- Page 1 20:1 Implant Handpiece Pieza de mano 20:1 para implantología Pièce à main 20:1 pour l’implantologie INSTRUCTIONS FOR USE Read before use. Keep in a safe place for future reference. CAUTION: Federal (US) law restricts this device to sale by or on the order of a licensed professional...
-
Page 2: Specifications
Never operate handpiece without a rotary instrument. • SPECIFICATIONS Description Maxima Elite i Maxima Elite iL Item code 570-1147 570-1148 Gear Ratio 20:1 20:1 Speed 250 - 2500 rpm max. 250 - 2500 rpm max. Rotary Instruments Ø2.35 (ISO1797-1) Ø2.35 (ISO1797-1) 2 - Maxima Elite i... - Page 3 Do not connect or disconnect attachments until drive motor has stopped completely. • Fig. 1 Connecting 1. Slide the attachment over the nose portion of the motor until it clicks. 2. Attachment is secure. Disconnecting 1. Pull attachment away from motor to separate. 3 - Maxima Elite i...
- Page 4 Fig. 2 2. Pull to remove rotary instrument. Installing and removing internal irrigation clip Installing (Fig. 3) 1. Place needle though hole in head cap 2. Slide clip into channel on handpiece body Fig. 3 4 - Maxima Elite i...
-
Page 5: Cleaning And Lubrication
Handpiece Maintenance (Fig. 5) Note: Cleaning and lubrication is required before each sterilization cycle. 1. Remove rotary instrument. 2. Detach handpiece from motor. 3. Fit E-type spray adapter onto universal cap nozzle of Henry Schein Maxima HP ® Spray (112-6928) Fig. - Page 6 1. Remove rotary instrument. 2. Detach handpiece from motor . 3. Fit chuck adapter onto universal cap nozzle of Henry Schein® Maxima HP Spray. 4. Insert spray adapter into chuck and dispense spray for 1 - 2 seconds (Fig. 6).
- Page 7 Note: Cleaning and lubrication is required before each sterilization cycle. 1. Remove rotary instrument. 2. Detach handpiece from motor. 3. Attach handpiece to appropriate connector in Henry Schein® Maxima XTEND® Maintenance Machine (570-0072). 4. Run maintenance cycle. See Maxima XTEND instructions for further information.
- Page 8 2. Place handpiece in sterilization pouch and seal. Bag handpieces individually. 3. Steam autoclave for a minimum of 15 minutes at 270° F (135° C). Let autoclave cycle completely. Do not remove before handpiece is completely cool and pouch is dry. 8 - Maxima Elite i...
-
Page 9: Replacement Parts And Accessories
1 year from date of purchase. Henry Schein® will repair or replace products at its sole discretion. This warranty shall be limited to replacement or repair 9 - Maxima Elite i... - Page 10 Distributed by: HENRY SCHEIN INC. 135 DURYEA ROAD MELVILLE, NY 11747 USA Made In South Korea Fabricado en Corea del Sur Fabriqué en Corée du Sud M0085 2019/05 10 - Maxima Elite i...
