5. Important Installation Information
accordance with BS 7671 (IET wiring regulations), building regulations, water regulations
accordance with BS EN 806.
• This shower unit is designed to be
connected to a 15mm cold water mains
supply.
• To make sure the heating elements are
activated the shower must be connected
to mains water supply with a minimum
static pressure of 0.1MPa (15lb/sq in) – 1
minute. The maximum static pressure is
1MPa (145lb/sq in) 10 bar.
•
may be exposed to frost, for example, in an
outdoor area. The shower must not be used
if suspected of being frozen. Frost damage
is not covered by the guarantee.
6. Fixing The Shower To The Wall
• Position your shower on a FLAT section of wall,
ensuring that it will NOT be in the direct water spray
• The shower unit should be positioned so that the
shower handset cannot be immersed in the bath or
shower tray when hanging down.
•
cover off complete with the control knobs and start /
stop push button.
1. Having decided on the water and cable entry
shower vertically against the wall and mark the
is square.
2. Carefully drill the two holes as marked using
certain there are no pipes or wires behind the
proposed holes.
3. Insert the wall plugs and screws provided
leaving the screw head proud by approximately
5mm. The shower can now be hung on these
screws.
4. Make sure that the shower is positioned
vertically and square, now mark and drill the
the wall. Do not fully tighten the screws at this
stage
5. The shower back plate and removable corner
mouldings have moulded cut out sections which
are clearly indicated to allow the chosen service
6
• Plumbers jointing compound must not
use P.T.F.E. Tape. The use of jointing
compound will invalidate the product
guarantee.
•
as heat can travel along pipe work and
damage components.
• Do complete all plumbing connections
before making the electrical connections.
NOTE: For the 9.5 & 10.5kW model, the
minimum running pressure must be obtained
at 9 L/min.
NOTE: The bottom screw should only be
IMPORTANT
TIPS
