methods are available. Choose the method based on test results. Cleaning is not possible when the [Ink Near End] or [Ink End] errors are displayed. Replace with new ink. "Replacing Ink"(P.
Page 84: Feed Correction
Chapter 2 Printing 2.7 Feed Correction Changing the media may affect the feed amount due to various factors, including the weight and thickness of the media and whether the take-up unit is used. Correct the drop position to suit the type of media used. Image defects (e.g., dark or light streaks) will result if the feed is not properly corrected.
Page 85 Chapter 2 Printing Correcting the Media Feed During Printing You can also correct the media feed amount in REMOTE mode or during printing. Press [ADJUST] in REMOTE mode or during printing. Enter the correction value, then press the [ENTER] key. •...
Page 86: Correcting The Drop Position
Chapter 2 Printing 2.8 Correcting the Drop Position Changing the media and print head height and temperature changes around the print head will also alter the drop positions. Correct the drop position to suit the type of media used. Image defects (e.g., overlaid lines or blurred images) will result if the drop position is not properly corrected.
Page 87 Chapter 2 Printing Enter the correction value, then press the [ENTER] key. • Correction value: -40 to 40 • If the lines do not coincide when the correction value is within the range -40 to 40, the print head height may have been improperly adjusted. Adjust the print head height. "Adjusting Print Head Height"(P.
Page 88: Preparing Rip Data
(2) Select the desired image data, then click [Open]. • If multiple printers are registered, select Tx330-1800B in "Printer Name". Select the image data imported. • The image data is added in the tab for Tx330-1800B selected in "Printer Name".
Page 89 (2) Select "Immediate Print" or "RIP and Print", then click [Start]. • Media width must be reacquired after replacing media. (1) Select the tab for Tx330-1800B in the main window. (2) Click (Update the printer status) in the Printer tab.
Page 90: Printing
Chapter 2 Printing 2.10 Printing Check beforehand • Was the print head adjusted? "Adjusting Print Head Height"(P. 47) • Is media loaded? "Loading the Media"(P. 51) • For roll media, is the rear roll media free of sagging? • When using the take-up unit, was the media mounted on the paper core of the take-up unit? "Loading the Roll Media"(P.
Page 91: Starting Printing
Starting Printing Send the RIP data from the PC. • "Preparing RIP data"(P. 88) • If the message "Attention20A Driver version" appears, install the latest Mimaki driver. https://mimaki.com/download/inkjet.html Start printing. • Printing starts once RIP data is received. [Number of passes]...
Page 92: Stopping Printing (Data Clear)
Chapter 2 Printing Stopping Printing (Data Clear) On the LOCAL mode screen, select [DATA CLEAR]. LOCAL width:1340mm ADJUST DATA CLEAR Press the [ENTER] key to clear the received data. • The receive buffer is cleared.
Page 93: Chapter 3 Setup
Chapter 3 Setup This chapter This chapter describes the [MENU] functions. Media Setting Menu ........94 Function Setting Menu ........1 01 Maintenance Menu ..........96 Environment Setting Menu ......1 03 Registering Nozzle Recovery..... 99 Machine Status Menu........1 05 Nozzle Check ........... 100...
Page 94: Media Setting Menu
* The available resolutions vary according to the model. External Heater ON/OFF Turns the external heater on or off. MAPS: Mimaki Advanced Pass System MAPS4 This function disperses the boundaries between passes to make feed streaks between passes less visible.
Page 95 Chapter 3 Setup Item Setting Details AUTO/ This should normally be set to "AUTO". When set to MAPS MANUAL "MANUAL", the following items are displayed: Speed 50 to 100 % Reducing speed will make streaks less visible. However, printing will be slower. Smoothing 0 to 100 % Increasing smoothing makes streaks less visible.
Page 96: Maintenance Menu
Chapter 3 Setup 3.2 Maintenance Menu This menu is used for maintenance actions. It also lets the user perform nozzle recovery if nozzle clogging persists even after cleaning and nozzle washing. l Menu List Item Details Setting Station Maint. This moves the carriage to allow station and print head maintenance.
Page 97 Chapter 3 Setup Item Details Setting Length 0.1 to 30.0 to Performs nozzle clogging detection after the length set is reached 100.0 m and before the next print starts. File 1 to 30 to Performs nozzle clogging detection after the preset number of files 1,000 files has been printed and before the next print starts.
