Aries 2055102 Installation Manual

INSTALLATION MANUAL
Level of Difficulty
Easy
Installation difficulty levels are based on time
and effort involved and may vary depending on
the installer level of expertise, condition of the
vehicle and proper tools and equipment.
This is the first of two manuals
required to complete this installation.
The second manual is included with
your running boards / side steps.
Parts List
6 VersaTrac mounting bracket, universal
™
2 VersaTrac mounting bracket,
™
passenger / right, front, upper
2 VersaTrac mounting bracket,
™
passenger / right, front, lower
14 Clip nut, M8*
30 Hex bolt, M8 - 1.25 x 25mm (B)
30 Lock washer, M8 (B)
30 Flat washer, M8 (B)
16 Hex nut, M8 (B)
2 Hex bolt, M10 - 1.50 x 30mm (B)
2 Lock washer, M10
2 Flat washer, M10
* Depending on the year of the vehicle,
clip nuts may or may not be needed.
(B) = Black hardware
Running boards / side steps sold separately
Tools Required
Ratchet Socket set
Torque wrench Socket extension
Level --
Torque Specifications
M6 bolt 3 ft-lbs.
M8 bolt 7 ft-lbs.
M10 bolt 16 ft-lbs.
M12 bolt 28 ft-lbs.
1/4" bolt 3 ft-lbs.
5/16" bolt 7 ft-lbs.
3/8" bolt 16 ft-lbs.
7/16" bolt 20 ft-lbs.
1/2" bolt 28 ft-lbs.
Use above torque setting unless otherwise noted
ARIESAUTOMOTIVE.COM
Product Photo
Upper
Lower
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive
cleaners, abrasive pads, wire brushes or other similar products that may damage the finish.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Product Registration and Warranty
ARIES stands behind our products with industry-leading warranties. To get copies of the product
warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys
• PRODUCT SUPPORT: 877.287.8634
Upper
Lower
• 2055102-INS-RF • 03/20/2023
2055102
Front
• ECN10606 • PAGE 1
Rear
