Bison BA894GSR Instruction Manual

Portable/Adjustable Basketball Systems
BA894GSR, BA894USR, BA894USRO and Sportmaster 4.5
P A R T S L I S T
Item Qty Description
A 1 Portable Base
B 2 Foot Pad
C 2 "L" Bracket
D 4 3/8" X 4 1/2" Hex Bolt
E 2 Backboard Braces (1 right, 1 left)
F 4 3/8" x 1" Hex Bolt
G 8 3/8" Flat Washer
H 4 3/8" Lock Washer
I 4 3/8" Hex Nut
J 1 Backboard
Do not remove the safety strap until the backboard and goal installation is complete. This unit is under
extreme spring tension and severe injury and damage will result.
¨ Inspect all contents prior to installation. Report any missing parts to dealer immediately.
¨
NEVER SUBSTITUTE LOCALLY SOURCED COMPONENTS FOR MISSING, LOST, OR DAMAGED FACTORY COMPONENTS.
¨ Carefully read all instructions before proceeding. Pay special attention to all safety instructions.
¨ Save this instruction in the event that the manufacturer must be contacted in the future for maintenance information.
While gym floor installers and refinishers often indicate floors are OK to walk or play on in 7-10 days
after oil based polyurethane finishes are applied, in reality, it can actually take up to 30 days for all the
chemicals in the polyurethane to dissipate. Chemical reactions between the floor finish and certain
materials including urethane feet contacting the floor can cause permanent discoloration. Placement of
this product on floors prior to the 30-day final cure period may risk discoloration that would not be
1. Carefully lift the front of the Portable Base (A) with a forklift or 4 adults until the back wheels make
contact. Remove and discard the shipping pallet. Install the Foot Pads (B) and then tighten the jam nuts
against the Foot Pads (B). See Figure 1.
2. Make sure Portable Base (A) is on a level floor. It is best to finish assembly on the floor where the
Portable Base (A) will actually be used.
Implementation Date: 11/30/23
—— Instruction Manual ——
4 1/2' Safe Play Area
(PC3670)
(FT1668)
(FT1541)
(FT1950)
(FT1960)
(FT1080)
covered by the manufacturer's warranty.
Rev: 8 N.J.C.
Item Qty Description
K 1 Backboard Hardware (Included in J above)
L 1 Breakaway Goal
M 1 Breakaway Goal Hardware (Included in L above)
N 1 set Pads (front, side, and arm)
O 20 1/4"-20 x 3/4" Flat Head Screw
P 2 Locator Pin
Q 10 Padding Bracket
R 2 Floor Bushing
S 1 Rachet Wrench (PC3554)
WARNING!
NOTICE:
File: I:\Pub\Inst\Port.sys\BA894G
1
Assembly Video
(FT1288)
Ref#:930469 JED
