- Page 1 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table Sizes: 3200x1100 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 6 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table COMPONENTS Table top x2 Leg Quadro Square x2 Connector frame x2 Beam x2 Plastic bracket x8 SCREWS M8x20MM CSK x4 M8x20MM Socket head x4 M6x20MM Socket head x8 HW7x30MM Wood Screws x8 Allen key x2 Colour of the beam is always black, regardless desk frame colour.
- Page 3 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table STEP 01 STEP 02 STEP 03 TOP VIEW Use fixed beam (E) and secure beam Using Allen Key provided, attach 2 plastic brackets per Using Allen Key provided, attach M8x20MM using screws provided to suit desk leg (E) (as per picture above) using M6x20MM (H) Socket head (G)- screw socket half way into leg for both legs (B) and into Connector frame...
- Page 4 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table STEP 04 TOP VIEW STEP 05 Attach beam (D) to legs (B) and Connector frame (C) Frame looks like this. Using Allen Key, attach beam (D) with Socket (F) using nut insert in legs. See point attached Repeat Step 1,2,3 and 4 then please do another set of legs.
- Page 5 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table STEP 06 Please tighten HW7x30MM Wood Screws (J) through the Place the desktop on top of the frame. Please place the legs ideally indent- ed around 300mm from each end left and right of the Tops, Place the legs plastic brackets into the underneath of the tops.
- Page 6 ASSEMBLY INSTRUCTIONS Quadro Square Boardroom table STEP 08 Note: Exclude Power Box Cutout. Please inquire for assembly cost by contacting our customer service or sales representatives. www.jasonl.com.au Need help! 6 of 6 1300 527 665 Call us on...