Page 98 Chapter 3 Setup Item Details Setting Reset Waste Ink Resets the waste ink tank usage count. "Replacing the Waste Tank Volume Ink Tank"(P. 134) Adjust Waste Ink Corrects the waste ink tank usage count. "When "Check Waste Volume Ink Tank" message appears"(P. 134) Tank Capacity Displays the waste ink tank capacity.
Page 99: Registering Nozzle Recovery
Chapter 3 Setup Registering Nozzle Recovery Allows other nozzles to be used for printing if maintenance actions like nozzle washing fail to resolve ejection failures (e.g., nozzle clogging or deflection). • Nozzle recovery can be specified for up to 20 nozzles per row. The time taken for printing remains unchanged even when nozzle recovery is set.
Page 100: Nozzle Check
Chapter 3 Setup Press the [ENTER] key once entry is complete. • Select [Maintenance] > [Nozzle Recovery] > [Test Print], then select "ON" to perform nozzle recovery and test printing. "Test Printing"(P. 81) Nozzle Check This is used to check for nozzle clogging before printing starts. Sets whether to perform maintenance functions automatically if nozzle clogging is detected.
Page 101: Function Setting Menu
Sets the stop time after printing. The next data is printed once the set time has elapsed. • The Mimaki RIP software (RasterLink) does not allow the user to specify Print End. If the machine is set to "HOST", the time will be "0".
Page 102 Sets the offset value from the media left and right standard margins (15 mm). Margin • The Mimaki RIP software (RasterLink) does not allow the user to specify margins. If the machine is set to "Host", the offset value will be "0 mm" for the left and right margins.
Page 103: Environment Setting Menu
• This can be set when both [DHCP] and [AutoIP] are disabled. Remote Control An application (MRA: Mimaki Remote Access) is required to use the remote control function. MRA is a remote access tool installed on a computer or smartphone that allows viewing of product information and panel operation from a remote location away from the machine (within the same network segment).
Page 104 Chapter 3 Setup Item Details Setting PIN code 0000 to 9999 Enter the same PIN code as MRA. The PIN code is used for authentication between the machine and MRA. • When the machine is set to "0000", MRA can access the machine with any PIN code.
Page 105: Machine Status Menu
Chapter 3 Setup 3.5 Machine Status Menu This is used to check machine information. l Menu List Item Details Usage WIPING The number of wiping cycles is displayed. • To reset the number of wiping cycles, press the [FUNC2] key while the level is displayed.
Page 106 Chapter 3 Setup...
Page 107: Chapter 4 Maintenance
Chapter 4 Maintenance This chapter To ensure years of precise performance, maintain the machine periodically based on frequency of use. Read the maintenance precautions thoroughly before maintaining this product. Maintenance Precautions ......108 Replacement of Consumable Item ....1 24 Consumable Item Replacement Timing..1 24 Maintenance Methods ........109 Wiper Replacement ........
Page 108: Maintenance Precautions
Chapter 4 Maintenance 4.1 Maintenance Precautions • This machine includes parts that must be replaced periodically. We therefore recommend taking out a maintenance contract. Carry out maintenance periodically and replace consumable items to prevent quality defects and accidents. • Clean periodically. Debris and dust will accumulate on electrical components when the machine is used for extended periods.
Page 109: Maintenance Methods
Items Required for Maintenance To order replacement consumable items, contact your local dealer or our service office. For more information on consumable items, refer to our website (https://mimaki.com/supply/inkjet.html). • Do not store consumable items in locations where children may enter.
Page 110: Ink Maintenance
Chapter 4 Maintenance Ink Maintenance If ink constituents are sedimented, the ink density may become uneven. We recommend shaking the ink periodically to keep printing consistent. Once every three days. • Shake taking care that the ink eco-cases do not become detached from the ink supply unit. Ink may leak out if the ink eco-cases become detached.
Page 111: Carriage Underside Cleaning
Chapter 4 Maintenance Clean the cap rubber. • Wipe off any ink and dust adhering using a cleaning stick moistened with maintenance liquid. Wipe off the maintenance liquid. Make sure none remains. • Clean the areas indicated in red in the diagram (the entire interior and exterior of the cap rubber, the tabs, and the mesh retainers).
Page 112: Wiper Cleaning
Chapter 4 Maintenance Clean around the print head. • Wipe off any ink and dust adhering using a cleaning stick moistened with maintenance liquid. Wipe off the maintenance liquid. Make sure none remains. Clean the print head sides and all around the nozzle plate using a cleaning stick. Never touch the nozzles Clean using a cleaning stick or soft cloth.
