TasmanEco Archie Cot Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Assembly Instructions: Archie Cot
IMPORTANT
DO NOT OVER-TIGHTEN SCREWS.
Tighten all screws and connectors by hand,
not power tools.
Read all instructions before assembly and use of product.
Two people are recommended to complete assembly.
Save these instructions for future use.
Tasman Eco Pty Ltd | ABN: 58 106 988 578
tasmaneco.com.au
Address: 580 Hume Highway, Casula,
services@tasmaneco.com.au
2170, NSW
@tasmaneco
We use recycalable materials for
(02) 9603 5000
our instructions and packaging.
(02@ 9603 5000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Archie Cot and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TasmanEco Archie Cot

Summary of Contents for TasmanEco Archie Cot

  • Page 1 Assembly Instructions: Archie Cot IMPORTANT DO NOT OVER-TIGHTEN SCREWS. Tighten all screws and connectors by hand, not power tools. Read all instructions before assembly and use of product. Two people are recommended to complete assembly. Save these instructions for future use.

  • Page 2: Cleaning And Care

    Regularly check your connector bolts, ensuring they are tight, and regularly check the cot for any weakness in the joints and panels. If you have any concerns report them immediately to Tasman Eco (services@tasmaneco.com.au). Do not use the cot if it has been damaged in any way.

  • Page 3: Parts List

    Parts List HEADBOARDS x 2 LEGS x 2 BASE SIDE x 2 COT BASE x 1 COT SIDE x 2 Hardware List M6x12MM SCREW X 22 M6x20MM SCREW x 10 M6x25MM SCREW x 10 FRAME SCREW BASE LOWER POSITION BASE UPPER POSTION UPPER MATRESS POSTION ALLEN KEY x 1 SPACER x 10...
  • Page 4 Assembly STEP 1: Lay on a flat clean surface with the legs facing up (the items will be upside down. Using 8 of the 12mm screws (shortest ones) assemble the base structure. IMPORTANT: Start screwing the screws in by hand and then use the allen key. This swill stop you cross threading the screws.
  • Page 5 Assembly (continued...) STEP 2: Connect the headboards using 6 of the 12mm bolts (shortest ones). The headboards will slot into the dedicated grooves. IMPORTANT: Start screwing the screws in by hand and then use the allen key. This swill stop you cross threading the screws.
  • Page 6 Assembly (continued...) STEP 3: Attach the cot side panels using the remaining 8 12mm screws (the shortest screws). IMPORTANT: Start screwing the screws in by hand and then use the allen key. This swill stop you cross threading the screws.
  • Page 7 Assembly (continued...) STEP 4: The below instructions are for setting up at bassinet height, if you prefer to set up at cot height skip to the next step. The upper base position used the 25mm screws (longest). IMPORTANT: Start screwing the screws in by hand and then use the allen key. This swill stop you cross threading the screws.
  • Page 8 Assembly (continued...) STEP 5: The below instructions are for setting up at cot height, if you prefer to set up at bassinet height see step 4. The lower base position used the 20mm screws. IMPORTANT: Start screwing the screws in by hand and then use the allen key. This swill stop you cross threading the screws.

  • Page 9: Product Guarantee

    To be eligible for the above guarantee, the original owner must register their details online at www.tasmaneco.com.au immediately upon receipt of the product. The product must be returned to Tasman Eco Pty Ltd or to the place of purchase with proof of purchase,...

Table of Contents
