BYD BATTERY-BOX PREMIUM QUICK START GUIDE
Valid for HVS 5.1/ 7.7/ 10.2/ 12.8
HVM 8.3/ 11.0/ 13.8/ 16.6/ 19.2/ 22.1
Please note that this is a Quick Start Guide only, which is a shortened assistance for the installation of the BYD Battery-Box Premium
HVS/HVM. It does not replace the Operating Manual, which must be read and understood completely before installation. Please
download and view it on this website: www.bydbatterybox.com.
Attention: High Voltage! Improper handling can pose a risk of electric shock and damage.
This guide and procedures described herein are intended for use by skilled workers only.
A skilled worker is defined as a trained and qualified electrician or installer who has all of the following skills and experience:
• Knowledge of the functional principles and operation of on-grid systems.
• Knowledge of the dangers and risks associated with installing and using electrical devices and acceptable mitigation methods.
• Knowledge of the installation of electrical devices.
• Knowledge of and adherence to this guide, the complete installation manual and all safety precautions and best practices.
In order to ensure the normal operation of the BYD Battery System, please download the app Be Connect 2.0 and then finish the
configuration in accordance with this document.
If there are errors generated during the commissioning or operation, please read the Service Guideline and Checklist alongside this
document, or digital version on the website.
If the battery system doesn't start at all, please contact BYD's local after-sales service team within 48 hours. Otherwise, the battery
could be permanently damaged.
Please do not stack up batteries without protective packages when storing or handling batteries, except for installation.
Be Connect 2.0
Be Connect 2.0
Google Play
APP Store
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BYD BATTERY-BOX PREMIUM HVS 5.1
Summary of Contents for BYD BATTERY-BOX PREMIUM HVS 5.1
- Page 1 HVM 8.3/ 11.0/ 13.8/ 16.6/ 19.2/ 22.1 Please note that this is a Quick Start Guide only, which is a shortened assistance for the installation of the BYD Battery-Box Premium HVS/HVM. It does not replace the Operating Manual, which must be read and understood completely before installation. Please download and view it on this website: www.bydbatterybox.com.
-
Page 3: Scope Of Delivery
1. Scope of Delivery 1 2 3 4 5 6 7 8 Base M4x14 Countersunk Female Power Male Power Terminal Resistor HVS Module HVM Module Screw Cable Coupler Cable Coupler Hanger (BCU Part) Documents Hanger (Wall Part) M5 Screw M6 Bolt and Nut Communication M4x14 Countersunk Connector... -
Page 4: Installation Location
3. Tools Network Wire Clamp Marker Phillips Screwdriver Bit Torque Wrench Flat-head Screwdriver Wire Stripper Hydraulic Plier Wrench Tape Measure Drill Heat Gun Cylinder Screwdriver Connector Wrench Rubber Mallet Crimping Pliers 4. Installation Location Max +50 °C Min -10 °C RH. - Page 5 5. Connection Limitation 2 ≤ N ≤ 5 3 ≤ N ≤ 8...
- Page 6 INVERTER INVERTER M = N L = M = N L ≠ M or l ≠ N or M ≠ N INVERTER INVERTER INVERTER ≤ 3 (Towers)
-
Page 7: Installation
9) HVM 19.3 10) HVM 22.1 1) 160-240 2) 240-360 3) 320-480 4) 400-600 5) 120-177 6) 160-236 7) 200-295 8) 240-354 9) 280-413 10) 320-472 -10°C~ 50°C Shenzhen BYD Electronics Co., Ltd. e.g., HVS XX 10 mm 8 Nm... -
Page 8: Connection Diagram
7. Connection Diagram Single Tower INVERTER BAT COM Port for an inverter data cable IN port for parallel tower connection PE Cable OUT OUT port for parallel tower connection DC Cable Network port for connecting a router or network switch Grounding cable connecting point DC- to inverter Data Cable... - Page 9 Multiple Towers (Ignore the Slave 1 in the drawing below to get the diagram of two towers) INVERTER NOTICE 1.Parallel connection is not applicable to SMA Sunny Boy Storage 3.7-6.0. Please check the inverter's operating manual on how to connect up to three battery systems.