Page 113 Chapter 4 Maintenance Remove the wiper. • Hold the lug at the rear of the wiper bracket, then pull out the wiper. Clean the wiper and bracket. • Wipe off any ink and dust adhering using a cleaning stick moistened with maintenance liquid. Wipe off the maintenance liquid.
Page 114: Ncu Cleaning
Chapter 4 Maintenance Reattach the wiper at the original position. Projection Once cleaning is complete, close the cover, then press the [ENTER] key. NCU Cleaning The NCU uses a sensor to monitor the ink droplets ejected from the print head nozzles. Continuing to use the dirty NCU may prevent the nozzle check function from operating correctly.
Page 115: Das (Automatic Correction Function) Sensor Cleaning
Chapter 4 Maintenance Clean the NCU. • Wipe off any ink and dust adhering using a cleaning stick moistened with maintenance liquid. Wipe off the maintenance liquid. Make sure none remains. • Insert the cleaning stick as far as the line shown in the illustration. Once cleaning is complete, close the cover, then press the [ENTER] key.
Page 116: Ink Discharge Channel Cleaning
Chapter 4 Maintenance Clean the DAS sensor. • Wipe clean using cotton swabs or a soft cloth. • For heavy soiling, wipe using a soft cloth soaked in diluted neutral detergent and thoroughly wrung out. Once cleaning is complete, close the cover, then press the [ENTER] key. Ink Discharge Channel Cleaning Clean the ink discharge channel regularly to prevent clogging of the ink discharge channel below the cap.
Page 117 Chapter 4 Maintenance • If not, use a syringe to draw up some maintenance liquid and drip in approximately half a capful. • Check to confirm that there is approximately half a capful of maintenance liquid inside. • If not, use a syringe to draw up some maintenance liquid and drip in approximately half a capful.
Page 118: Jam Sensor Detecting Plate Cleaning
Chapter 4 Maintenance Jam Sensor Detecting Plate Cleaning Continuing to use the dirty carriage underside will rub dried ink and attached dust on to the media, resulting in contaminated prints. On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key. •...
Page 119: Peeling Roller Cleaning
Chapter 4 Maintenance Peeling Roller Cleaning • For heavy soiling, wipe using a soft cloth soaked in diluted neutral detergent and thoroughly wrung out. Belt Correction Unit Cleaning Adhesive applied to the feeding belt may adhere to the rubber gripper on the belt correction unit. Any adhesive on the rubber gripper may cause the belt correction unit to slip and affect printing quality.
Page 120 Chapter 4 Maintenance Feed the belt by specifying the count in [Maintenance] > [Belt Maintenance] > [Belt Cleaning]. Repeat steps 1 and 2 to clean the entire length of the belt. Raise the pressure roller. • Holding the sections labeled GRIP with both hands, pull toward you. Lock the pressure roller.
Page 121: Cover (Exterior) Cleaning
Chapter 4 Maintenance Remove the maintenance cover. Clean the rubber gripper. • Using a cloth soaked in alcohol, wipe the rubber gripper above and below the feeding belt. Rubber gripper Feeding belt Rubber gripper Attach the maintenance cover. Cover (Exterior) Cleaning •...
Page 122 Chapter 4 Maintenance Check beforehand Is [Near End] or [Ink End] displayed? • Maintenance liquid and ink is aspirated during the washing operation. Washing is not possible if an error occurs during this process. Replace with new ink. • Do not turn off the main power supply. Turning off the main power supply will disable the automatic maintenance function (including nozzle clogging prevention function and ink discharge channel cleaning function).
Page 123 Chapter 4 Maintenance Open the maintenance cover on the right side. • Check to confirm that the cap is filled with maintenance liquid. • If not, use a syringe to draw up some maintenance liquid and fill until it almost overflows from the cap.
Page 124: Replacement Of Consumable Item
4.3 Replacement of Consumable Item To order replacement consumable items, contact your local dealer or our service office. For more information on consumable items, refer to our website (https://mimaki.com/supply/inkjet.html). • Do not store consumable items in locations where children may enter.
Page 125: Wiper Replacement
Chapter 4 Maintenance Wiper Replacement The machine maintains a count of the number of wiping cycles. The "Replace Wiper" message appears when a preset count is reached. Replace dirty or warped wipers with new ones. "Replace Wiper" appears on the display. On the LOCAL mode screen, select [MENU] >...
