TKO 8060FT Owner's Manual

Functional trainer
Hide thumbs

Advertisement

Quick Links

Download this manual
Functional Trainer
Model 8060FT
M
10.2023
www.tkostrength.com
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8060FT and is the answer not in the manual?

Questions and answers

Related Manuals for TKO 8060FT

Summary of Contents for TKO 8060FT

  • Page 1 Functional Trainer Model 8060FT 10.2023 www.tkostrength.com...
  • Page 2 Safety Read this owner’s manual carefully before assembling or using TKO equipment. WARNING: Serious injury could occur if these safety precautions are not observed. Safety Precautions • Before beginning any exercise program, consult your physician. Evaluate your present fitness level and determine the exercise program most appropriate for your particular age and condition.

  • Page 3: Product Diagram

    Product Diagram...

  • Page 4: Exploded Diagram

    Exploded Diagram...

  • Page 5: Parts List

    Parts List Description Description Rear Upright Frame Top Weight 247*65*25.4 Right Base Frame Weight Stack 260*100*25.40 End Cap Φ34.5*Φ6.5*25 Left Base Frame Pulley Φ89*26.20 Right Upper Cross Frame Cushion Φ55*Φ20.5*75 Left Upper Cross Frame Upper Cross Frame Pad 70*70*10 Double Pulley Frame Cushion 30*70*20 Pad Φ56*Φ20.5*5 Hook Frame...
  • Page 6 Assembly Note: Before starting assembly, remove all parts and hardware from the carton, ensure you have everything according to the list. Step 1 Connect Rear Upper Frame (1), Right Base Frame (2), and Left Base Frame (3), using 6 Hex Bolt M12*30 (83),12 Flat Washer Φ13.5*Φ24*2.5 (87) and 6 Nut M12 (94).
  • Page 7 Assembly Step 2 Install 4 Support for Weight Stack (28), 4 Cushion Ø55*Ø20.5*75 (53) and 4 Guide Rod (19) onto the machine as the picture shown; Please ignore 4 Support for Weight Stack (28) if the user need 20 pieces of weight stack.
  • Page 8 Assembly Step 3 Install the Weight Stack (50), Top Weight (47) &(49) onto 2 Guide Rod, and then use 4 Hex Bolt M10*35 (80),4 Flat Washer Ø11*Ø20*2 (86) and 4 Spring Washer Ø 10 (90) to fix them. Please tighten the bolts.
  • Page 9 Assembly Step 4 Remove Limit Plate 65*30*80*4 (46) from Right Slide Frame (30); Install Limit Plate 65*30*80*4 (46) and Right Slide Frame (30) onto Left Base Frame (3), using 2 Hex Bolt M10*70 (75)，4 Flat Washer Ø11*Ø20*2 (86) and 2 Nut M10 (93)； Connect the rear of Left Upper Cross Frame (5) with the Back Upright Frame, using 2 Hex Bolt M12*30 (83), 4 Flat Washer Φ13.5*Φ24*2.5 (87) and 2 Nut M12(94);...
  • Page 10 Assembly Step 5 Install Right Slide Frame (29) in the same way; Connect Right Upper Cross Frame (4) and Left Upper Cross Frame (5), using 2 Hex Bolt M12*30 (83), 4 Flat Washer Φ13.5*Φ24*2.5 (87) and 2 Nut M12 (94). Please do not tighten the nuts for this step.
  • Page 11 Assembly Step 6 Install 2 Fixing Plates (10) onto the machine, using 8 Hex Bolt M10*20 (81), 8 Flat Washer Φ11*Φ20*2 (86) and 8 Spring Washer Φ10 (90). Please don’ t tighten the A1 position bolts and make sure there is 3- 5mm space.
  • Page 12 Assembly Step 6(2) Take the left side for example, install the Cable (24) as the picture shows. Please remove the pulley if necessary. Then, put the pulley back when the Cable is installed. Install the right side cable in the same way.
  • Page 13 Assembly...
  • Page 14 Assembly Step 7 Install Upper Cross Frame With Chin Bar Handles (6) onto Right Upper Cross Frame (4) and Left Upper Cross Frame (5), using 4 Hex Bolt M12*35 (84), 8 Flat Washer Φ13.5*Φ24*2.5 (87) and 4 Nut M12 (94). Please don’t tighten the Nut；...
  • Page 15 Assembly Step 8 Install these parts onto the Front Side Shroud (17), as the picture shows. Please provide their direction when installing; After finishing, please set it aside for later use.
  • Page 16 Assembly Step 9 Install the other side shroud in the same way.
  • Page 17 Assembly Step 10 Flat Washer Φ11*Φ20*2 Spring Washer Φ10 Remove 2 M10*30 (79), 2 (86), and 2 (90) from Handle Hex Bolt Frame (9) as the picture shows; After finishing, please set it aside for later use.
  • Page 18 Assembly Step 11 Install these parts onto the Front Shroud (14), as the picture shows. Please attend the shroud and Hook Frame’s direction when installing; After finishing, please set it aside for later use.
  • Page 19 Assembly Step 12 Please pull multiple times Adjustable Handle (23) to make the pulley of the top weight up to the highest. If it don’t smooth, please put on some silicone oil on the guid rod. Pull Adjustable Handle (23) again until it is smooth.
  • Page 20 Assembly Step 13 Install Front shroud (14) onto Fixing Plate (10), using 4 Hex Pan Bolt M6*20 (64), 4 Flat Washer Φ6.6*Φ12*1.6 (85) and 4 Spring Washer Φ6 (89); Please don’t tighten the bolt and make sure there is 3-5mm space.
  • Page 21 Assembly Step 14 Install Front Side Shroud (17) onto Front shroud (14) and Right Rear Shroud (16), using 14 Hex Pan Bolt M6*20 (64), 14 Flat Washer Φ6.6*Φ12*1.6 (85) and 14 Spring Washer Φ6 (89); Please don’t tighten the bolt and make sure there is 3-5mm space.
  • Page 22 Assembly Step 15 Install Front Side Shroud (17) onto Front shroud (14) and Left Rear Shroud(15), using 14 Hex Pan Bolt M6*20 (64), 14 Flat Washer Φ6.6*Φ12*1.6 (85) and 14 Spring Washer Φ6 (89); Please don’t tighten the bolt and make sure there is 3-5mm space.
  • Page 23 Assembly Step 16 Please make sure all the shroud bolts are in the right postion; Please tighten the Bolt M10*20 (81) in the postion A1 and A2; Please tighten all the bolts of the Front Shroud (14); Please tighten all the bolts of the Light Rear Shroud (15) and Left Rear Shroud (16); Please tighten all the bolts of the 2 Front Side Shroud (17).
