- Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 6...
- Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm COMPONENTS Table top x2 Leg Quadro Square x2 Connector frame x1 Beam x4 Plastic bracket x16 SCREWS M8x20MM CSK x8 M8x20MM Socket head x8 M6x20MM Socket head x16 M6x30MM Socket head x16 Allen key x2...
- Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm STEP 01 STEP 02 Using Allen Key provided, attach 4 plastic brackets per leg (E) Using Allen Key provided, attach M8x20MM Socket head (G)- (as per picture above) using M6x20MM (H) Socket head screw.
- Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm STEP 03 Adjust extendable beam (D) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600...
- Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm STEP 04 TOP VIEW STEP 05 Attach beam (D) to legs (B) and Connector frame (C) Frame looks like this. Using Allen Key, attach beam (D) with Socket (F) using nut insert in legs.
- Page 6 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Square Need help! Boardroom table Call us on 1300 527 665 Size: 2400 mm STEP 06 TABLE TOP BOTTOM VIEW Place desktops ontop of frame. Nut inserts in top will align with plastic joiner brackets using M6x30MM (I) sockets attached tops to frame.
