Bison VB1252W Instruction Manual

—— Instruction Manual ——
2 N
P A R T S L I S T
Item Qty Description
A 1 Dome Base
C 2 Net Carousel
1
E 3 1/2" x 1" Hex Bolt
G 2 1/2" Nylock Nut
I 3 1/2" Flat Washer
♦
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦
Read all instructions before proceeding.
1. Using a 1/2" x 1" Hex Bolt (E), 1/2" Flat Washer (I), Plastic Washer (F), and a 1/2" Nylock Nut (G) assemble the
Net Winding Racks (D) to the 2 Net Carousel (C). See Figure 1.
2. Attach the carousel assembly to the threaded end of the Upright Pole (B) using a 1/2" x 1" Hex Bolt (E), 1/2" Lock
Washer (H), and a 1/2" Flat Washer (I). See Figure 2.
3. Mount the assem-
Date: 4/11/2012 Rev: I.R.
S W
ET TORAGE
VB1252W Net Winders
D
Figure 1
B.A. N.J.C.
INDER
Item Qty Description
B 1 Upright Pole
D 2 Net Winding Rack
F 2 Plastic Washer
H 1 1/2" Lock Washer
C
E
I
F
G
File: \Pub\Instructions\Volleyball\VB1252W.pub.
1
Customer Service
(800) 247-7668
bled Upright Pole (B) onto the Dome
Ref#: 960713