Page 126: Wiper Cleaner Replacement
Chapter 4 Maintenance Clean the wiper slider. • Wipe off any ink and dust adhering using a cleaning stick moistened with maintenance liquid. Wipe off the maintenance liquid. Make sure none remains. Mount a new wiper. Projection Once replacement is complete, close the cover, then press the [ENTER] key. •...
Page 127 Chapter 4 Maintenance Open the maintenance cover on the right side. Remove the fitting. • Hold the lugs on the fitting, then pull off. • Take care to avoid losing the rubber seal. Remove the wiper cleaner. • Slide forward to remove.
Page 128: Cap Replacement
Chapter 4 Maintenance Mount a new wiper cleaner. • Slide to the rear to attach it. Reattach the fitting. • Improper attachment may result in leaking maintenance solution. Once replacement is complete, close the cover, then press the [ENTER] key. Cap Replacement If ejection failures (e.g., nozzle clogging or deflection) remain unresolved even after cleaning, replace with a new cap.
Page 129 Chapter 4 Maintenance Select [Station Maint.] > [Replace Cap], then press the [ENTER] key. • The carriage moves over the platen. Open the maintenance cover on the right side. Remove the cap. • Squeeze the lugs on either side of the cap and pull off. [When using Sb ink and TP ink] Rinse the cap with the mesh side facing downward in a container filled with maintenance liquid.
Page 130: Replacing The Absorber Around The Station
Chapter 4 Maintenance Mount a new cap or a cap that has been washed. • Position with the slot at the front and push in until it clicks. Once replacement is complete, close the cover, then press the [ENTER] key. Replacing the Absorber Around the Station If the cap absorber or maintenance liquid absorber is very dirty or if ink drips on to the media, replace with a new cap absorber.
Page 131 Chapter 4 Maintenance Remove the maintenance liquid absorber. Wipe away any maintenance liquid from around the slider block. Mount a new maintenance liquid absorber. • Push firmly on to the protrusion. Check to confirm that the absorber is not lifting or curved. Once replacement is complete, close the cover, then press the [ENTER] key.
Page 132: Blowing Fan Filter Replacement
Chapter 4 Maintenance Blowing Fan Filter Replacement Replace the blowing fan filter if it is dirty. If sublimation transfer ink is used • Replace the filter every three months. • Turn off the main power and unplug the power cable before replacement. Remove the fan filter cover.
Page 133: Ink Supply Unit Ink Absorber Replacement
Chapter 4 Maintenance Ink Supply Unit Ink Absorber Replacement We recommend replacing the ink absorber each time you replace the ink pack, to prevent dirt building up on the pedestal of the ink supply unit. • Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when handling ink, maintenance liquid, waste ink, or other solutions used with the machine.
Page 134: Waste Ink Tank Replacement
Chapter 4 Maintenance Waste Ink Tank Replacement The ink used in printing and head cleaning is stored in the waste ink tanks on the right and left sides of the machine. • For a 2-liter tank, the preset level is 80 % (1.6 L). •...
Page 135: Washing Water Replacement
Chapter 4 Maintenance Hold the handle on the waste ink tank and slide out. Attach the cap to the removed waste ink tank, and use tape to prevent leakage of waste ink. • When disposing of ink, maintenance liquid or other liquid used with the product, or containers or non-woven fabric contaminated with ink or other liquid, contact an industrial waste disposal operator or dispose of the product in accordance with the local laws and regulations.
Page 136: Washing Unit Maintenance
Chapter 4 Maintenance Press the [ENTER] key. • Draining begins, as indicated by a message requesting you to wait. After a message indicates that draining is finished, close the valve. Press the [ENTER] key. • A message now asks if you wish to supply washing water. Press the [ENTER] key.
Page 137 Chapter 4 Maintenance Remove the feeding unit. • Remove any loaded media. • Remove the feeding unit from the machine and move it out of the way. • If a screen in local mode is displayed again because you accidentally held down the END key or opened a cover after removing the feeding unit, repeat the initial steps as follows.
Page 138 Chapter 4 Maintenance • If the feeding unit is attached incorrectly or the tension bar was not raised, the screen for attaching the feeding unit is displayed again. Press the ON/OFF button on the feeding unit. Press the [ENTER] key. •...
