Assembly Instructions:
Willow Toy Box
IMPORTANT
DO NOT OVER-TIGHTEN SCREWS.
Tighten all screws and connectors by hand,
not power tools.
Read all instructions before assembly and use of product.
Recommended that two people complete this assembly.
Save these instructions for future use.
Tasman Eco Pty Ltd
tasmaneco.com.au
ABN: 58 106 988 578
services@tasmaneco.com.au
Address: 4-6 Merryvale Road, Minto NSW
@tasmaneco
We use recycled materials for our
(02) 9603 5000
instructions and packaging.
(02@ 9603 5000
Advertisement
Related Manuals for TasmanEco Willow Toy Box
Summary of Contents for TasmanEco Willow Toy Box
- Page 1 Assembly Instructions: Willow Toy Box IMPORTANT DO NOT OVER-TIGHTEN SCREWS. Tighten all screws and connectors by hand, not power tools. Read all instructions before assembly and use of product. Recommended that two people complete this assembly. Save these instructions for future use.
- Page 2 Safety Considerations - Child Follow manufacturer's assembly instructions in detail, ensuring safety features are not compromised. ENSURE THE TOY BOX IS NOT POSITIONED TOO CLOSE TO HEATERS, BLINDS, CURTAINS, WINDOWS OR POWERPOINTS. DO NOT KEEP ITEMS NEARBY WHERE THERE IS DANGER OF THE ITEM FALLING INTO THE TOY BOX.
-
Page 3: Parts List
Parts List Top Panel + Rear Panel x 1 Front Panel x 1 Side Panels x 2 Bottom Panel x 1 Toy Box Legs x 4 Hardware List Soft Close Strut x 1 Strut Screw x 1 Locking Pins x 18 Cam Locks x 18 Allen Key x 1 WARNING... - Page 4 Assembly STEP 1: Screw 12 x locking pins into place on both of the side panels. Locking Pins x 12 STEP 2: Screw the 4 x legs into the base by turning these clockwise. Turn the base over so it is standing on the legs and then screw in 6 x locking pins, using the images below as a reference.
- Page 5 Assembly (continued...) STEP 3: Connect the front, rear and 1 x side panel, using the locking pins to connect them in place, then use your cam locks to lock them into place. Cam Locks x 6 STEP 4: Now, connect the other side panel to the front and rear panels, locking them into place using your cam locks.
- Page 6 Assembly (continued...) STEP 5: Connect the toy box base to the already assembled toy box frame, lock this into place using your cam locks. Cam Locks x 6 STEP 6: Screw in your soft close strut to your toy box, following the image below. Lock it into place using the strut screw, also pictured below.
-
Page 7: Product Guarantee
To be eligible for the above guarantee, the original owner must register their details online at www.tasmaneco.com.au immediately upon receipt of the product. The product must be returned to Tasman Eco Pty Ltd or to the place of purchase with proof of purchase,...
