UG-1766
ORDERING INFORMATION
BILL OF MATERIALS
Table 5.
Qty Reference Designator
4 C1, C6, C18, C25
2 C11, C12
2 C2, C4
1 C21
1 C22
1 C23
1 C3
2 C8, C33
1 C34
1 C35
1 C36
1 C5
1 EXTSUP
1 L1
1 PWR_SEL
3 GAIN_SEL,REFSUP_SEL,VDD_SEL
2 P2, P3
1 R13
8 R4, R8, R14, R16, R41, R42, R43, R44
2 R2, R3
1 R35
2 R36, R47
1 R40
1 R45
1 R46
1 REF
1 SDP
1 TP1
1 TP2
1 EXT_REF
1 U1
1 U2
1 U3
1 U4
1 U5
1
FEC refers to Farnell Electronic Component Distributors.
2
Generic indicates that any device with the specified value, size, and rating can be used.
Description
Ceramic capacitors, 0.1 μF, 16 V, X7R, 0402
Ceramic capacitors, 4.7 μF, 10 V, X7R, 0805
Ceramic capacitors, 10 μF, 10 V, X5R, 0603
Ceramic capacitor, 68 pF, 50 V, NP0, 0402
Ceramic capacitor, 15 pF, 50 V, C0G, 0402
Ceramic capacitor, 22 μF, 25 V, X5R, 1206
Tantalum capacitor, 10 μF, 16 V, 1411
Ceramic capacitors, 1 μF, 10 V, X7R, 0603
Ceramic capacitors, 10 μF, 25 V, X5R, 0603
Ceramic capacitors, 0.1 μF, 25 V, X5R, 0402
Ceramic capacitors, 1 μF, 25 V, X5R, 0402
Ceramic capacitor, 10 μF, 25 V, X5R, 0805
Terminal block, 5.08 mm pitch
Inductor, 4.7 μH, 5 A, 57.4 mΩ direct current resistance (DCR)
3-pin male header, 2.54 mm pitch
6-pin male headers, 2.54 mm pitch
16-pin male headers, 2.54 mm pitch
Resistor, SMD, 0 Ω, 1%, 1/10 W, 0603, thick film
Resistors, SMD, 0 Ω, 1/16 W, 0603, thick film
Resistors, SMD, 100 kΩ, 5%, 1/10 W, 0603, thick film
Resistor, SMD, 100 kΩ, 1%, 1/5 W, 0402, thick film
Resistors, SMD, 150 kΩ, 1%, 1/10 W, 0402, thick film
Resistor, SMD, 0 Ω, 1/10 W, 0805, thick film
Resistor, SMD, 21.5 kΩ, 1%, 1/10 W, 0402, thick film
Resistor, SMD, 1.1 MΩ, 1%, 1/16 W, 0402, thick film
3-pin male header, 2.54 mm pitch
SDP connector
Test point, black
Test point, red
Subminiature Version B (SMB) connector
2
32 kΩ, I C electronically erasable programmable read-only
memory (EEPROM)
1 A low noise, buck-boost dc-to-dc converter
16-channel, 16-Bit, nanoDAC+
Ultralow noise, 200 mA linear regulator
Ultralow noise, high accuracy voltage reference
Rev. 0 | Page 12 of 13
EVAL-AD5677RSDZ
Supplier/Part Number
GRM155R71C104KA88D
C2012X7R1A475M085AC
GRM188R61A106KE69D
GCM1555C1H680JA16D
CGA2B2C0G1H150J050BA
CL31A226KAHNNNE
TAJB106K016RNJ
CL10B105KP8NNNC
GRT188R61E106ME13D
TMK105BJ104KV-F
GRM155R61E105MA12D
GRM21BR61E106KA73L
OSTTC022162
XFL4020-472MEB
M20-9990345
TSW-103-08-G-D
67996-416HLF
CRCW0603000ZRT1
MC0603WG00000T5E-TC
RC0603JR-07100KL
ERJ-PA2F1003X
ERJ-2RKF1503X
MC 0.1W 0805 0R
ERJ-2RKF2152X
AC0402FR-071M1L
YMC03SAAN
FX8-120S-SV(21)
20-2137
20-313137
1-1337482-0
24LC32A-I/ST
LTC3536EDD#PBF
AD5677RBCPZ-1
ADM7160ACPZN3.3-R7
ADR4525BRZ
User Guide
1, 2
