ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
STEP 04
Attach beam (D) to legs (B) and Connector frame (C)
using nut insert in legs. See point attached
Need help!
Call us on
TOP VIEW
1300 527 665
STEP 05
F
F
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
Repeat Step 1,2,3 and 4 then please do another set of legs. Please keep
400mm distance between the two connector frame (C)
F
www.jasonl.com.au
4 of 6
