www.jasonl.com.au
ASSEMBLY INSTRUCTIONS
Horizon L-Shaped
Need help!
Quadro Square
Call us on
1300 527 665
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
Page 1 of 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jason.L Horizon L-Shaped Quadro Square
Summary of Contents for Jason.L Horizon L-Shaped Quadro Square
- Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 9...
- Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm COMPONENTS Table top x1 Table top Return x1 Legs Quadro x2 Legs Quadro Return x1 Beam x1 Beam Return x1 Plastic bracket x6 Joiner plates x2 SCREWS...
- Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 01 STEP 02 Using Allen Key provided, attach 2 plastic brackets (G) Using Allen Key provided, attach M8x20MM Socket head (J)- per legs (C &...
- Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 03 Adjust extendable beam (E) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800...
- Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 04 TOP VIEW STEP 05 Attach beam (E) to legs (C) using nut insert in legs. Frame looks like this. Using Allen Key, attach beam (E) with Socket (I) See point attached Page 5 of 9...
- Page 6 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 06 Now attach the return beam (F) to return leg (D) using nut insert in legs. See point attached. Then, connect the hook of the return beam to the beam of the main structure.
- Page 7 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 07 Attach Connector Plates (H) to Return Top (B) by tightening Screws (M) Page 7 of 9...
- Page 8 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 08 nut insert nut insert nut insert nut insert TABLE TOP Place table top (A) ontop of frame. Using nut inserts in the desk, use M6x30mm socket (L) and attach desktop to the frame. BOTTOM VIEW Using nut inserts in the desktop, use M6x30mm socket (L) and attach desktop (B) to the frame.
- Page 9 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Horizon L-Shaped Need help! Quadro Square Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm STEP 09 Using an Allen Key remove the top 2 caps from screens uprights. Bring two partition towards one another and slide the 90 degree connector rod - down between the two screen uprights. Under the desktop, use 4 l-shaped panel brackets to secure the screens to the desktops.