-
Page 10: Electrical Connections
8. Electrical Connections NOTE: Before making all electrical connections, please make sure the air switch on the BCU is o . 8.1 PE Connection 8.2 DC Connection 8-10 mm L = E + (2~3) mm SC10 - 5 S = 6-10 mm² Click Elastic piece Thin-walled side... - Page 11 8.3 Connecting the Data Cable to an Inverter NOTICE e.g., CAN L Option a e.g., CAN H The connection diagram with di erent inverters could be INVERTER read in the section 13. Option b e.g., Min. CAT5 Max. 20m 8.4 Connecting the Data Cable to a Router (It's not mandatory, but recommended) T568B Min.
- Page 12 Saved,encrypted with the privacy policy and protect your personal information security. After you agree the policy, we will initialize the SDK WLAN: BYD-XXXX BYD-XXXX and collect your device information (such as device_id, MCC, MNC, etc.). You can Saved,encrypted...
- Page 13 Skip When adding modules, make sure the SOC of the existing tower is similar to the SOC of the extension module (normally about 30%) Configuration was done according to BYD Battery-Box Configuration/ Compatible Inverter List and Operating Manual. Next Next...
-
Page 14: Led Status
11. Extension Note: Within 5 days before extension, it is recommended to fully charge the original system to SOC 100% at least once. Voltage = X New Battery Original Battery Voltage (X)/ V SOC (Y) SOC ≈ Y SOC ≈ Y X<100.80 0~5% 100.80≤X<103.20... - Page 15 13. Communication Options with Inverters SMA SBS 2.5/ 3.7/ 5.0/ 6.0 NOTICE Designation of "INV" port Battery-Box Parallel connection is not applicable to SMA Sunny Battery-Box Boy Storage 3.7-6.0. Please 12345678 check the inverter Operating Manual on how to connect up to three batter y systems.
- Page 16 Kaco NH SUNGROW SH5.0_6.0_8.0_10RT SUNGROW SH3.0/ 3.6/ 4.0/ 5.0/ 6.0 RS BATTERY RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-2 Terminal-3 COM0 RJ45-2 LOAD Terminal-4 Battery-Box SUNGROW Kaco NH RJ45-1 RJ45-3 RJ45-5 Terminal-1 Terminal-2 Battery-Box SUNGROW Terminal-3 SUNGROW Terminal-4 Battery-Box Battery-Box Kaco NH Battery-Box Battery-Box Kaco NH...
- Page 17 GE GEH 5.0/ 8.6/ 10-1U-10 Solplanet Western CO HHS 3000-6000/ HBS 3000-6000 Solplanet Western BATTERY RJ45-1 RJ45-3 RJ45-5 RJ45-1 RJ45-3 RJ45-5 GRID Terminal-1 Terminal-1 Terminal-2 COM0 Terminal-3 RJ45-2 LOAD Terminal-4 Terminal-2 Terminal-3 Terminal-4 Battery-Box Battery-Box Western Battery-Box Solplanet Battery-Box 1 2 3 4 5 6 7 8 Battery-Box Battery-Box Solplanet...
- Page 18 Maxhub PHN(5-10)KT-BH2 Kontron SolBrid 10-3-2/10-3-4 Maxhub Battery-Box Battery-Box Kontron Kontron Battery-Box 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Battery-Box Maxhub Cable Length≤ 20m Cable Length≤...
- Page 19 WLAN name, password and serial number.
- Page 20 + 49 9352 8523999 / +44 (0) 2037695998(UK) + 61 2 8005 6688 + 86 755 89888888-47175 +34 91 060 22 67(ES) / +39 02 87368364(IT) No.3009, BYD Road, Pingshan, Shenzhen, 2/62 Belmore Road, Riverwood, NSW 2210 Bruchtannenstr. 28, 63801 Kleinostheim, Germany 518118, P. R. China www.eft-systems.de...