Page 139 Chapter 4 Maintenance Remove the absorption roller from the machine. • At least two people should remove the absorption roller. Rinse and then remove water from the absorption roller. (1) Remove the screws at each end with a screwdriver, then remove one sleeve at a time for cleaning.
Page 140: Reapplying Adhesive
Promptly reapply belt adhesive when a warning message advises to reapply it. • Genuine Mimaki adhesive is solvent-based. When applying adhesive, always wear a protective mask designed for working with organic solvents, as well as safety glasses and gloves.
Page 141: Peeling Off Adhesive
Chapter 4 Maintenance • The adhesive is not the cause if cloth media sags even before use and lifts up or sags after being applied to the feeding belt (with the pressure roller). Also note that this kind of media cannot be used.
Page 142 Chapter 4 Maintenance Press to select "BELT ADHESIVE," then press the [ENTER] key. Press to select "Peeling off adhesive," then press the [ENTER] key. After a message requests you to remove the media, make sure no cloth media is on the feeding belt, then press the [ENTER] key.
Page 143 Chapter 4 Maintenance After a message requests you to set the doctor, attach the doctor on the front of the machine. • Attach the doctor leaving a gap between it and the belt. (1) Loosen the doctor adjustment plates (at each end), move the point of attachment to the top, then tighten loosely.
Page 144 Chapter 4 Maintenance Press to set the feed speed, then press the [ENTER] key. • Setting value: 5 to 60 [mm/s] • 20 mm/s is recommended. Place a cloth soaked in kerosene along the inside of the doctor on the feeding belt. Press the [ENTER] key.
Page 145: Applying Adhesive
• Vinyl tape (2 cm wide) • Adhesive (Polixresin SX 1L, sold separately) • Genuine Mimaki adhesive is solvent-based. When applying adhesive, always wear a protective mask designed for working with organic solvents, as well as safety glasses and gloves.
Page 146 Chapter 4 Maintenance • When using a commercial adhesive, be sure to check the compatibility of the solvents it contains with the material that the belt is made of. In this case, contact your distributor or a sales office. • Be careful to avoid getting adhesive on the contact area of the belt correction unit (on the right in the front of the machine) and near the 6 mm dia.
Page 147 Chapter 4 Maintenance After a message requests you to set the doctor, attach the doctor on the front of the machine. • Attach the doctor without any gap between it and the belt. (1) Loosen the doctor adjustment plates (at each end), move the point of attachment to the top, then tighten loosely.
Page 148 Chapter 4 Maintenance Press to set the feed speed, then press the [ENTER] key. • Recommended value: 15 m/s Dribble 150 to 200 cc of adhesive evenly near the edge of the doctor. Press the [ENTER] key. • The feeding belt now moves. •...
Page 149 Chapter 4 Maintenance • After the level of adhesive no longer decreases, gradually increase the height of the doctor and apply a thicker coat. • Do not lower the doctor after raising it, which will result in uneven adhesive. Remove the doctor and wipe off any remaining adhesive or debris with kerosene/light oil and a waste cloth.
Page 150: Cleaning The Washing Tray And Brush
Chapter 4 Maintenance After a message about resetting the adhesive counter is displayed, press the [ENTER] key. • The adhesive counter is reset. • If, after drying, the adhesive is too strong, wipe the belt surface with a wet cloth to prepare it for use.
Page 151: Cleaning The Feeding Belt
Chapter 4 Maintenance Press the [ENTER] key and select "DRAIN WATER." • Display changes to the menu for draining the washing water. • If you have not used neutral detergent and do not need to drain the washing water, press the [END] key to finish tray cleaning.
Page 152: Cleaning The Peeling Sensors
Chapter 4 Maintenance • Before cleaning, be sure to remove any cloth media on the feeding belt. In local mode, press [FUNC1 (MENU)] > > [ENTER] key. • The Maintenance menu is displayed. Press to select [Belt Maintenance], then press the [ENTER] key. Press to select [BELT CLEANING], then press the [ENTER] key.
Page 153: Resetting The Counter
Chapter 4 Maintenance Dry the reflectors wiped in step 1 with a dry cotton swab. Wipe the three light-emitting surfaces of the peeling sensors with a cotton swab soaked in maintenance liquid. Dry the lenses wiped in step 3 with a dry cotton swab. Resetting the Counter Initialize counters for adhesive and the absorption roller as follows.
Page 154 Chapter 4 Maintenance...
