Related Manuals for jurop C 60

Summary of Contents for jurop C 60

  • Page 1 C 60-84-110 Rev. 07 29-07-2021...
  • Page 2 2021 – Jurop – Azzano Decimo (PN) Reproduction, electronic storage and dissemination, even partial, are prohibited. Jurop reserves the right to modify the products described in this manual without prior notice. Any product names mentioned herein are the trademarks of their respective owners.

  • Page 3: Table Of Contents

    Extraordinary maintenance Malfunctions: pag. troubleshooting Scrapping pag. – SPARE PART DATA SHEET C 60-84-110 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 3 / 20 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)

  • Page 4: General Warnings

    • Compressor has to be fitted with its own tag reporting the following data: Model, Serial number, Year, Max speed, Max pressure. Pic. 1.1 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...

  • Page 5: Technical Data

    (B). • The one which is not used could be used with an overpressure safety valve (Pic. 2.1). Pic. 2.2 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 5 / 20 e-mail: info@jurop.it...
  • Page 6 . 07 – INSTALLATION USE AND MAINTENANCE MANUAL C60-84-110 29-07-2021 C with gearbox [mm] C 60 G 2” C 84 G 2” G 2” C 110 G 2 ½” G 2 ½” C84 with hydraulic motor Jurop SpA . +39 0434 636811 F .

  • Page 7: Performances

    ISO VG 150 Biodegradable Heavy Service MAX 180°C JUROP lubricant recommended for vane pumps (cod. 40461EHB06) synthetic oil Light Service causes discharge temperatures below 150°C (low ambient temperature, use for short periods) Heavy Service causes discharge temperatures between 150°C and 180°C (ambient temperature above 20°C, frequent use)

  • Page 8: Safety And Accident Prevention

    (outdoor or be damage and the operator may be injured. indoor). • Please contact JUROP’s Technical dept. if necessary. Do not exceed the power supply parameters indicated in the technical tables (see par. 2.2-2.4). • Based on the final use of the compressor, the insertion in the...

  • Page 9: Installation

     Equal working angle α and α1 of both couplings; • Before each movement, verify that the lifting equipment has a  The internal fork joints must be coplanar; suitable capacity. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...
  • Page 10 HDR motor Safety valve * optional components • Filtration: class 19/16 contamination according to ISO 4406 to be obtained with a ßx = 75 filter. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 10 / 20 e-mail: info@jurop.it...

  • Page 11: Precautions When Starting The System

     Stop the compressor;  Restart operation only after it has cooled down. • Do not operate the pump without lubrication: it may cause quick wear and possible breakdown of vanes. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...

  • Page 12: Maintenance

    Checking the vanes wear • Use lubricants that are of good quality and with the characteristics recommended by JUROP in relation to the operating temperatures. • Unscrew the vanes wear check-plug on the front flange (Fig. 6.2). • Turn the shaft by hand until vanes appearance.

  • Page 13: Extraordinary Maintenance

    • Hold the shaft before extracting the flange: the rotor weight must when the machine is cold, stopped and switched off. Implement the not solicit the internal components. • Extract the worn vanes. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n°...
  • Page 14 Mounting the hydraulic drive • We recommend the drive coupling be oiled when vanes are being replaced. • However lubricate the drive coupling every 1500 hours. Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 14 / 20 e-mail: info@jurop.it...

  • Page 15: Malfunctions: Troubleshooting

    • Before scrapping the machine, the following materials need to be separated and suitably disposed of. Material Cast Iron Steel Alluminum Copper Bronze Rubber Vane Plastic C 60 85 % 12 % 0.2 % 0.4 % 0.1 % 0.1 % 0.7 % 0.7 % 0.5 % C 84...

  • Page 16: Spare Part Data Sheet - C60-84-110

    . 07 – SPARE PART DATA SHEET C60-84-110 29-07-2021 C 60-84-110 PICTURE SHOWS C 84 A663200510 WITH GEARBOX C 84 E668100510 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 16 / 20 e-mail: info@jurop.it...

  • Page 17: Tel . +39 0434 636811 Fax

    . 07 – 29-07-2021 SPARE PART DATA SHEET C60-84-110 C 60-84-110 Pos. Code Description Q.ty Pos. Code Description Q.ty 1401200400 OILER C60 4026305614 NUT WITH FLANGE 1401200400 OILER C84-110 4026308006 NUT M10 (C84) 1407200500 OIL PUMP PN45-106 4026308007 NUT M12 (C60-110)
  • Page 18 . 07 29-07-2021 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 18 / 20 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 19 . 07 29-07-2021 Jurop SpA . +39 0434 636811 F . +39 0434 636812 http://www.jurop.it Via Crosera n° 50 19 / 20 e-mail: info@jurop.it 33082 Azzano Decimo, PN (Italia)
  • Page 20 29-07-2021 U.T. A.T. Jurop SpA Via Crosera, 50 33082 Azzano Decimo, PN (ITALY) Tel. +39 0434 636811 Fax. +39 0434 636812 http://www.jurop.it e-mail: info@jurop.it Jurop SpA reserves the right to modify the products described in this manual without prior notice.

This manual is also suitable for:

C 84C 84 hdrC 110
