Bison OL89QC Installation And Use Manual

—— Installation and Safe Use Manual ——
Customer Service
(800) 247 7668
P A R T S L I S T
Item Qty Description
A 1 Extension Arm Assembly
B 2 4" Square U-Bolt
C 4 1/2" Flat Washers
D 4 1/2" Lock Washers
E 4 1/2" Hex Nuts
F 2 Upper Backboard Supports
G 2 Lower Backboard Supports
H 4 Backboard Mounting Angles
I 8 5/16" x 1" Hex Bolts
J 8 5/16" Flange Nuts
K 1 Pole Cap
L 1 Acrylic Backboard (packaged separately)
M 1 Acrylic Hardware (packaged with backboard)
Improper installation, maintenance or use may cause product failure and serious personal injury.
¨ Inspect all contents prior to installation. Report any missing parts to dealer immediately.
¨ Carefully read all instructions before proceeding. Pay special attention to the safety instructions on page 4.
¨ Save this instruction in the event that the manufacture must be contacted in the future for maintenance information.
1. Call your local utility locating service before digging, usually by dialing 811, to avoid serious injury or
service interruptions. Also avoid lawn sprinkler lines.
2. Determine the desired position of the pole assembly by taking into consideration that the distance between
the front of the pole assembly and the face of the Acrylic Backboard (L) changes as the Rim (N) height is
adjusted. At the top position (official 10' height) the distance is 22 1/2", at the lowest position the distance
is 28" and at middle heights the distance is 30" to 31". See Figure 1A.
3. Your pole is shipped in 2 sections reducing freight costs and handling difficulty, and increasing pole
rigidity. Lay the two Pole Sections (O) on a flat surface with the pole ends with the drilled holes end to
end. See Figure 1C.
4. Using the 1/2" Button Head Screws (U), 1/2" Lock Washers (V), and 5/16" Hex Key (X) attach two
Pole Connector Bars (W) to the inside of the end of one of the two Pole Sections (O). See Figure 1C.
5. Slide the other Pole Section (O) over the two Pole Connector Bars (W) and up against the partially
assembled Pole Section (O). See Figure 1C.
6. Using the remaining 1/2" Button Head Screws (U) and 1/2" Lock Washers (V), attach the 2nd
Pole Section (O) to the Pole Connector Bars (W). See Figure 1C.
7. Tighten all 1/2" Button Head Screws (U) only when the two Pole Sections (O) fit tightly together. If you
have access to a torque wrench, torque to 75 foot pounds or get as tight as possible by hand.
Implementation Date: 10/18/23
Q C B
M BA89QC-AW, BA89QC-BK,
OL89QC, OL89QCS
Warning!
Rev: 19 N.J.C. File: E\Pub\Instructions\Pole Systems\BA89QC-BK.pub
S
Item Qty Description
N 1 Rim and Net (packaged separately)
O 2 4" Square Pole Sections (packaged separately)
P TBD Quick Dry concrete (provided by customer)
Q 1 Pole Pad (packaged separately)
R 2 1/4-20 x 8" Carriage Bolt
S 2 Pre-Drilled Wooden Panels
T 2 1/4-20 Wing Nut
U 8 1/2" Button Head Screws
V 8 1/2" Lock Washers
W 2 Pole Connector Bars
X 1 5/16" Hex Key
Y 1 Warning Label
Scan for Supplemental
Installation and
Assembly Video
Ref#: 920096 L.M
