11. Riser Rail Fitting Instructions
1. Establish position for the riser rail, and
mark the wall for the lower mounting
bracket. Make allowances for the tallest
person likely to use the shower regularly.
2. Remove covers from the wall brackets.
3. Position the top bracket and mark the wall
4. Fit the rail into the top bracket. Place the
remaining bracket onto the rail. Ensure
the rail is vertically aligned and mark the
wall. Remove the rail and bracket, then
drill and plug the wall.
5. Slide the height adjuster onto the rail,
release mechanism with push button.
will make it easier to slide on.
6. Replace the rail assembly into the top
the larger rail hole is facing outwards and
7. Snap covers over both brackets.
8. Firmly attach shorter conical end of
passing through the hose retaining ring
with no kinks.
NOTE: The adjustable height adjuster
grips the conical ends of the hose, not the
handle of the shower handset.
Check there are no hidden cables or pipes before drilling holes for wall plugs.
The use of a residual current device (RCD) is recommended.
Exercise great care when using power tools near water.
CAUTION
1
3
5
7
Short
end
TIPS
2
4
6
8