Page 155: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting This chapter This chapter describes corrective actions for troubleshooting and messages on the display. Troubleshooting..........156 Problems Causing Messages to Appear ..1 60 The power does not turn on..... 156 Warning Messages ........1 60 Printing is not possible......156 Ink Error .............
Page 156: Troubleshooting
Chapter 5 Troubleshooting 5.1 Troubleshooting For information on troubleshooting, refer to this chapter. Refer to our website (https://mimaki.com/support/) for frequently asked questions (FAQs) about this product and customer support videos. If the recommended corrective action does not resolve the problem, contact your local dealer or our service office.
Page 157 Chapter 5 Troubleshooting Symptom Corrective action Perform the procedure described in "Feed Correction"(P. 84). Perform the procedure described in "Cap Rubber Cleaning"(P. 110). Perform the procedure described in "Carriage Underside Cleaning"(P. 111). Perform the procedure described in "Feed Correction"(P. 84). Text is double- or triple-printed in the media feed direction.
Page 158 Chapter 5 Troubleshooting Print Head Nozzle Washing If ejection failures (e.g., nozzle clogging or deflection) remain unresolved even after head cleaning ( "Head Cleaning"(P. 83)), apply nozzle wash to the print head. On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key. •...
Page 159: The Ink Has Leaked Out
Chapter 5 Troubleshooting The ink has leaked out • If an ink leak occurs, turn off the main power immediately and unplug the power cable. Then, contact your local dealer or our service office.
Page 160: Problems Causing Messages To Appear
Chapter 5 Troubleshooting 5.2 Problems Causing Messages to Appear If a problem arises, the buzzer sounds and a message appears on the display. You can also check the local guidance. "Displaying Machine Information (Local Guidance)"(P. 28) Take the appropriate action in accordance with the content of the message. If a message reappears even after taking the prescribed action, contact your local dealer or our service office.
Page 161 Chapter 5 Troubleshooting Message Cause Corrective action Turn off the main power and wait a while before turning back on. "Turning Off the Power"(P. 30) Replace Wasteinktank • The waste ink tank count Check the waste ink levels in the waste ink tank.
Page 162: Ink Error
Chapter 5 Troubleshooting Message Cause Corrective action Check Absorption Roller • It is time to check the • Clean the absorption roller. absorption roller water • Reset the absorption roller counter. level. "Resetting the Counter"(P. 153) Belt Adhesive 200 m Remain •...
Page 163: Error Message
Chapter 5 Troubleshooting Message Cause Corrective action Ink Type • The ink type registered on • Insert an ink IC chip for the correct ink the IC chip is different type. "Mounting the ink"(P. 41) from the ink type filled. Expiration Near •...
Page 164 RIP software. parameters that do not allow printing. Driver Version • Printing is not possible • Install the latest Mimaki driver because the Mimaki driver available from: version is old. https://mimaki.com/download/ inkjet.html PCB MAIN ET •...
Page 165 Chapter 5 Troubleshooting Error Message Cause Corrective action number USB INIT ERR • A problem was detected Check the USB cable connection. "Using a USB Cable"(P. 33) with the USB cable USB TIME OUT connection. Use a compatible cable. "Using a USB Cable"(P.
Page 166 Chapter 5 Troubleshooting Error Message Cause Corrective action number • If this message is displayed again, contact your local dealer or our service office. Peeling Unit Warn • Error during peeling Make sure that both edges of the media can be peeled off evenly. (sensor ON/OFF detected continuously).
Page 167 Chapter 5 Troubleshooting Error Message Cause Corrective action number Y Org Detect Error • A problem was detected with Y origin detection (initialization). L-SCALE BLACK • A problem was detected • Turn off the main power and wait a with the linear scale. while before turning back on.
Page 168 Chapter 5 Troubleshooting Error Message Cause Corrective action number (C) OPCODE • A problem was detected • Turn off the main power and wait a with the main PCB. while before turning back on. (C) SWI "Turning Off the Power"(P. 30) (C)PFTCHABRT (C)DATAABRT FW/SIO bit...
Page 169: System Halt
Chapter 5 Troubleshooting Error Message Cause Corrective action number HDCE* PCB V1R2 • A problem was detected • Turn off the main power and wait a with the HDCE PCB while before turning back on. HDCE* PCB V2R5 power supply. "Turning Off the Power"(P.
Page 170 Chapter 5 Troubleshooting...
