—— Installation and Safe Use Manual ——
6" H
For the following packages:
Customer Service
(800) 247-7668
Item
Qty
Description
A
1
Ground Anchor**
B
1
Pole
C
1
Lower Arm
D
2
Upper Arm
E
1
Crank
F
1
Height Gauge
G
1
Pointer
H
1
Pole Cap (Factory Installed)
I
1
1/2" X 6 1/2" Hex Bolt
J
1
1/2"-13 Deformed Lock Nut
K
1
3/4" X 7" Hex Bolt
L
2
3/4" Hex Nut
M
2
3/4" Flat Washer
N
2
5/8" X 11" Hex Bolt
O
3
5/8" X 12" Hex Bolt
P
6
5/8" Lock Nut
¨
Inspect all contents prior to installation. Report any missing parts to dealer immediately
¨
Read all instructions before proceeding.
·
Improper installation, maintenance or use may cause product failure and serious personal injury.
·
Three or four people in good physical condition and capable of lifting at least 90-100lbs each are
1. Leave the red plastic plugs in the four threaded holes in the Ground Anchor (A) to eliminate concrete
from plugging or damaging the threads.
2. Determine the footing location. When the Rim (CC) is at official 10' height, the distance from the face of
the Backboard (X) to the front of the Ground Anchor (A) and Pole (B) (without pole padding) is
approximately 56". Contact your local utility locator service before digging a 20" minimum diameter by
48" minimum deep footing. See Figures 1 & 2.
3. The top surface of the Ground Anchor (A) should be installed 1 1/2" to 2" higher than the playing surface
with the concrete slightly crowned to allow water run off with out interfering with the hinge tube At 10'
rim height the face of the backboard will be approximately 56" from the front of the pole.
4. Before pouring the concrete, make sure you have the required tools available including: a level, a
broomstick or similar pole to vibrate the concrete, and a tape measure to correctly position the
Ground Anchor (A).
Implementation Date: 4/15/24
EZ S
PR98UHTJR, HT6060G, HT6060GS, HT6072G, OL6060HT, OL6060HTS, OL6072HT
recommended for safe installation and assembly.
N.J.C.
Rev: 5
U P
PR98GHT, PR98GHTJR, PR98SHT, PR98SXLHT, PR98UHT,
P A R T S L I S T
**Packaged Separately
Item
Qty
Description
Q
1
5/8" X 5" Hex Bolt
R
4
5/8" X 1 1/2" Hex Bolt
S
4
5/8" Lock Washer
T
1
3/4" X 2 1/2" Hex Bolt
U
1
1/4" X 3" Hex Bolt
V
3
1/4" X 2 1/2" Hex Bolt
W
5
1/4" Hex Nut
X
1
Backboard** (see table on page 4)
Y
1
Backboard H-Frame** (see table on page 4)
Z
8
5/16" X 1" Machine Screw
AA
8
5/16" Lock Washer
BB
8
5/16" Hex Nut
CC
1
BA32 Rim** (BA39U optional)
DD
1
Pole Pad** (If applicable)
EE
1
Backboard Padding** (If applicable)
FF
16-18
60lb Bag of Quick Dry Concrete (Provided by Customer)
Warning!
1
File: \ pub\Inst\Pole Sys\Hang Time\HT6Pole2
S
Scan for Supplemental
.
Ref#: 920444
Installation and
Assembly Video
L.M..
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bison OL6060HT
Summary of Contents for Bison OL6060HT
- Page 1 EZ S For the following packages: Customer Service PR98GHT, PR98GHTJR, PR98SHT, PR98SXLHT, PR98UHT, Scan for Supplemental PR98UHTJR, HT6060G, HT6060GS, HT6072G, OL6060HT, OL6060HTS, OL6072HT (800) 247-7668 Installation and Assembly Video P A R T S L I S T **Packaged Separately...
- Page 2 Figure 1 Figure 2...
- Page 3 5. Mix concrete per manufacturers instructions. Begin adding concrete into the hole until the concrete is approximately 28”-30” deep. It’s a good idea for the first few batches of concrete to be mixed “wet”. This will increase your working time and allow the Ground Anchor (A) to be inserted easier. As you add concrete insert the broomstick into the wet concrete and agitate it up and down repeatedly, this will help to remove air bubbles.
- Page 4 Figure 4 7. Remove the plugs from the threaded holes in the Ground Anchor (A). Unpack the Pole (B) and Crank (E). Align the hinge tabs on the Pole (B) with the hinge tube on the Ground Anchor (A). Insert the 1/2” X 6 1/2” Hex Bolt (I) through the hinge tabs.
- Page 5 13. Review the table above to determine which instructions to follow for assembly of the Backboard (X) that comes with your system. HT5HFRAME2 HT6060G, HT6060GS, PR98UHTJR, PR98GHTJR, OL6060HT, OL6060HTS 1. Use the 5/16" X 1" Machine Screws (Z), 5/16" Lock Washers (AA) and 5/16" Hex Nuts (BB) to install Backboard H-Frame (Y) into Backboard (X).
- Page 6 HT6HFRAME2 : HT6072G, PR98GHT, PR98UHT, OL6072HT 1. Use the 5/16" X 1" Machine Screws (Z), 5/16" Lock Washers (AA) and 5/16" Hex Nuts (BB) to install Backboard H-Frame (Y) to Backboard (X). See Figure 11. 2. Once Backboard (X) is assembled refer to instruction 12 to complete system assembly.
- Page 7 Figure 12 14. Lift the assembled Backboard (X) and H-Frame (Y) up and align it with the bolt holes in the Lower Arm (C). Using a 5/8” X 12” Hex Bolt (O) and 5/8” Lock Nut (P) attach the Backboard (X) to the Lower Arm (C).
- Page 8 15. Install the Rim (CC) using the hardware and instructions provided with the Rim (CC). Install Net. 16. Locate the four 5/8” X 1 1/2” Hex Bolts (R) and 5/8” Lock Washers (S). Prepare them by having the 5/8” Lock Washers (S) installed and placed by the Ground Anchor (A). 17.
- Page 9 Figure 16 18. Attach Height Gauge (F) to the Lower Arm (C) with a 1/4” X 2 1/2” Hex Bolt (V) and 1/4”Hex Nut (W) in the back mounting hole. Slide the Pointer (G) onto a 1/4”-20 X 3”Hex Bolt (U) then install one 1/4”...