Page 171: Chapter 6 Appendix
Chapter 6 Appendix This chapter This chapter describes the machine specifications. Specifications ..........172 Options ............1 75 Relay Box........... 1 75...
Page 172: Specifications
Chapter 6 Appendix 6.1 Specifications Item Tx330-1800B Print Type On-demand piezo head head Specifications Two staggered heads with 400 nozzles × 8 rows each Resoluti 300 dpi, 600 dpi 600 dpi, 900 dpi, 1,200 dpi, 1,800 dpi Ink Type Sb420, TP410...
Page 173 Chapter 6 Appendix Item Tx330-1800B Media heater NCU (Nozzle clogging Provided detection) DAS (Automatic correction Provided function) *5, 6 *6, 7 Interfac Data transfer Ethernet 1000BASE-T (recommended) , USB 2.0 Hi-speed function Command MRL-V Languages English, Japanese, Chinese, Turkish, Portuguese, Spanish, Italian, Korean...
Page 174 Chapter 6 Appendix Item Tx330-1800B 622 kg (848 kg) Weight *1. With setup menu margins set to the minimum (5 mm) on either side. *2. External diameter and weight after winding media. *3. Free of sagging due to weight. *4. Excluding media size variation and initial loading fluctuations.
Page 175: Options
2 specified as options. • The Tx330-1800B allows only one relay box (OPT-J0370 or OPT-J0407) to be connected. • The optional connection relay cable (OPT-J0512 drying fan connection kit) and the mounting bracket (OPT-01012 OPT-DsubBKT) are required when using a relay box.
Page 176 Chapter 6 Appendix...
Page 177 Index Index Adjust Waste Ink Volume .......................... 134 Air PG ................................ 98 Auto Cleaning .............................. 97 Auto Maint............................ 22, 96, 97 Auto Power-off.............................. 102 Auto Power-on.............................. 102 Auto Remote .............................. 102 Auto-correction (DAS) .......................... 94, 161 Blowing fan .............................. 132 Cancel ................................ 26 Cap ............................ 24, 109, 110, 128 Cap absorber.............................. 130 Cap Replacement............................ 96 Capping Use Days ............................ 105...
Page 178 Index [ENTER] key.............................. 26 Environment Setting Menu ........................... 103 Error................................ 26, 160 Error History .............................. 105 FCC .................................. 5 Feed Comp........................... 28, 45, 84, 94 Feed Speed .............................. 95 Feeding unit.............................. 23, 56 Front cover .............................. 22 [FUNCTION] key ............................ 26, 28 Function Setting Menu .......................... 101 Grit roller............................... 109 Head Cleaning.............................. 26 Head height .............................. 47 Heater................................ 25...
Page 179 Maintenance .............................. 105 Maintenance cover ............................ 22 Maintenance History............................. 105 Maintenance liquid absorber ........................ 130 Maintenance liquid cartridge .......................... 23 Maintenance Menu ............................ 96 MAPS (Mimaki Advanced Pass System) ....................... 94 Margin ................................ 102 Media................................ 51 Media cutter.............................. 22 Media feed.............................. 26 Media Information............................ 95 Media Name Change ............................. 95 Media Remain .............................. 95...
Page 180 Index Network ................................ 103 NOT-READY mode ............................ 27 Nozzle Check ............................... 100 Nozzle clogging ............................ 83, 100 Nozzle Deflection ............................ 83 Nozzle Recovery ............................ 96, 99 Nozzle Wash ............................ 96, 158 Operating Panel ............................ 22, 26 Option Roll Unit Select .......................... 101 PIN code............................... 104 Pinch roller .............................. 109 Power cable.............................. 29 Power outlet .............................. 29 Power plug .............................. 29...
Page 181 Index Station .............................. 22, 24 Station Maint.............................. 96 Status lamp .............................. 26 Switching hub .............................. 32 Symbol ................................ 7 SYSTEM HALT .............................. 26 Take-up unit ............................. 22, 52 Test Printing ............................ 26, 81, 96 Time Set ............................... 103 Top Blower .............................. 102 Torque limiter .............................. 54 Unit Setting .............................. 103 Usage ................................ 105 USB interface cable..........................
Page 182 MEMO...
Page 183 Operation manual March, 2025 MIMAKI ENGINEERING CO.,LTD. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 JAPAN D203884-10-17032025...

MIMAKI TX330-1800B Operation Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for MIMAKI TX330-1800B

Summary of Contents for MIMAKI TX330-1800B

Table of Contents
